Denon AVR-2312 Service Manual

200
PCB7CHAMPASSY
Note: The symbols in the column "Remarks" indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model
EA : Australia model E1C : China model
BK : Black model SP : Premium Silver model
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
Q7001 943212500020S High Voltage PNP
Transistors(SOT-23)
CVTMMBT5401
Q7104,7105 00D2710301903 TR KTA1268BLATP CVTKTA1268BLATPA
Q7114 00D2710314903 T.R , KTA1024Y HVTKTA1024YT
Q7118 00D2710314903 T.R , KTA1024Y HVTKTA1024YT
Q7120,7121 00D2730471907 T.R , KTC3206Y HVTKTC3206YAT
Q7125 963219003340S T.R , BIAS KTC3964 CVTKTC3964
Q7131 00D9630235301 T.R Power, 2SD2560 HVT2SD2560
Q7132 00D9630235204 T.R Power, 2SB1647 HVT2SB1647
Q7138 943212500020S High Voltage PNP
Transistors(SOT-23)
CVTMMBT5401
Q7139 943214500040S High Voltage NPN
Transistors(SOT-23)
CVTMMBT5551
Q7204,7205 00D2710301903 TR KTA1268BLATP CVTKTA1268BLATPA
Q7214 00D2710314903 T.R , KTA1024Y HVTKTA1024YT
Q7218 00D2710314903 T.R , KTA1024Y HVTKTA1024YT
Q7220,7221 00D2730471907 T.R , KTC3206Y HVTKTC3206YAT
Q7225 963219003340S T.R , BIAS KTC3964 CVTKTC3964
Q7231 00D9630235301 T.R Power, 2SD2560 HVT2SD2560
Q7232 00D9630235204 T.R Power, 2SB1647 HVT2SB1647
Q7238 943212500020S High Voltage PNP
Transistors(SOT-23)
CVTMMBT5401
Q7239 943214500040S High Voltage NPN
Transistors(SOT-23)
CVTMMBT5551
Q7304,7305 00D2710301903 TR KTA1268BLATP CVTKTA1268BLATPA
Q7314 00D2710314903 T.R , KTA1024Y HVTKTA1024YT
Q7318 00D2710314903 T.R , KTA1024Y HVTKTA1024YT
Q7320,7321 00D2730471907 T.R , KTC3206Y HVTKTC3206YAT
Q7325 963219003340S T.R , BIAS KTC3964 CVTKTC3964
Q7331 00D9630235301 T.R Power, 2SD2560 HVT2SD2560
Q7332 00D9630235204 T.R Power, 2SB1647 HVT2SB1647
Q7338 943212500020S High Voltage PNP
Transistors(SOT-23)
CVTMMBT5401
Q7339 943214500040S High Voltage NPN
Transistors(SOT-23)
CVTMMBT5551
Q7404,7405 00D2710301903 TR KTA1268BLATP CVTKTA1268BLATPA
Q7414 00D2710314903 T.R , KTA1024Y HVTKTA1024YT
Q7418 00D2710314903 T.R , KTA1024Y HVTKTA1024YT
Q7420,7421 00D2730471907 T.R , KTC3206Y HVTKTC3206YAT
Q7425 963219003340S T.R , BIAS KTC3964 CVTKTC3964
Q7431 00D9630235301 T.R Power, 2SD2560 HVT2SD2560
Q7432 00D9630235204 T.R Power, 2SB1647 HVT2SB1647
Q7438 943212500020S High Voltage PNP
Transistors(SOT-23)
CVTMMBT5401
Q7439 943214500040S High Voltage NPN
Transistors(SOT-23)
CVTMMBT5551
Q7504,7505 00D2710301903 TR KTA1268BLATP CVTKTA1268BLATPA
Q7514 00D2710314903 T.R , KTA1024Y HVTKTA1024YT
Q7518 00D2710314903 T.R , KTA1024Y HVTKTA1024YT
Q7520,7521 00D2730471907 T.R , KTC3206Y HVTKTC3206YAT
Q7525 963219003340S T.R , BIAS KTC3964 CVTKTC3964
Q7531 00D9630235301 T.R Power, 2SD2560 HVT2SD2560
Q7532 00D9630235204 T.R Power, 2SB1647 HVT2SB1647
Q7538 943212500020S High Voltage PNP
Transistors(SOT-23)
CVTMMBT5401
Q7539 943214500040S High Voltage NPN
Transistors(SOT-23)
CVTMMBT5551

Denon AVR-2312 Specifications

General

Impedance	8 Ω
Speaker selector	A+B
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@8 Ohm)	135 W
Power output per channel (20-20KHz@8 Ohm)	105 W
HDMI in	7
Composite video in	4
Ethernet LAN (RJ-45) ports	1
Multichannel audio input type	RCA
Component video (YPbPr/YCbCr) in	2
Headphone connectivity	6.3 mm
Connectivity technology	Wired
Speakers connectivity type	Binding post
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Wi-Fi	No
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Preset stations quantity	56
Internet radio services supported	Last.fm, Napster
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Display	VFD
HDMI version	1.4a
Product color	Black
Audio decoders	Dolby Pro Logic IIz, Dolby TrueHD, DTS-HD Master Audio
Volume control	Rotary
Apple docking compatibility	iPad, iPhone, iPod
Number of products included	1 pc(s)
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	600 W

Weight and Dimensions

Depth	382 mm
Width	434 mm
Height	167 mm
Weight	11000 g
