Page #197 background image
197
PCB FRONT ASSY
Note: The symbols in the column "Remarks" indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model
EA : Australia model E1C : China model
BK : Black model SP : Premium Silver model
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC601 00D2631289900 IC AZ4580MTR-E1 CVIAZ4580MTR-E1
IC607 00D2631289900 IC AZ4580MTR-E1 CVIAZ4580MTR-E1
Q6026 943219006820S TR KTC1027Y CVTKTC1027YT
Q6042 943214500020S TR 2SC3052 CVT2SC3052
Q6052 943214500020S TR 2SC3052 CVT2SC3052
Q6062 943214500020S TR 2SC3052 CVT2SC3052
Q6081 943216500020S TR RT1N141C CVTRT1N141C
Q6112 943215500020S TR RT1P141C CVTRT1P141C
Q6311,6312 943215500020S TR RT1P141C CVTRT1P141C
Q6313,6314 943216500020S TR RT1N141C CVTRT1N141C
Q6703 943216500020S TR RT1N141C CVTRT1N141C
D6021 90M-HD302360R DIODE ZJ6.8BT CVDZJ6.8BT
D6023,6024 00D9630328409 DIODE , RECTIFIER, AXIAL CVD1N4007ST
D6026 943202007690S DIODE , ZENER 18V CVDZJ18BT
D6027 00D9430087209 ZENER DIODE ZJ24B 1/2W CVDZJ24BT
D6041 943209001080S DIODE 1SS355T CVD1SS355T
D6051 943209001080S DIODE 1SS355T CVD1SS355T
D6061 943209001080S DIODE 1SS355T CVD1SS355T
D6712 00D2760694903 DIODE , ZENER (CHIP,5.1V) HVDUDZS5.1BSR
D6729,6730 00D2760694903 DIODE , ZENER (CHIP,5.1V) HVDUDZS5.1BSR
D6803 963209003510S
DIODE , RELIABLE ESD
PROTECTION
CVDCDS3C05HDMI1
D6835,6836 963209003510S
DIODE , RELIABLE ESD
PROTECTION
CVDCDS3C05HDMI1
RESISTORS GROUP
z
R6024 943124500040S
RES,M-
OXIDEFILM(1W/4.7ohm)
CRG1SANJ4R7RT
VR601 943671010330S ENCODER VR CSR2A055Z
VR604 943671010330S ENCODER VR CSR2A055Z
CAPACITORS GROUP
C6021 00D9430175108 ELECT CAP 10UF 50V CCEA1HH100T
C6022,6023 00MOF15104040
CAP,METAL-
FILM(100V/0.1uF)
CCME2A104JXT
C6024 943134501530S CAP , ELECT(63V/470uF) CCEA1JH471 *
C6025 943134010530S ELECT CAP 1UF 50V C CCEA1HH1R0T
C6027 943134010530S ELECT CAP 1UF 50V C
CCEA1HH1R0T
C6031 nsp CAP, CHIP(1608, 50V/30pF) CCUS1H300JA
