Denon AVR-2312 Service Manual

198
Ref. No. Part No. Part Name Remarks Q'ty New
C6034 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C6044 nsp COPPER WIRE C3A206
C6071-6073 nsp CHIP CAP 100PF 50V J CCUS1H101JA
C6081 nsp CHIP CAP 0.1UF/50V/2012 CCUC1H104KC
C6082 00D9430175108 ELECT CAP 10UF 50V CCEA1HH100T
C6083 nsp
CAP, CHIP(1608,
50V/0.047uF)
CCUS1H473KC
C6084 nsp CHIP CAP 0.01UF 50V K CCUS1H103KC
C6113 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C6114 963134010980S ELECT CAP 47UF 16V CCEA1CH470T
C6321 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C6351,6352 nsp CHIP CAP 0.01UF 50V K CCUS1H103KC
C6356 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C6417 nsp
CAP, CHIP(1608,
50V/0.047uF)
CCUS1H473KC
C6423,6424 nsp
CAP, CHIP(1608,
50V/0.047uF)
CCUS1H473KC
C6425 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C6501,6502 nsp CHIP CAP 1000PF 50VK CCUS1H102KC
C6503 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C6512,6513 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C6514 943134501540S CAP , ELECT(50V/1uF)-S CCEA1HKS1R0T *
C6523 943134501550S CAP , ELECT(50V/10uF)-S CCEA1HKS100T *
C6601 943134501550S CAP , ELECT(50V/10uF)-S CCEA1HKS100T *
C6603,6604 nsp CHIP CAP 330PF 50V J CCUS1H331JA
C6623,6624 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C6691 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C6693 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C6694 943134501540S CAP , ELECT(50V/1uF)-S CCEA1HKS1R0T *
C6702 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C6712 00D9430175108 ELECT CAP 10UF 50V CCEA1HH100T
C6719 00D9430062101 ELECT CAP 100UF 16V CCEA1CH101T
C6720 nsp CAP, CHIP(1608, 50V/82pF) CCUS1H820JA
C6726
nsp
CAP, CHIP(1608,
50V/0.047uF)
CCUS1H473KC
C6731,6732 943134010530S ELECT CAP 1UF 50V C CCEA1HH1R0T
C6733 943134501540S CAP , ELECT(50V/1uF)-S CCEA1HKS1R0T *
C6735 nsp CHIP CAP 100PF 50V J CCUS1H101JA
C6753 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C6755 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C6802 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C6803 00D9430173003 CAP , ELECT(10V/220uF)-S CCEA1AKS221T
C6812 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
OTHERS PARTS GROUP
BK601,602 nsp FIP BRACKET CMD1A572
BK603 nsp PCB BRACKET CMD1A569

Denon AVR-2312 Specifications

General

Impedance	8 Ω
Speaker selector	A+B
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@8 Ohm)	135 W
Power output per channel (20-20KHz@8 Ohm)	105 W
HDMI in	7
Composite video in	4
Ethernet LAN (RJ-45) ports	1
Multichannel audio input type	RCA
Component video (YPbPr/YCbCr) in	2
Headphone connectivity	6.3 mm
Connectivity technology	Wired
Speakers connectivity type	Binding post
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Wi-Fi	No
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Preset stations quantity	56
Internet radio services supported	Last.fm, Napster
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Display	VFD
HDMI version	1.4a
Product color	Black
Audio decoders	Dolby Pro Logic IIz, Dolby TrueHD, DTS-HD Master Audio
Volume control	Rotary
Apple docking compatibility	iPad, iPhone, iPod
Number of products included	1 pc(s)
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	600 W

Weight and Dimensions

Depth	382 mm
Width	434 mm
Height	167 mm
Weight	11000 g
