211
PCB CNT ASSY
Note: The symbols in the column "Remarks" indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model
EA : Australia model E1C : China model
BK : Black model SP : Premium Silver model
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC991 963239008800S I.C, RS232 DRIVER(3.3V) CVIILX3232DT
IC993 00D2631286903 I.C , REGULATOR (12V) CVIPQ120DNA1ZPH
D9904 00D2760665903 DIODE , ZENER 16V CVDZJ16BT
D9906 00D2760794900
DIODE, ULTRA-HIGH
SPEED
CVDKDS160RTKP
RESISTORS GROUP
R9701-9705 nsp RES,CHIP(0OHM,5%,1608) CRJ10DJ0R0T
CAPACITORS GROUP
C9901 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C9903-9905 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C9906 00D9430175108 ELECT CAP 10UF 50V CCEA1HH100T
C9907 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C9908 nsp CAP, CHIP(1608, 50V/33pF) CCUS1H330JA
C9909 nsp CAP, CHIP(1608, 50V/33pF) CCUS1H330JA
C9920,9921 00D9430175108 ELECT CAP 10UF 50V CCEA1HH100T
C9923,9924 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
OTHERS PARTS GROUP
CN21A nsp
PIN HEADER
(15P,1.25mm,STRAIGHT,B-
TO-B)
CJP15GI281Z
CN22A nsp
PIN HEADER
(17P,1.25mm,STRAIGHT,B-
TO-B)
CJP17GI281Z
CN23A nsp
PIN HEADER
(13P,1.25mm,STRAIGHT,B-
TO-B)
CJP13GI281Z
CN24A nsp
PIN HEADER
(27P,1.25mm,STRAIGHT,B-
TO-B)
CJP27GI281Z
CN25A nsp
PIN HEADER
(17P,1.25mm,STRAIGHT,B-
TO-B)
CJP17GI281Z
CN26A nsp
PIN HEADER
(15P,1.25mm,STRAIGHT,B-
TO-B)
CJP15GI281Z
CN27A nsp
PIN HEADER
(21P,1.25mm,STRAIGHT,B-
TO-B)
CJP21GI281Z
