Denon AVR-2312 Service Manual

210
Ref. No. Part No. Part Name Remarks Q'ty New
L7821 943115010260S SPEAKER COIL (0.5UH) CLEY0R5KAK
L7831 943115010260S SPEAKER COIL (0.5UH) CLEY0R5KAK
L7841 943115010260S SPEAKER COIL (0.5UH) CLEY0R5KAK
L7851 943115010260S SPEAKER COIL (0.5UH) CLEY0R5KAK
L7861 943115010260S SPEAKER COIL (0.5UH) CLEY0R5KAK
RY781-784 682010023006S RELAY 12V 2C1P CSL3A021ZU
RY788 943682000810S RELAY 12V 2C2P CSL4A016ZU
TM601 963183010730S MODULE, TUNER(USA,F-TYPE FM ANT) E3 CNVKSTMT001MV0-2S
TM601 183010013007S MODULE, TUNER(USA,F-TYPE FM ANT) E2,EA CNVKSTMT104MV1-2
TM601 183010014000S MODULE, TUNER(USA,F-TYPE FM ANT) E1C CNVKSTMT004MV1-2

Denon AVR-2312 Specifications

General

Impedance	8 Ω
Speaker selector	A+B
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@8 Ohm)	135 W
Power output per channel (20-20KHz@8 Ohm)	105 W
HDMI in	7
Composite video in	4
Ethernet LAN (RJ-45) ports	1
Multichannel audio input type	RCA
Component video (YPbPr/YCbCr) in	2
Headphone connectivity	6.3 mm
Connectivity technology	Wired
Speakers connectivity type	Binding post
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Wi-Fi	No
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Preset stations quantity	56
Internet radio services supported	Last.fm, Napster
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Display	VFD
HDMI version	1.4a
Product color	Black
Audio decoders	Dolby Pro Logic IIz, Dolby TrueHD, DTS-HD Master Audio
Volume control	Rotary
Apple docking compatibility	iPad, iPhone, iPod
Number of products included	1 pc(s)
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	600 W

Weight and Dimensions

Depth	382 mm
Width	434 mm
Height	167 mm
Weight	11000 g
