Denon AVR-2312 Service Manual

209
Ref. No. Part No. Part Name Remarks Q'ty New
C9312 943134010620S ELECT CAP 4700UF 25V CCEA1EH472E
C9316 943134010620S ELECT CAP 4700UF 25V CCEA1EH472E
C9317-9319 nsp MYLAR CAP 0.1UF 50V J HCQI1H104JZT
C9321-9323 nsp MYLAR CAP 0.1UF 50V J HCQI1H104JZT
OTHERS PARTS GROUP
BD691 nsp CHIP FERRITE BEAD(60ohm 4516) CLZ9Z014Z
BK601 nsp PLATE , MAIN PCB CMC2A424
BK701 nsp PCB BRACKET CMD1A569
BK901,902 nsp BRACKET, PCB(FUSE) CMD1A730
BK903,904 nsp PCB BRACKET CMD1A569
BN701 nsp WIRE ASS'Y LOCKING
(9P,2.5MM,220MM,UL1569#20,105)
CWB7E0092203D
BN702B nsp WIRE ASS'Y LOCKING
(7P,2.5MM,350MM,UL1569#20,105)
CWB7E0073503D
BN703 nsp WIRE ASS'Y LOCKING
(3P,2.5MM,220MM,UL1569#24,105)
CWB7C0032203D
BN931 nsp WIRE ASS'Y LOCKING
(5P,2.0MM,150MM,UL1007#26)
CWB1B005150HC
BN932 nsp WIRE ASS'Y LOCKING
(9P,2.0MM,200MM,UL1007#26)
CWB1B009200HC
CN61A nsp PIN HEADER (17P,1.25mm,STRAIGHT,B-
TO-B)
CJP17GI281Z
CN62A nsp PIN HEADER (15P,1.25mm,STRAIGHT,B-
TO-B)
CJP15GI281Z
CN63A nsp PIN HEADER (17P,1.25mm,STRAIGHT,B-
TO-B)
CJP17GI281Z
CN64A nsp PIN HEADER (21P,1.25mm,STRAIGHT,B-
TO-B)
CJP21GI281Z
CN781 nsp WAFER, YW396-NNAB(7.92mm) CJP03GA89ZY
CN932 nsp LOCK-WAFER/STRAIGHT/2MM
PITCH/9PIN
CJP09GI288ZY
CN940 nsp LOCK-WAFER/STRAIGHT/2.5MM
PITCH/5PIN
CJP05GI289ZY
CN941 nsp LOCK-WAFER/STRAIGHT/2.5MM
PITCH/3PIN
CJP03GI289ZY
CN97A nsp PIN HEADER (15P,1.25mm,STRAIGHT,B-
TO-B)
CJP15GI281Z
CN98A,99A nsp PIN HEADER (11P,1.25mm,STRAIGHT,B-
TO-B)
CJP11GI281Z
F9301-9305 nsp FUSE HOLDER KJCFC5S
GND71 nsp EARTH PALTE HJT1A025
JK681 943643010150S JACK NOSPCC2PW/R CJJ4N034U
JK682 943643010160S JACK NOSPCC1PBLACK CJJ4M046U
JK684
943643010160S JACK NOSPCC1PBLACK CJJ4M046U
JK689 943643010150S JACK NOSPCC2PW/R CJJ4N034U
JK781 943646010240S JACK NOSPCC6PRRR/BBB CJJ5R008U
JK782 943643101050S JACK, SPK 8P (JB-801A-CU-02) CJJ5Q007U *
JW703A nsp WIRE ASS'Y
(1P,200MM,BLK,UL1015#20,CKM-T)
CWE7102200TT
L6752 943115010270S MPX COIL(FM19KHzFILTER) E2,EA CLM4B001Z
L6922 943115010270S MPX COIL(FM19KHzFILTER) E2,EA CLM4B001Z
L7801 943115010260S SPEAKER COIL (0.5UH) CLEY0R5KAK
L7811 943115010260S SPEAKER COIL (0.5UH) CLEY0R5KAK

Denon AVR-2312 Specifications

General

Impedance	8 Ω
Speaker selector	A+B
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@8 Ohm)	135 W
Power output per channel (20-20KHz@8 Ohm)	105 W
HDMI in	7
Composite video in	4
Ethernet LAN (RJ-45) ports	1
Multichannel audio input type	RCA
Component video (YPbPr/YCbCr) in	2
Headphone connectivity	6.3 mm
Connectivity technology	Wired
Speakers connectivity type	Binding post
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Wi-Fi	No
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Preset stations quantity	56
Internet radio services supported	Last.fm, Napster
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Display	VFD
HDMI version	1.4a
Product color	Black
Audio decoders	Dolby Pro Logic IIz, Dolby TrueHD, DTS-HD Master Audio
Volume control	Rotary
Apple docking compatibility	iPad, iPhone, iPod
Number of products included	1 pc(s)
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	600 W

Weight and Dimensions

Depth	382 mm
Width	434 mm
Height	167 mm
Weight	11000 g
