Denon AVR-2312 Service Manual

208
Ref. No. Part No. Part Name Remarks Q'ty New
R7841 nsp RES,M-OXIDEFILM(1W/10ohm) CRG1SANJ100RT
R7842 nsp RES, M-OXIDE FILM(2W/10ohm) CRG2SANJ100RT
R7851 nsp RES,M-OXIDEFILM(1W/10ohm) CRG1SANJ100RT
R7852 nsp RES, M-OXIDE FILM(2W/10ohm) CRG2SANJ100RT
R7861 nsp RES,M-OXIDEFILM(1W/10ohm) CRG1SANJ100RT
R7862 nsp RES, M-OXIDE FILM(2W/10ohm) CRG2SANJ100RT
R7921-7926 nsp RES,M-OXIDEFILM(1W/2.2Kohm) CRG1SANJ222RT
CAPACITORS GROUP
C6096 nsp CHIP CAP 100PF 50V J CCUS1H101JA
C6719 00D9609010023 CAP , ELECT(50V/0.47uF) CCEA1HHR47T
C6724 943134010590S ELECT CAP 22UF 50V CCEA1HH220T
C6728 943134010590S ELECT CAP 22UF 50V CCEA1HH220T
C6730 nsp CHIP CAP 330PF 50V J CCUS1H331JA
C6745 nsp CHIP CAP 0.01UF 50V K CCUS1H103KC
C6802 943134010590S ELECT CAP 22UF 50V CCEA1HH220T
C6805 943134010590S ELECT CAP 22UF 50V CCEA1HH220T
C6806 nsp CHIP CAP 330PF 50V J CCUS1H331JA
C6820 nsp CHIP CAP 0.01UF 50V K CCUS1H103KC
C6829,6830 943134010590S ELECT CAP 22UF 50V CCEA1HH220T
C6833,6834 943134010590S ELECT CAP 22UF 50V CCEA1HH220T
C6835,6836 nsp CHIP CAP 330PF 50V J CCUS1H331JA
C6845 00D9609010023 CAP , ELECT(50V/0.47uF) CCEA1HHR47T
C6849 00D9430175108 ELECT CAP 10UF 50V CCEA1HH100T
C6891,6892 00D9430175108 ELECT CAP 10UF 50V CCEA1HH100T
C6893,6894 nsp CHIP CAP 100PF 50V J CCUS1H101JA
C6897 nsp CHIP CAP 0.01UF 50V K CCUS1H103KC
C6901-6903 nsp CHIP CAP 100PF 50V J CCUS1H101JA
C6904 nsp CAP, CHIP(1608, 50V/33pF) CCUS1H330JA
C6907 nsp CHIP CAP 100PF 50V J CCUS1H101JA
C6911 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C6921,6922 nsp CAP , MYLAR E2,EA HCQI1H822JZT
C6923,6924 nsp CAP , MYLAR E2,EA HCQI1H472JZT
C6931,6932
00D9430175108 ELECT CAP 10UF 50V CCEA1HH100T
C7802 nsp MYLAR CAP 0.047UF 50V HCQI1H473JZT
C7806 nsp CHIP CAP 1000PF 50VK CCUS1H102KC
C7812 nsp MYLAR CAP 0.047UF 50V HCQI1H473JZT
C7816 nsp CHIP CAP 1000PF 50VK CCUS1H102KC
C7822 nsp MYLAR CAP 0.047UF 50V HCQI1H473JZT
C7826 nsp CHIP CAP 1000PF 50VK CCUS1H102KC
C7832 nsp MYLAR CAP 0.047UF 50V HCQI1H473JZT
C7836 nsp CHIP CAP 1000PF 50VK CCUS1H102KC
C7842 HVDMTZJ5.6BT MYLAR CAP 0.047UF 50V HCQI1H473JZT
C7846 nsp CHIP CAP 1000PF 50VK CCUS1H102KC
C7852 nsp MYLAR CAP 0.047UF 50V HCQI1H473JZT
C7856 nsp CHIP CAP 1000PF 50VK CCUS1H102KC
C7862 nsp MYLAR CAP 0.047UF 50V HCQI1H473JZT
C7866 nsp CHIP CAP 1000PF 50VK CCUS1H102KC
C7893-7899 nsp CAP, CHIP(2012,250V/0.01uF) CCUC2E103KC
C7901,7902 nsp METALLIZED CAP 0.1UF 250V J KCME2E104JP04T
C7903 nsp CHIP CAP 1000PF 50VK CCUS1H102KC
C7905 943134010470S ELECT CAP 0.1UF 50V CCEA1HH0R1T
C7907,7908 963134010180S CAP , ELECT(71V/12000uF) CCET71VLKS123N
C7927 00D9430175108 ELECT CAP 10UF 50V CCEA1HH100T
C7931 00MOA10705020 ELECT CAP 100UF 50V CCEA1HH101T
C9301 943134501560S CAP , ELECT(16V/100uF)-S CCEA1CKS101T *
C9302 943134501550S CAP , ELECT(50V/10uF)-S CCEA1HKS100T *
C9303 00D9430062101 ELECT CAP 100UF 16V CCEA1CH101T
C9304 00D9430175108 ELECT CAP 10UF 50V CCEA1HH100T
C9305 943134501550S CAP , ELECT(50V/10uF)-S CCEA1HKS100T *
C9306 943134010600S ELECT CAP 3300UF 16V CCEA1CH332E
C9307 943134501550S CAP , ELECT(50V/10uF)-S CCEA1HKS100T *
C9308 943134010600S ELECT CAP 3300UF 16V CCEA1CH332E
C9309 00MOA10705020 ELECT CAP 100UF 50V E3,E1C CCEA1HH101T
C9309 00MOA10705020 ELECT CAP 100UF 50V E2,EA CCEA1HH101T
C9310
943134010620S ELECT CAP 4700UF 25V CCEA1EH472E
C9311 943134501560S CAP , ELECT(16V/100uF)-S CCEA1CKS101T *

Denon AVR-2312 Specifications

General

Impedance	8 Ω
Speaker selector	A+B
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@8 Ohm)	135 W
Power output per channel (20-20KHz@8 Ohm)	105 W
HDMI in	7
Composite video in	4
Ethernet LAN (RJ-45) ports	1
Multichannel audio input type	RCA
Component video (YPbPr/YCbCr) in	2
Headphone connectivity	6.3 mm
Connectivity technology	Wired
Speakers connectivity type	Binding post
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Wi-Fi	No
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Preset stations quantity	56
Internet radio services supported	Last.fm, Napster
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Display	VFD
HDMI version	1.4a
Product color	Black
Audio decoders	Dolby Pro Logic IIz, Dolby TrueHD, DTS-HD Master Audio
Volume control	Rotary
Apple docking compatibility	iPad, iPhone, iPod
Number of products included	1 pc(s)
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	600 W

Weight and Dimensions

Depth	382 mm
Width	434 mm
Height	167 mm
Weight	11000 g
