Denon AVR-2312 Service Manual

212
Ref. No. Part No. Part Name Remarks Q'ty New
CN28A nsp
PIN HEADER
(11P,1.25mm,STRAIGHT,B-
TO-B)
CJP11GI281Z
CN41A nsp
PIN HEADER
(15P,1.25mm,STRAIGHT,B-
TO-B)
CJP15GI281Z
CN42A nsp
PIN HEADER
(27P,1.25mm,STRAIGHT,B-
TO-B)
CJP27GI281Z
CN43A nsp
PIN HEADER
(15P,1.25mm,STRAIGHT,B-
TO-B)
CJP15GI281Z
CN44A nsp
PIN HEADER
(17P,1.25mm,STRAIGHT,B-
TO-B)
CJP17GI281Z
CN45A nsp
PIN HEADER
(11P,1.25mm,STRAIGHT,B-
TO-B)
CJP11GI281Z
CN51A nsp
PIN HEADER
(15P,1.25mm,STRAIGHT,B-
TO-B)
CJP15GI281Z
CN52A nsp
PIN HEADER
(17P,1.25mm,STRAIGHT,B-
TO-B)
CJP17GI281Z
CN53A nsp
PIN HEADER
(13P,1.25mm,STRAIGHT,B-
TO-B)
CJP13GI281Z
CN61B nsp
PIN SOCKET
(17P,1.25mm,ANGLE, B-TO-
B) P
CJP17HJ282Z
CN62B nsp
PIN SOCKET
(15P,1.25mm,ANGLE, B-TO-
B)
CJP15HJ282Z
CN63B nsp
PIN SOCKET
(17P,1.25mm,ANGLE, B-TO-
B) P
CJP17HJ282Z
CN64B nsp
PIN SOCKET
(21P,1.25mm,ANGLE, B-TO-
B)
CJP21HJ282Z
CN97B nsp
PIN SOCKET
(15P,1.25mm,ANGLE, B-TO-
B)
CJP15HJ282Z
CN98B,99B nsp
PIN SOCKET
(11P,1.25mm,ANGLE, B-TO-
B)
CJP11HJ282Z
JK991 943646100420S
JACK, D-SUB 9P (HDR-9PF-
RSB)
CJJ9W001Z
JK993 643010086019S
JACK, STEREO (RED
MOLD)
CJJ2D019Z
JW901,902 nsp
WIRE ASS'Y (1P,
80MM,BLK,#22)
CWE5202080A

Denon AVR-2312 Specifications

General

Impedance	8 Ω
Speaker selector	A+B
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@8 Ohm)	135 W
Power output per channel (20-20KHz@8 Ohm)	105 W
HDMI in	7
Composite video in	4
Ethernet LAN (RJ-45) ports	1
Multichannel audio input type	RCA
Component video (YPbPr/YCbCr) in	2
Headphone connectivity	6.3 mm
Connectivity technology	Wired
Speakers connectivity type	Binding post
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Wi-Fi	No
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Preset stations quantity	56
Internet radio services supported	Last.fm, Napster
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Display	VFD
HDMI version	1.4a
Product color	Black
Audio decoders	Dolby Pro Logic IIz, Dolby TrueHD, DTS-HD Master Audio
Volume control	Rotary
Apple docking compatibility	iPad, iPhone, iPod
Number of products included	1 pc(s)
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	600 W

Weight and Dimensions

Depth	382 mm
Width	434 mm
Height	167 mm
Weight	11000 g
