Denon AVR-2312 Service Manual

201
Ref. No. Part No. Part Name Remarks Q'ty New
Q7604,7605 00D2710301903 TR KTA1268BLATP CVTKTA1268BLATPA
Q7614 00D2710314903 T.R , KTA1024Y HVTKTA1024YT
Q7618 00D2710314903 T.R , KTA1024Y HVTKTA1024YT
Q7620,7621 00D2730471907 T.R , KTC3206Y HVTKTC3206YAT
Q7625 963219003340S T.R , BIAS KTC3964 CVTKTC3964
Q7631 00D9630235301 T.R Power, 2SD2560 HVT2SD2560
Q7632 00D9630235204 T.R Power, 2SB1647 HVT2SB1647
Q7638 943212500020S High Voltage PNP
Transistors(SOT-23)
CVTMMBT5401
Q7639 943214500040S High Voltage NPN
Transistors(SOT-23)
CVTMMBT5551
Q7704,7705 00D2710301903 TR KTA1268BLATP CVTKTA1268BLATPA
Q7714 00D2710314903 T.R , KTA1024Y HVTKTA1024YT
Q7718 00D2710314903 T.R , KTA1024Y HVTKTA1024YT
Q7720,7721 00D2730471907 T.R , KTC3206Y HVTKTC3206YAT
Q7725 963219003340S T.R , BIAS KTC3964 CVTKTC3964
Q7731 00D9630235301 T.R Power, 2SD2560 HVT2SD2560
Q7732 00D9630235204 T.R Power, 2SB1647 HVT2SB1647
Q7738 943212500020S High Voltage PNP
Transistors(SOT-23)
CVTMMBT5401
Q7739 943214500040S High Voltage NPN
Transistors(SOT-23)
CVTMMBT5551
D7011,7012 943209001080S DIODE 1SS355T CVD1SS355T
D7108,7109 00D9430182609 DIODE 1SS133MT CVD1SS133MT
D7115,7116 00D9430182609 DIODE 1SS133MT CVD1SS133MT
D7118 00D9430182609 DIODE 1SS133MT CVD1SS133MT
D7139 00D9430182609 DIODE 1SS133MT CVD1SS133MT
D7208,7209 00D9430182609 DIODE 1SS133MT CVD1SS133MT
D7215,7216 00D9430182609 DIODE 1SS133MT CVD1SS133MT
D7218 00D9430182609 DIODE 1SS133MT CVD1SS133MT
D7239 00D9430182609 DIODE 1SS133MT CVD1SS133MT
D7308,7309 00D9430182609 DIODE 1SS133MT CVD1SS133MT
D7315,7316 00D9430182609 DIODE 1SS133MT CVD1SS133MT
D7318 00D9430182609 DIODE 1SS133MT CVD1SS133MT
D7339 00D9430182609 DIODE 1SS133MT CVD1SS133MT
D7408,7409 00D9430182609 DIODE 1SS133MT CVD1SS133MT
D7415,7416 00D9430182609 DIODE 1SS133MT CVD1SS133MT
D7418 00D9430182609 DIODE 1SS133MT CVD1SS133MT
D7439 00D9430182609 DIODE 1SS133MT CVD1SS133MT
D7508,7509 00D9430182609 DIODE 1SS133MT CVD1SS133MT
D7515,7516 00D9430182609 DIODE 1SS133MT CVD1SS133MT
D7518 00D9430182609 DIODE 1SS133MT CVD1SS133MT
D7539 00D9430182609 DIODE 1SS133MT CVD1SS133MT
D7608,7609 00D9430182609 DIODE 1SS133MT CVD1SS133MT
D7615,7616 00D9430182609 DIODE 1SS133MT CVD1SS133MT
D7618 00D9430182609 DIODE 1SS133MT CVD1SS133MT
D7639 00D9430182609 DIODE 1SS133MT CVD1SS133MT
D7708,7709 00D9430182609 DIODE 1SS133MT CVD1SS133MT
D7715,7716 00D9430182609 DIODE 1SS133MT CVD1SS133MT
D7718 00D9430182609 DIODE 1SS133MT CVD1SS133MT
D7739 00D9430182609 DIODE 1SS133MT CVD1SS133MT
ZD714 943202010080S DIODE ZJ5.1B CVDZJ5.1BT
ZD715,716 90M-HD302440R DIODE ZJ4.7B CVDZJ4.7BT
ZD724 943202010080S DIODE ZJ5.1B CVDZJ5.1BT
ZD725,726 90M-HD302440R DIODE ZJ4.7B CVDZJ4.7BT
ZD734 943202010080S DIODE ZJ5.1B CVDZJ5.1BT
ZD735,736 90M-HD302440R DIODE ZJ4.7B CVDZJ4.7BT
ZD744 943202010080S DIODE ZJ5.1B CVDZJ5.1BT
ZD745,746 90M-HD302440R DIODE ZJ4.7B CVDZJ4.7BT
ZD754 943202010080S DIODE ZJ5.1B CVDZJ5.1BT
ZD755,756 90M-HD302440R DIODE ZJ4.7B CVDZJ4.7BT
ZD764 943202010080S DIODE ZJ5.1B CVDZJ5.1BT
ZD765,766 90M-HD302440R DIODE ZJ4.7B CVDZJ4.7BT
ZD774 943202010080S DIODE ZJ5.1B CVDZJ5.1BT

Denon AVR-2312 Specifications

General

Impedance	8 Ω
Speaker selector	A+B
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@8 Ohm)	135 W
Power output per channel (20-20KHz@8 Ohm)	105 W
HDMI in	7
Composite video in	4
Ethernet LAN (RJ-45) ports	1
Multichannel audio input type	RCA
Component video (YPbPr/YCbCr) in	2
Headphone connectivity	6.3 mm
Connectivity technology	Wired
Speakers connectivity type	Binding post
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Wi-Fi	No
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Preset stations quantity	56
Internet radio services supported	Last.fm, Napster
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Display	VFD
HDMI version	1.4a
Product color	Black
Audio decoders	Dolby Pro Logic IIz, Dolby TrueHD, DTS-HD Master Audio
Volume control	Rotary
Apple docking compatibility	iPad, iPhone, iPod
Number of products included	1 pc(s)
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	600 W

Weight and Dimensions

Depth	382 mm
Width	434 mm
Height	167 mm
Weight	11000 g
