Denon AVR-2312 Service Manual

214
Ref. No. Part No. Part Name Remarks Q'ty New
C5134 nsp CHIP CAP 0.01UF 50V K CCUS1H103KC
C5136 nsp CHIP CAP 0.01UF 50V K CCUS1H103KC
C5142,5143 00D9430062101 ELECT CAP 100UF 16V CCEA1CH101T
C5146 nsp CHIP CAP 0.01UF 50V K CCUS1H103KC
C5147 963134010980S ELECT CAP 47UF 16V CCEA1CH470T
C5148 nsp CHIP CAP 0.01UF 50V K CCUS1H103KC
C5149 963134010980S ELECT CAP 47UF 16V CCEA1CH470T
C5154 nsp CHIP CAP 0.01UF 50V K CCUS1H103KC
C5155 nsp CHIP CAP 220PF 50V CCUS1H221JA
C5156 nsp CHIP CAP 0.01UF 50V K CCUS1H103KC
C51585159 nsp CAP, CHIP(1608, 50V/0.047uF) CCUS1H473KC
C5161 nsp CAP, CHIP(1608, 50V/0.047uF) CCUS1H473KC
C5162,5163 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C5165 nsp CHIP CAP 0.01UF 50V K CCUS1H103KC
C5166,5167 nsp CAP, CHIP(1608, 50V/0.047uF) CCUS1H473KC
C5169 nsp CAP, CHIP(1608, 50V/0.047uF) CCUS1H473KC
C5170,5171 943134010530S ELECT CAP 1UF 50V C CCEA1HH1R0T
C5173 943134010530S ELECT CAP 1UF 50V C CCEA1HH1R0T
C5178,5179 nsp CAP, CHIP(1608, 50V/0.047uF) CCUS1H473KC
C5181 nsp CAP, CHIP(1608, 50V/0.047uF) CCUS1H473KC
C51825189 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C51905191 963134010980S ELECT CAP 47UF 16V CCEA1CH470T
C5192-5201 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C5202 963134010980S ELECT CAP 47UF 16V CCEA1CH470T
C5203 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C5204 nsp CHIP CAP 10UF 6.3V CCUC0J106KC
C5205,5206 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C5213 00D9430175108 ELECT CAP 10UF 50V CCEA1HH100T
C52205222 nsp CHIP CAP 10UF 6.3V CCUC0J106KC
C5223-5225 nsp RES, CHIP(2012/5%/0ohm) CRJ18AJ0R0T
OTHERS PARTS GROUP
BN51A nsp
WIRE ASS'Y
(1P,100MM,BLK,UL1007#24,CKM-T)
CWE4202100AT
BN53A nsp
WIRE ASS'Y
(1P,100MM,BLK,UL1007#24,CKM-T)
CWE4202100AT
CN51B nsp
PIN SOCKET (15P,1.25mm,ANGLE,
B-TO-B)
CJP15HJ282Z
CN52B nsp
PIN SOCKET (17P,1.25mm,ANGLE,
B-TO-B) P
CJP17HJ282Z
CN53B nsp
PIN SOCKET (13P,1.25mm,ANGLE,
B-TO-B)
CJP13HJ282Z
CN931 nsp
LOCK-WAFER/ANGLE/2MM
PITCH/5PIN
CJP05GJ288ZY
JK551 943643101130S JACK, 3P(YL),SEPA-GND, SILVER CJJ4P076Z *
JK553 943643101080S JACK, S-VIDEO (DIN-409A X 2) CJJ9N001Z *
JK554 943643101140S JACK, 2P(YL),SEPA-GND, SILVER CJJ4N095Z *
JK556-558 943643101100S JACK, 3P (RCA-303D-00-08) CJJ4S050Z *

Denon AVR-2312 Specifications

General

Impedance	8 Ω
Speaker selector	A+B
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@8 Ohm)	135 W
Power output per channel (20-20KHz@8 Ohm)	105 W
HDMI in	7
Composite video in	4
Ethernet LAN (RJ-45) ports	1
Multichannel audio input type	RCA
Component video (YPbPr/YCbCr) in	2
Headphone connectivity	6.3 mm
Connectivity technology	Wired
Speakers connectivity type	Binding post
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Wi-Fi	No
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Preset stations quantity	56
Internet radio services supported	Last.fm, Napster
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Display	VFD
HDMI version	1.4a
Product color	Black
Audio decoders	Dolby Pro Logic IIz, Dolby TrueHD, DTS-HD Master Audio
Volume control	Rotary
Apple docking compatibility	iPad, iPhone, iPod
Number of products included	1 pc(s)
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	600 W

Weight and Dimensions

Depth	382 mm
Width	434 mm
Height	167 mm
Weight	11000 g
