Denon AVR-2312 Service Manual

Conrmation item Setting and display Details of how to operate remote controller
Output sequence of remote control codes
※
It is useful to form a macro program.
Contents of conrmation Remarks
10
Amp Assign (signal) Path
(Amp Assign : 2CH)
Amp assign : 2CH
SURROUND mode : DIRECT
Vol -20dB
Display:
A 1 0 D V D
1.Press [AMP]
2.Press [ZONE SELECT] , Select "ZONE2"
3.Press [ZONE OFF]
q
ZONE2 POWER OFF ·Input : Analog / Output : Speakers (SURR BACK L/R)
·Input : Analog / Output : Pre OUT (Front L/R)
(
※
As the input source, you can switch from DVD to other ones.)
4.Press [ZONE SELECT], Select "ZONE3"
5.Press [ZONE OFF]
w
ZONE3 POWER OFF
6.Press [ZONE SELECT], Select "MAIN"
7.Press [
7
]
e
7
Initialization &Amp assign 2CH &
SURROUND mode : DIRECT & Volume
-20dB
8.Press [DVD]
r
DVD (Main Zone)
11
Amp Assign (signal) Path
(Amp Assign : BiAMP)
Amp assign : BiAMP
SURROUND mode : Multi ch STEREO
Vol -20dB
Display:
A 1 1 D V D
1.Press [AMP]
2.Press [ZONE SELECT] , Select "ZONE2"
3.Press [ZONE OFF]
q
ZONE2 POWER OFF ·Input : Analog / Output : Speakers (SURR BACK L/R)
·Input : Analog / Output : Pre OUT (SB L/R)
(
※
As the input source, you can switch from DVD to other ones.)
4.Press [ZONE SELECT], Select "ZONE3"
5.Press [ZONE OFF]
w
ZONE3 POWER OFF
6.Press [ZONE SELECT], Select "MAIN"
7.Press [
8
]
e
8
Initialization & Amp assign BiAMP &
SURROUND mode : Multi ch STEREO &
Volume -20dB
8.Press [DVD]
r
DVD (Main Zone)
12
Amp Assign (signal) Path
(Amp Assign : Front-B)
Amp assign : Front-B
SURROUND mode : Multi ch STEREO
Vol -20dB
Display:
A 1 2 D V D
1.Press [AMP]
2.Press [ZONE SELECT] , Select "ZONE2"
3.Press [ZONE OFF]
q
ZONE2 POWER OFF ·Input : Analog / Output : Speakers (SURR BACK L/R)
·Input : Analog / Output : Pre OUT (SB L/R)
(
※
As the input source, you can switch from DVD to other ones.)
4.Press [ZONE SELECT], Select "ZONE3"
5.Press [ZONE OFF]
w
ZONE3 POWER OFF
6.Press [ZONE SELECT], Select "MAIN"
7.Press [
9
]
e
9
Initialization & Amp assign Front-B &
SURROUND mode Multi ch STEREO &
Volume -20dB
8.Press [DVD]
r
DVD (Main Zone)
13
Front Height (signal) Path Amp assign : Front Height ( As AVR2312)
Amp assign : NORMAL (As AVR3312)
SURROUND mode : Multi ch STEREO
Vol -20dB
Surround Parameter-Speaker : F.Height
Display:
A 1 4 D V D
1.Press [AMP]
2.Press [ZONE SELECT] , Select "ZONE2"
3.Press [ZONE OFF]
q
ZONE2 POWER OFF ·Input : Analog / Output : Speakers (F.HEIGHT L/R)
(
※
As the input source, you can switch from DVD to other ones.)
AVR2312 and AVR3312, operate differently
4.Press [ZONE SELECT], Select "ZONE3"
5.Press [ZONE OFF]
w
ZONE3 POWER OFF
6.Press [ZONE SELECT], Select "MAIN"
7.Press [+10/MEMORY]
e
MEMORY/+10 (Main Zone)
As AVR2312
Initialization & Amp assign Front Height &
SURROUND mode:Multi ch STEREO &
Volume -20dB
As AVR3312
Initialization & Amp assign NORMAL &
SURROUND mode:Multi ch STEREO &
Volume -20dB & Surround Parameter-
Speaker : F.Height
8.Press [DVD]
r
DVD (Main Zone)
14
Front Wide (signal) Path Amp assign : NORMAL
SURROUND mode : Multi ch STEREO
Vol -20dB
Surround Parameter-Speaker : F.Wide
Display:
A 1 5 D V D
1.Press [AMP]
2.Press [ZONE SELECT], Select "ZONE2"
3.Press [ZONE OFF]
q
ZONE2 POWER OFF ·Input : Analog / Output : Speakers (F.WIDE L/R)
(
※
As the input source, you can switch from DVD to other ones.)
only AVR3312
4.Press [ZONE SELECT], Select "ZONE3"
5.Press [ZONE OFF]
w
ZONE3 POWER OFF
6.Press [ZONE SELECT], Select "MAIN"
7.Press [SLEEP]
e
SLEEP MODE
Initialization &Amp assign NORMAL &
SURROUND mode:Multi ch STEREO &
Volume -20dB Surround Parameter-Speaker
: F.Wide
8.Press [DVD]
r
DVD (Main Zone)
28
g.19
g.20
g.20
g.22
g.23

Denon AVR-2312 Specifications

General

Impedance	8 Ω
Speaker selector	A+B
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@8 Ohm)	135 W
Power output per channel (20-20KHz@8 Ohm)	105 W
HDMI in	7
Composite video in	4
Ethernet LAN (RJ-45) ports	1
Multichannel audio input type	RCA
Component video (YPbPr/YCbCr) in	2
Headphone connectivity	6.3 mm
Connectivity technology	Wired
Speakers connectivity type	Binding post
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Wi-Fi	No
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Preset stations quantity	56
Internet radio services supported	Last.fm, Napster
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Display	VFD
HDMI version	1.4a
Product color	Black
Audio decoders	Dolby Pro Logic IIz, Dolby TrueHD, DTS-HD Master Audio
Volume control	Rotary
Apple docking compatibility	iPad, iPhone, iPod
Number of products included	1 pc(s)
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	600 W

Weight and Dimensions

Depth	382 mm
Width	434 mm
Height	167 mm
Weight	11000 g
