Denon AVR-2312 Service Manual

67
Error
Code
Details of Error code Display Coping strategies
5A
NACK was received when "C"
command sent to Sub CPU, DSP
PLD etc.
S u b * * * m i n
C o n n e c t i o n F a i l 5 A
Turn off and on the power. Updating
starts automatically.
5B
NACK was received when "L"
command sent to Sub CPU, DSP,
PLD etc.
S u b * * * m i n
U p d a t i n g f a i l 5 B
Turn off and on the power. Updating
starts automatically.
5C
Sub CPU, DSP, PLD etc. failed to
receive rmware for rewriting sent
from DM860 (when timed out).
S u b * * * m i n
U p d a t i n g f a i l 5 C
Turn off and on the power. Updating
starts automatically.
5D
Sub CPU, DSP, PLD etc. failed
to receive rmware for rewriting
sent from DM860 (when an error
occurred).
S u b * * * m i n
U p d a t i n g f a i l 5 D
Turn off and on the power. Updating
starts automatically.
5E
Data in rmware such as Sub CPU,
DSP and PLD for rewriting sent
from DM860 was invalid (when a
Check Sum error occurred).
S u b * * * m i n
U p d a t i n g f a i l 5 E
Turn off and on the power. Updating
starts automatically.
5F
Invalid data in rmware such as Sub
CPU, DSP and PLD for rewriting
sent from DM860 was invalid (invalid
data was received).
S u b * * * m i n
U p d a t i n g f a i l 5 F
Turn off and on the power. Updating
starts automatically.
60
NACK was received when "P"
command sent to Sub CPU, DSP,
PLD etc.
S u b * * * m i n
U p d a t i n g f a i l 6 0
Turn off and on the power. Updating
starts automatically.
61
NACK was received when "I"
command sent to Sub CPU, DSP,
PLD etc.
S u b * * * m i n
U p d a t e C h e c k N G 6 1
Turn off and on the power. Updating
starts automatically.
62
Start of Sub
µ-
com fail.
S u b * * * m i n
U p d a t i n g f a i l 6 2
Turn off and on the power. Updating
starts automatically.
80
Acquisition of serial ash data failed
before serial ash was deleted.
G U I * * * m i n
U p d a t i n g f a i l 8 0
Turn off and on the power. Updating
starts automatically.
81
Deleting data failed before serial
ash was rewritten.
G U I * * * m i n
U p d a t i n g f a i l 8 1
Turn off and on the power. Updating
starts automatically.
82
Receiving rmware for rewriting
serial ash sent by DM860 failed
(when timed out).
G U I * * * m i n
U p d a t i n g f a i l 8 2
Turn off and on the power. Updating
starts automatically.
83
Receiving rmwarefor rewriting
serial ash sent by DM860 failed
(when an error).
G U I * * * m i n
U p d a t i n g f a i l 8 3
Turn off and on the power. Updating
starts automatically.
84
Receiving rmwarefor rewriting
serial ash sent by DM860 failed
(when a Check Sum error).
G U I * * * m i n
U p d a t i n g f a i l 8 4
Turn off and on the power. Updating
starts automatically.
85
Receiving rmwarefor rewriting
serial ash sent by DM860 failed
(when invalid data was received).
G U I * * * m i n
U p d a t i n g f a i l 8 5
Turn off and on the power. Updating
starts automatically.
86
The data verication was invalid
after serial ash was rewritten.
G U I * * * m i n
U p d a t i n g f a i l 8 6
Turn off and on the power. Updating
starts automatically.

Denon AVR-2312 Specifications

General

Impedance	8 Ω
Speaker selector	A+B
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@8 Ohm)	135 W
Power output per channel (20-20KHz@8 Ohm)	105 W
HDMI in	7
Composite video in	4
Ethernet LAN (RJ-45) ports	1
Multichannel audio input type	RCA
Component video (YPbPr/YCbCr) in	2
Headphone connectivity	6.3 mm
Connectivity technology	Wired
Speakers connectivity type	Binding post
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Wi-Fi	No
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Preset stations quantity	56
Internet radio services supported	Last.fm, Napster
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Display	VFD
HDMI version	1.4a
Product color	Black
Audio decoders	Dolby Pro Logic IIz, Dolby TrueHD, DTS-HD Master Audio
Volume control	Rotary
Apple docking compatibility	iPad, iPhone, iPod
Number of products included	1 pc(s)
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	600 W

Weight and Dimensions

Depth	382 mm
Width	434 mm
Height	167 mm
Weight	11000 g
