Denon AVR-2808 Service Manual

101
AVR-2808
CC535 nsp CK73B1H102KT +1005
CC536 nsp CK73B1A104KT +1005
CC538 nsp CK73B1H102KT +1005
CC539-544 nsp CK73B1A104KT +1005
CC545 nsp CK73B1H102KT +1005
CC546 nsp CK73B1A104KT +1005
CC548 00D 257 0525 903 CK73B0J475KT(P) +1608
CC550,551 nsp CK73B1A104KT +1005
CC554-557 00D 257 0525 903 CK73B0J475KT(P) +1608
CC560,561 00D 257 0525 903 CK73B0J475KT(P) +1608
CC563 00D 257 0525 903 CK73B0J475KT(P) +1608
CC564-567 00D 254 4657 904 CE67C1C100MT(RV2)
CC604-606 00D 257 0525 903 CK73B0J475KT(P) +1608
CC607-609 nsp CK73B1A104KT +1005
CC610-612 nsp CK73B1H102KT +1005
CC951 nsp CK73B1E103KT(1005)
CC952 nsp CK73B1H102KT +1005
CC953 00D 257 0525 903 CK73B0J475KT(P) +1608
CC954 nsp CC73CH1H101JT +1005
CC956,957 00D 257 5002 926 CC73CH1H100DT +1005
CC958 00D 257 0525 903 CK73B0J475KT(P) +1608
CC966 nsp CK73B1E104KT +1608
CC967 00D 257 5006 935 CK73B1H331KT +1005
CC968 00D 257 5006 919 CK73B1H221KT +1005
CC970 nsp CK73B1A104KT +1005
CC974 nsp CK73B1A104KT +1005
CC976 nsp CK73B1A104KT +1005
CC983 00D 257 0525 903 CK73B0J475KT(P) +1608
CC985 nsp CK73B1A104KT +1005
CC989 nsp CK73B1A104KT +1005
OTHERS PARTS GROUP
CX035 00D 203 5405 005 3P SDN-VH CON.CORD
CX041 00D 205 0355 046 4P KR CON BASE(L)
CX063 nsp 6P CONN.BASE(KR-PH)
CX071 00D 205 1343 950 7P FFC BASE(9610SC)
CX072 00D 205 1325 075 7P SOCKET(9120)
CX111 nsp 11P SOCKET(9120)
CX122 00D 205 1326 029 12P SOCKET(9120)
CX163 nsp 16P SOCKT(9120)
CX172 00D 205 1326 074 17P SOCKT(9120)
CY131 nsp 13P CON PLUG TWG-P
CY154 nsp 15P CON.SOCKET TUC-P
CY171 00D 205 1326 074 17P SOCKT(9120)
FB152 00D 235 0130 903 CHIP EMIFIL(11A121) +1608
FB301 nsp RM73B--0R0KT +1608
FB551 00D 235 0130 903 CHIP EMIFIL(11A121) +1608
FB552 00D 235 0158 901 CHIP BEADS(18PG121) +1608
FB553,554 00D 235 0130 903 CHIP EMIFIL(11A121) +1608
FB701-704 00D 235 0130 903 CHIP EMIFIL(11A121) +1608
FB951 00D 235 0181 907 ZBFS5105-PT
JK503 00D 205 1447 005 19P-HDMI-CONNECTOR
JK551 00D 205 1447 005 19P-HDMI-CONNECTOR
JK701 00D 205 1447 005 19P-HDMI-CONNECTOR
L802 00D 235 0125 905 INDUCTOR(FLC32C220K)+3216
L901 00D 235 0125 905 INDUCTOR(FLC32C220K)+3216
W101,102 nsp M3 SCREW TERMINAL
X101 00D 399 1053 901 FCX-03(24.576MHz)
X201 00D 399 1054 900 FCX-03(20.815MHz)
X251 00D 399 1054 900 FCX-03(20.815MHz)
X551 00D 399 1039 909 FCX-03(28.322MHZ)
X801 00D 399 1052 902 FCX-03(28.6363MHz)
X901 00D 399 0864 900 XTAL(13.5MHZ) +REF
X951 00D 399 1038 900 FCX-03(12MHZ)
Ref. No. Part No. Part Name Remarks Q'ty New
