Denon AVR-2808 Service Manual

112
AVR-2808
1U-3854A POWER AMP P.W.B. UNIT ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC701 00D 263 1100 063 KIA7809API-U/P
IC702,703 00D 263 1100 021 KIA7812API-U/P
IC704,705 00D 263 1099 022 KIA7912PI-U/P
IC706 00D 263 1293 006 KIA7818API-U/P
IC707 00D 263 1100 034 KIA7815API-U/P
TR401 00D 271 0301 903 KTA1268-BL-AT/P
TR402-408 00D 273 0495 006 2SC3964
TR423-429 00D 273 0458 904 KTC3200-BL-AT/P
TR702 00D 269 0192 902 KRC102S-RTK/P (10K-10K)
TR703 00D 269 0184 907 KRA102S-RTK/P (10K-10K)
TR705 00D 273 0458 904 KTC3200-BL-AT/P
TR706 00D 269 0192 902 KRC102S-RTK/P (10K-10K)
TR708 00D 269 0184 907 KRA102S-RTK/P (10K-10K)
TR709 00D 271 0312 905 KTA1504S-GR-RTK/P
TR714 00D 269 0192 902 KRC102S-RTK/P (10K-10K)
TR715 00D 269 0184 907 KRA102S-RTK/P (10K-10K)
TR716 00D 273 0464 901 KTC3875S-GR-RTK/P
TR718 00D 273 0464 901 KTC3875S-GR-RTK/P
TR720 00D 269 0192 902 KRC102S-RTK/P (10K-10K)
TR721 00D 269 0184 907 KRA102S-RTK/P (10K-10K)
TR722 00D 271 0312 905 KTA1504S-GR-RTK/P
TR723 00D 273 0464 901 KTC3875S-GR-RTK/P
TR724 00D 269 0192 902 KRC102S-RTK/P (10K-10K)
TR726 00D 269 0184 907 KRA102S-RTK/P (10K-10K)
TR732 00D 269 0192 902 KRC102S-RTK/P (10K-10K)
TR733 00D 269 0184 907 KRA102S-RTK/P (10K-10K)
TR737 00D 273 0464 901 KTC3875S-GR-RTK/P
TR738 00D 271 0312 905 KTA1504S-GR-RTK/P
TR739 00D 273 0464 901 KTC3875S-GR-RTK/P
D401-421 00D 276 0401 905 1SS133T77 (TAPE)
D702-705 00D 276 0401 905 1SS133T77 (TAPE)
D707,708 00D 276 0401 905 1SS133T77 (TAPE)
D710-713 00D 276 0401 905 1SS133T77 (TAPE)
D714,715 00D 276 0338 007 S4VB20F
D717 00D 276 0855 001 D3SB20-7103
ZD401-414 00D 276 0643 970 MTZJ4.7A T77
RESISTORS GROUP
R422 00D 244 2051 961 RS14B3A101JNBST(S)
R423 00D 241 2387 940 RD14B2E4R7JNBST
R424-437 00D 244 2052 957 RS14B3A562JNBST(S)
R438-451 00D 241 2375 981 RD14B2E220JNBST
R452-479 00D 244 2671 956 RS14B3DR47JNBST(S)
R706,707 00D 243 2039 032 RW99=3H0R1K
R752-765 00D 244 2671 901 RS14B3D100JNBST(S)
R768-771 00D 244 2052 960 RS14B3A221JNBST(S)
VR401-407 00D 211 6159 908 V06PB102T(3318F-1-102A)
CAPACITORS GROUP
C401 00D 254 4804 906 CE04W2A101MT(RA3)
C402-408 00D 254 4802 908 CE04W1J101MT(RA3)
C409-415 00D 254 4802 924 CE04W1J470MT(RA3)
C416-429 00D 254 4586 949 CE04W2A100MT(RA3)
C704 00D 254 4524 985 CE04W1H100MT SMG/RE3
C706 nsp CK73B1H103KT (1608) +1608
C707 00D 254 4538 939 CE04W1C470MT SMG/RE3
C708 nsp CK73B1E104KT +1608
