Denon AVR-2808 Service Manual

106
AVR-2808
1U-3840A FRONT P.W.B. UNIT ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC101 00D 499 0318 002 GP1UM271XKVF
z IC102 00D 268 0073 905 ICP-N15T
IC201-203 00D 269 0241 002 TORX142L(F)
IC204,205 00D 269 0242 001 TOTX142L(F)
IC206,207 00D 262 1205 907 TC74HCU04AF(TP1) +C
IC208 00D 262 3561 908 TC74VHC14F
IC601 00D 262 3676 903 TC74VHCT08AF(E,K,F)
IC602 00D 262 2580 906 CXA1511M +C
IC701 00D 269 0240 003 GP1FMV31RK0F
IC702 00D 263 0615 902 BA15218F-DXE2 +C
TR101 00D 269 0191 903 KRA104S-RTK/P (47K-47K)
TR102 00D 274 0212 907 2SD1782KT146
TR103 00D 269 0193 901 KRC104S-RTK/P (47K-47K)
TR106 00D 273 0494 900 KTC2022D-Y-RTF/P
TR112,113 00D 274 0212 907 2SD1782KT146
TR301 00D 269 0192 902 KRC102S-RTK/P (10K-10K)
TR302,303 00D 271 0312 905 KTA1504S-GR-RTK/P
TR304 00D 269 0193 901 KRC104S-RTK/P (47K-47K)
TR371-373 00D 269 0192 902 KRC102S-RTK/P (10K-10K)
TR601 00D 269 0191 903 KRA104S-RTK/P (47K-47K)
TR602 00D 271 0326 904 2SA1954(B)-TE85L
TR603 00D 269 0192 902 KRC102S-RTK/P (10K-10K)
TR604 00D 273 0464 901 KTC3875S-GR-RTK/P
TR605 00D 269 0191 903 KRA104S-RTK/P (47K-47K)
D101 00D 276 0704 903 1SR35-400A(T93X)
D103 00D 276 0794 900 KDS160-RTK/P
D105 00D 276 0794 900 KDS160-RTK/P
D107 00D 276 0794 900 KDS160-RTK/P
D203-205 00D 276 0738 908 KDS226-RTK/P (A-K)
D601,602 00D 276 0794 900 KDS160-RTK/P
D603 00D 276 0833 900 ESD PROTECTOR(6802)
D604 00D 276 0794 900 KDS160-RTK/P
D605 00D 276 0837 906 NSAD500F-T1B-A
ZD101 00D 276 0761 975 MTZJ18B T77
ZD102 00D 276 0762 903 MTZJ24B T77
ZD103 00D 276 0636 903 MTZJ8.2BT77
ZD601 00D 276 0760 963 MTZJ6.2B T77
ZD701-703 00D 276 0683 930 UDZS5.1B-TE17 +C
LD301 00D 393 9671 002 SMLU12416W-S
LD371-373 00D 393 9662 901 SEL1410ETP2(D2/D3)
FL101 00D 393 8095 003 FLD(HCA-19LM07T)
RESISTORS
GROUP
R146 00D 244 2043 937 RS14B3A100JNBST(S)
R149 00D 244 2043 937 RS14B3A100JNBST(S)
CAPACITORS GROUP
C101 00D 255 1279 951 CQ93M1H104JT(B)
C102 00D 256 1042 903 CF93A2E104KT
C103,104 nsp CK73B1E104KT +1608
C105 nsp CC73CH1H101JT +1608
C106 00D 254 4196 986 CE04W1H100MT (SRA)
C107 nsp CC73CH1H101JT +1608
C108 00D 255 1279 951 CQ93M1H104JT(B)
C109 00D 254 4536 928 CE04W1A101MT SMG/RE3
C110 00D 254 4524 985 CE04W1H100MT SMG/RE3
