Denon AVR-2808 Service Manual

96
AVR-2808
PARTS LIST OF P.W.B. UNIT
＊本表に"nsp" と記載されている部品は供給できません。
＊ Parts for which "nsp" is indicated on this table cannot be supplied.
＊本表に記載されている部品は、補修用部品のため製品に使用している部品とは一部、形状、寸法などが異なる場合があります。
＊ The parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions.
1U-3838A DIGITAL P.W.B. UNIT ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC101-103 00D 262 3449 004 LC89057W-VF4A
IC107 00D 263 1197 908 BU4094BCFV-E2
IC109-111 00D 262 2944 908 SN74HC151APW-EL2 +REF
IC151 00D 262 3590 005 EPM240T100C5N
IC152 00D 262 3261 907 CY2302 +REF
IC153 00D 262 3436 907 TC74VHC244FT
IC201 00D 262 3550 032 ADSP21366KBCZ1AA1135
IC202 00D 262 3732 902 EN5312QI-T
IC203 00D 262 3339 907 SN74LVC139APWR +REF
IC204,205 00D 262 3559 907 TC74VHC573FT
IC206 00D GEN 8595 DSP1 ROM SUB ASSY S29AL016D90TFI020#
IC207 00D 262 3681 008 CY7C1049DV33-10ZSXI
IC251 00D 262 3729 038 ADSP21367KBPZ2A1135
IC254 00D 262 3746 008 W9864G2GH-7
IC255 00D GEN 8596 DSP2 ROM SUB ASSY S29AL016D90TFI020#
IC301 00D 262 3501 900 PCM1803DBR
IC302 00D 263 1047 906 NJM2115M-TE1 +C
IC303 00D 263 1249 911 UPC2933BT1D-E1-AT
IC304 00D 262 3585 900 DSD1608PAHR
IC305-310 00D 262 3555 901 SA5532ADR
IC312 00D 263 1288 901 PQ050DNA1ZPH
IC351,352 00D 262 3552 904 AK4385ET
IC353,354 00D 263 1289 900 AZ4580MTR-E1
IC551 00D 262 3744 903 BR24L02FV-W
IC552,553 00D 262 3723 908 SN74CBT3306PWG4
IC554 00D 262 3720 008 SII9135CTU
IC555 00D 263 1270 906 UPC2918BT1D-E1-AT
IC556 00D 262 3744 903 BR24L02FV-W
IC557,558 00D 262 3723 908 SN74CBT3306PWG4
IC601 00D 262 3579 000 EPM570F256C5N
IC701 00D 263 1271 905 AZ1117H-1.8TRE1
IC702 00D 262 3719 006 SII9134CTU
IC801 00D 263 1271 905 AZ1117H-1.8TRE1
IC802 00D 263 1271 921 AZ1117H-3.3TRE1
IC803 00D 263 1271 918 AZ1117H-2.5TRE1
IC804 00D 263 1249 908 UPC2925BT1D-E1-AT
IC805 00D 263 1271 905 AZ1117H-1.8TRE1
IC806 00D 262 3603 002 ADV7401BSTZ-110
IC807 00D 262 3478 004 ADV7320
IC901 00D 263 1270 906 UPC2918BT1D-E1-AT
IC902 00D 262 3577 002 FLI2310-LF-CF
IC903 00D 262 3598 007 K4S643232H-UC60
IC951 00D GEN 8594 SUB CPU SUB ASSY M3062LFGPGP
IC956 00D 262 3410 907 TC74VHCT08AFT
IC958 00D 262 3444 902 TC74VHC08FT
IC959 00D 263 1271 921 AZ1117H-3.3TRE1
IC960 00D 262 3732 902 EN5312QI-T
IC990 00D 262 3410 907 TC74VHCT08AFT
TR201,202 00D 269 0184 907 KRA102S-RTK/P (10K-10K)
TR203 00D 269 0192 902 KRC102S-RTK/P (10K-10K)
TR251 00D 269 0184 907 KRA102S-RTK/P (10K-10K)
TR252 00D 269 0192 902 KRC102S-RTK/P (10K-10K)
TR301-304 00D 269 0192 902 KRC102S-RTK/P (10K-10K)
TR305-307 00D 269 0184 907 KRA102S-RTK/P (10K-10K)
TR308 00D 269 0192 902 KRC102S-RTK/P (10K-10K)
TR309 00D 269 0184 907 KRA102S-RTK/P (10K-10K)
ファームウエアをアップデート
するときは、SDI で最終バージョ
ンを確認して下さい。
サービス基板はアップデートし
て使用下さい。
WhenupdateFirmware,please
confirmalastversioninSDI.
Usetheserviceboardafter
updatingit.
