AVR-2808
4. AUDIO UNIT ASSY
(1) Disconnect the connector wires. ( コネクタワイヤーをはずす。）
(2) Disconnect the connector board. . ( コネクタボードをはずす。）
Please refer to "EXPLODED VIEW" for the disassembly method of each P.W.B included in AUDIO UNIT ASSY.
AUDIOUNITASSY の各基板のはずしかたは "EXPLODEDVIEW" を参照してください。
5. AM FM TUNER (AVR-2808CI/AVR-988/AVR-2808 model only)
Please refer to "EXPLODED VIEW" for the disassembly method of AM FM TUNER.
AMFMTUNER のはずしかたは "EXPLODEDVIEW" を参照してください。
6. REMOTE/IPOD UNIT
Please refer to "EXPLODED VIEW" for the disassembly method of REMOTE/IPOD UNIT.
REMOTE/IPODUNIT のはずしかたは "EXPLODEDVIEW" を参照してください。
Proceeding (手順) : TOP COVER SUB ASSY → BACK PANEL
→ 1.DIGITAL UNIT ASSY → 2-2.AUDIO UNIT ASSY
Picture A
Board to board
Picture A
Board to board
Proceeding (手順) : TOP COVER SUB ASSY → BACK PANEL
→ 1.DIGITAL UNIT ASSY → 2-2.AUDIO UNIT ASSY
→ 44.AM FM TUNER
Proceeding (手順) : TOP COVER SUB ASSY → BACK PANEL
→ 1. DIGITAL UNIT ASSY → 2-2.AUDIO UNIT ASSY
→ 44.AM FM TUNER → 3-4.REMOTE/IPOD UNIT
