AVR-3310CI/AVR-3310/AVR990/AVC-3310
(3) Disconnect the FFC Cables.
(4) Remove the screws
[Attention of assembling]
When mounting the FRONT PANEL ASSY on the CHASSIS, do so with the DOOR open so as to prevent
breaking the EARTH PLATE(DOOR).
If the FRONT PANEL ASSY is mounted on the chassis with the DOOR closed, the EARTH PLATE(DOOR) will
hit the CHASSIS and break.
Direction of photograph: C
FFC Cable
ٟ
dd
s
Please refer to "EXPLODED VIEW" for the disassembly method of each P.W.B included in FRONT PANEL ASSY.
DOOR open
DOOR closed (EARTH PLATE (DOOR) will be broken.)
EARTH PLATE (DOOR)
DOOR
DOOR
EARTH PLATE (DOOR)
Direction of photograph: A
Direction of photograph: A
