Denon AVR-391 Owner's Manual

30
ENGLISH
Examples of front display
Below we describe typical examples of displays on the set’s display window.
Front Display Description
Top menu display
Speaker Setup
w
q
q The number of the current selected setting menu is displayed.
w The currently selected item is displayed on the display.
Use ui to move to the item you want to set.
Display when changing settings
Front •Large–
w
e
q
Speaker Config.
w
q
r Press ENTER.
t Press RETURN.
Speaker Setup
w
q
q The number of the current selected setting menu is displayed.
w Use ui to move to the item you want to set.
e • – is displayed at the sides of item whose setting can be changed. Use o p to change to the desired setting.
r Press ENTER to set to the mode in which the setting can be made.
t Press RETURN to return to the previous menu.
Display when resetting
Default? :• No
q
w
q
Default
Press ENTER.
q The number of the current selected setting menu is displayed.
w Press
i to select “Default”, then press ENTER to set.
1.AVR391E3ENG4th100602.inddSec:301.AVR391E3ENG4th100602.inddSec:30 2010/06/0414:29:272010/06/0414:29:27

Denon AVR-391 Specifications

General

Number of Channels	5.1
HDMI Inputs	4
HDMI Outputs	1
Dolby Formats	Dolby Digital, Dolby Pro Logic II
Audio Return Channel	Yes
Component Video Inputs	2
Digital Optical Inputs	1
Digital Coaxial Inputs	1
Response Bandwidth	10 Hz - 100 kHz
Signal-To-Noise Ratio	98 dB
THD	0.08%
Input Impedance	47 kOhms
Input Sensitivity	200 mV
Tuner Bands	AM/FM
Power Output	75 Watts per channel
DTS Formats	DTS
Tuner Frequency Range	FM: 87.5 - 108 MHz
Video Inputs/Outputs	Composite
Audio Inputs/Outputs	Digital Optical
Dimensions	434 x 151 x 319 mm
Weight	8.5 kg
