Denon AVR-4310 User Manual


Getting Started Connections Playback Remote ControlMulti-zone Information Troubleshooting Specifications
ENGLISH
Setting items Setting contents
HDMI
HDMI
Set this to change the HDMI
input terminals assigned to
the input sources.
The
DVD HDP TV SAT/CBL VCR DVR V.AUX
input sources
are assigned to the HDMI input terminals as shown below.
HDMI 1 / HDMI 2 / HDMI 3 / HDMI 4 / HDMI 5 / HDMI 6
None : Do not assign an HDMI input terminal to the selected input
source.
Upon purchase, the settings of the different input sources are as shown
below.
Input
source
DVD HDP TV
SAT/
CBL
VCR DVR V.AUX
Default
setting
HDMI
1
HDMI
2
None
HDMI
3
HDMI
4
HDMI
5
HDMI
6
An input source to which an HDMI input terminal cannot be assigned is
displayed as “– – –”.
To play the video signal assigned at “HDMI” combined with the audio
signal assigned at “Input Assign“ – “Digital”, select “Digital” at “Input
Mode” (vpage 49).
When the AVR-4310 and monitor are connected with an HDMI cable, if
the monitor is not compatible with HDMI audio signal playback, only the
video signals are output to the monitor.
The audio signals input from the analog, digital and EXT. IN connectors
are not output to the monitor.
When control dock for iPod is used as the input source, assignment of
the HDMI input terminal is disabled, even if it is assigned.
When “HDMI Control” – “Control” (vpage 37) is set to “ON”, HDMI
input terminal cannot be assigned to “TV”.
b
•
•
•
•
•
•
Digital
DIGITAL
Set this to change the digital
input terminals assigned to
the input sources.
The
CD DVD HDP TV SAT/CBL VCR DVR V.AUX
input
sources are assigned to the digital input terminals as shown below.
COAX 1 (COAXIAL) / COAX 2 / COAX 3 / OPT 1 (OPTICAL) / OPT 2 / OPT
3 / D.LINK (DENON LINK)
z
z : “D.LINK” is set when the AVR-4310 is connected by DENON LINK
to a DENON Blu-ray disc / DVD player (vpage 19 “Components
Equipped with a DENON LINK Connector”).
None : Do not assign a digital input terminal to the selected input source.
See overleaf
Main remote control
operation buttons
:Displaying the menu
Cancel the menu
:Moves the cursor
(Up/Down/Left/Right)
:Confirm the setting :Return to previous menu
Making the Input Settings (Source Select)
Setting items Setting contents
Digital
DIGITAL
(Continued)
Upon purchase, the settings of the different input sources are as shown
below.
Input
source
CD DVD HDP TV SAT/CBL
Default
setting
COAX 3 COAX 1 None OPT 1
COAX
2
Input
source
VCR DVR V.AUX
Default
setting
None OPT 2 OPT 3
When control dock for iPod is used as the input source, assignment of
the digital input terminal is disabled, even if it is assigned.
b
Component
COMP
Set this to change the
component video input
terminals assigned to the
input sources.
The
DVD HDP TV SAT/CBL VCR DVR V.AUX
input sources
are assigned to the component video input terminals as shown below.
1-RCA (Component video 1) / 2-RCA (Component video 2) / 3-RCA
(Component video 3)
None : Do not assign a component video input terminal to the selected
input source.
Upon purchase, the settings of the different input sources are as shown
below.
Input
source
DVD HDP TV
SAT/
CBL
VCR DVR V.AUX
Default
setting
1-RCA 2-RCA None None None 3-RCA None
An input source to which a component video input terminal cannot be
assigned is displayed as “– – –”.
When control dock for iPod is used as the input source, assignment of
the component video input terminal is disabled, even if it is assigned.
b
•
•
Settings

Denon AVR-4310 Specifications

General

Equalizer	Yes
Product color	Black
Impedance	8 Ω
Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Total Harmonic Distortion (THD)	0.05 %
S-Video inputs quantity	7
Component video (YPbPr/YCbCr) in	3
Dimensions (WxDxH)	434 x 414 x 171 mm
HDMI ports quantity	6
Headphone outputs	1
Headphone connectivity	3.5 mm
S-Video outputs quantity	2
Power consumption (standby)	1 W
Power consumption (typical)	780 W

Weight and Dimensions

Weight	15800 g
