121
Audio Check PASS
Refer to troubleshooting "4.1. AUDIO CHECK"(110 page).
CHECK1
CHECK3
CHECK2
CHECK4
CHECK5
CHECK6
ADV7850
TMDS
BUFFER
ARC(SPDIF)
5M570ZF256C5N
SPDIF/I2S SELECTOR
R2A15220FP
LC89057W-VF4A-E
PCM1795SDBR
×7
DIGITAL AUDIO
DSP BLOCK
×3
INTERFACE RECEIVER
FRONT
REAR
SPDIF
ADV8003
HDMI
TRANSMITTER
with scaler
video encoder
OSD etc...
Sil9575
Sil1292
LAN8720A
/DSD
/DSD
×2
×2
×6
×2
×4
