16
(2) Disconnect the connector wires.
Please refer to "EXPLODED VIEW" for the disassembly method of each PWB included in RADIATOR(L) SUB ASSY.
N9002
N9003
N102
N202
N302
N402
N502
N9004
Shooting direction: B
Shooting direction: B
Direction of photograph: D
Shooting direction: A
