Denon AVR-4520CI

235
ADV8003
Pin No. Mnemonic Type Description
AB8 DDR_DQ[29] DDR interface Data Line. Interface to external RAM data lines.
AB9 DDR_A[12] DDR interface Address Line. Interface to external RAM address lines.
AB10 DDR_A[6] DDR interface Address Line. Interface to external RAM address lines.
AB11 DDR_A[3] DDR interface Address Line. Interface to external RAM address lines.
AB12 DDR_A[0] DDR interface Address Line. Interface to external RAM address lines.
AB13 DDR_BA[0] DDR interface Bank Address Line. Indicates which data bank to write/read from.
AB14
DDR_RAS
DDR interface Row Address Strobe for DDR Memory.
AB15 DDR_CKE DDR interface Clock Enable for External DDR Memory.
AB16 DDR_DQ[12] DDR interface Data Line. Interface to external RAM data lines.
AB17 DDR_DQS[1] DDR interface Data Strobe for DDR Data Bytes[15:8].
AB18 DDR_DQ[8] DDR interface Data Line. Interface to external RAM data lines.
AB19 DDR_DQ[13] DDR interface Data Line. Interface to external RAM data lines.
AB20 DDR_DQ[0] DDR interface Data Line. Interface to external RAM data lines.
AB21 DDR_DQ[5] DDR interface Data Line. Interface to external RAM data lines.
AB22 DDR_DQS[0] DDR interface Data Strobe for DDR Data Bytes[7:0].
AB23 DDR_DQ[4] DDR interface Data Line. Interface to external RAM data lines.
AC1 DDR_DQ[16] DDR interface Data Line. Interface to external RAM data lines.
AC2 DDR_DQ[20] DDR interface Data Line. Interface to external RAM data lines.
AC3 DDR_DQ[22] DDR interface Data Line. Interface to external RAM data lines.
AC4 DDR_DQ[25] DDR interface Data Line. Interface to external RAM data lines.
AC5 DDR_DQ[28] DDR interface Data Line. Interface to external RAM data lines.
AC6 DDR_DQ[27] DDR interface Data Line. Interface to external RAM data lines.
AC7 DDR_DQ[24] DDR interface Data Line. Interface to external RAM data lines.
AC8 DDR_A[9] DDR interface Address Line. Interface to external RAM address lines.
AC9 DDR_A[5] DDR interface Address Line. Interface to external RAM address lines.
AC10 DDR_A[7] DDR interface Address Line. Interface to external RAM address lines.
AC11 DDR_A[1] DDR interface Address Line. Interface to external RAM address lines.
AC12 DDR_A[10] DDR interface Address Line. Interface to external RAM address lines.
AC13 DDR_BA[1] DDR interface Bank Address Line. Indicates which data bank to write/read from.
AC14 DDR_BA[2] DDR interface Bank Address Line. Indicates which data bank to write/read from.
AC15
DDR_WE
DDR interface Write Enable Signal for DDR RAM.
AC16 DDR_VREF DDR interface
1
Reference Voltage for DDR RAM.
AC17 DDR_DQ[10] DDR interface Data Line. Interface to external RAM data lines.
AC18
DDR_DQS[1]
DDR interface Data Strobe for DDR Data Byte[15:8].
AC19 DDR_DQ[15] DDR interface Data Line. Interface to external RAM data lines.
AC20 DDR_DQ[7] DDR interface Data Line. Interface to external RAM data lines.
AC21 DDR_DQ[2] DDR interface Data Line. Interface to external RAM data lines.
AC22
DDR_DQS[0]
DDR interface Data Strobe for DDR Data Byte[7:0].
AC23 DDR_DQ[1] DDR interface Data Line. Interface to external RAM data lines.
1
Sensitive node. Careful layout is important. The associated circuitry should be kept as close as possible to the ADV8003.
