1.4. Version display on the Setup Menu

Use the following procedure to display the rmware version.

(1) Press the "SETUP" button on the remote control.

(2) Select "General-Information-Firmware".

A version with 12 digits is displayed as shown in the following image.

AVR-4520 GUI Image

The displayed 12 digits are derived from each device version as shown below

This rmware version No. (xxxx-xxxx-xxxx) is included in the service contact document.

These 12 digits are also included in the document.

0215-7241-1281

Main μcom 0 0 2 7

Info display

0 2 1 5 - 7 2 4 1 - 1 2 8 1

Sub μcom 6 2 1 2 0 0 1 4

A.PLD 2 0 1 0

DSP1 7 8 0 2

DSP2 7 9 0 1

DSP3 8 0 0 5

GUI 6 2 1 2 0 0 2 1

DM860A FBL 0 9 0 3 1 1

DM860A SBL B 2 0 1 2 0 5 0 9 0 6 4 7

DM860A IMG I 2 0 1 2 0 6 2 8 0 2 1 8

The 1st digit from the right for Main μcom

The 1st digit from the right for Sub μcom

The 1st digit from the right for GUI

The 1st digit from the right for DSP3

The 1st digit from the right for

DSP2

The 1st digit from the right for A.PLD

The 1st digit from the right for DSP1

The 2nd digit from the right for Sub μcom

The 2nd digit from the right for Main μcom

The 2nd digit from the right for GUI

The 2nd digit from the right for IMG

The 1st digit from the right for IMG
