Denon AVR-4802 Service Manual

56
AVR-4802/AVC-A11SR
Ref. No. Part No. Part Name Remarks
Ref. No. Part No. Part Name Remarks Q'ty
C228 255 1264 908 Mylar film 1000pF/50V CQ93M1H102JT(B)
C230 255 4235 976 Mylar film 0.015
µ F/100V CQ93P2A153JT(NH)
C232 255 4235 976 Mylar film 0.015
µ F/100V CQ93P2A153JT(NH)
C234 255 4232 937 Mylar film 1000pF/100V CQ93P2A102JT(NH)
C301,302 254 4557 936 Electrolytic 22
µ F/50V CE04W1H220MT(RFS)
C303,304 254 5573 949 Electrolytic 10 µ F/50V CE04W1H100MT(RFS)
C305,306 255 1273 944 Mylar film 220pF/50V CQ93M1H221KT(B)
C307,308 255 1273 902 Mylar film 100pF/50V CQ93M1H101KT(B)
C309,310 255 1264 940 Mylar film 2200pF/50V CQ93M1H222JT(B)
C311,312 254 4382 910 Electrolytic 220
µ F/16V CE04W1C221MT(ASF)
C313,314 255 4242 943 Mylar film 33pF/100V CQ93P2A330JT(NH)
C315,316 255 4235 918 Mylar film 100pF/100V CQ93P2A101JT(NH)
C317,318 253 4465 902 Ceramic chip 5pF/500V CC45SL2H050CT
C319,320 255 4235 918 Mylar film 100pF/100V CQ93P2A101JT(NH)
C321,322 254 4557 910 Electrolytic 2.2
µ F/50V CE04W1H2R2MT(RFS)
C323-326 254 4481 918 Electrolytic 10 µ F/100V CE04W2A100MT(ASF)
C327,328 255 1264 908 Mylar film 1000pF/50V CQ93M1H102JT(B)
C329-332 255 4235 976 Mylar film 0.015
µ F/100V CQ93P2A153JT(NH)
C333,334 255 4232 937 Mylar film 1000pF/100V CQ93P2A102JT(NH)
C401,402 254 4557 936 Electrolytic 22
µ F/50V CE04W1H220MT(RFS)
C403,404 254 5573 949 Electrolytic 10 µ F/50V CE04W1H100MT(RFS)
C405,406 255 1273 944 Mylar film 220pF/50V CQ93M1H221KT(B)
C407,408 255 1273 902 Mylar film 100pF/50V CQ93M1H101KT(B)
C409,410 255 1264 940 Mylar film 2200pF/50V CQ93M1H222JT(B)
C411,412 254 4382 910 Electrolytic 220
µ F/16V CE04W1C221MT(ASF)
C413,414 255 4242 943 Mylar film 33pF/100V CQ93P2A330JT(NH)
C415,416 255 4235 918 Mylar film 100pF/100V CQ93P2A101JT(NH)
C417,418 253 4465 902 Ceramic chip 5pF/500V CC45SL2H050CT
C419,420 255 4235 918 Mylar film 100pF/100V CQ93P2A101JT(NH)
C421,422 254 4557 910 Electrolytic 2.2
µ F/50V CE04W1H2R2MT(RFS)
C423-426 254 4481 918 Electrolytic 10 µ F/100V CE04W2A100MT(ASF)
C427,428 255 1264 908 Mylar film 1000pF/50V CQ93M1H102JT(B)
C429-432 255 4235 976 Mylar film 0.015
µ F/100V CQ93P2A153JT(NH)
C433,434 255 4232 937 Mylar film 1000pF/100V CQ93P2A102JT(NH)
C503,504 255 1265 936 Mylar film 0.01
µ F/50V CQ93M1H103JT(B)
C505-508 254 4313 963 Electrolytic 1
µ F/50V CE04W1H010MT(ASF)
C509,510 254 4528 716 Electrolytic 47 µ F/100V CE04W2A470MC SMG/RE3
OTHER PARTS GROUP
AS101-104 415 0309 026 P.V.C. tube (L=20) 4
AS105-110 009 0185 113 Bus bar(4P) 6
CW76,77 204 2513 087 7P KR-DA connector cord 2
CW941,942 203 6365 018 4P KR-DA connector cord 2
CY35,36 203 5265 009 3P SDN-SDN connector cord 2
CY92 205 0343 090 9P connector base (KR-PH) 1
CY114 205 0375 013 11P connector base (KR-PH) 1
CY921,922 203 2407 006 2P SDN-SDN connector cord 2
CY924 203 2407 019 2P SDN-SDN connector cord 1
CY925,926 203 2407 022 2P SDN-SDN connector cord 2
L101,102 235 0068 004 Inductor 1
µ H2
L202 235 0068 004 Inductor 1
µ H1
L301,302 235 0068 004 Inductor 1
µ H2
L401,402 235 0068 004 Inductor 1
µ H2
RL101,102 214 0209 002 Relay FTR-F1AD024V 2
RL202 214 0209 002 Relay FTR-F1AD024V 1
RL301,302 214 0209 002 Relay FTR-F1AD024V 2
RL351,352 214 0209 002 Relay FTR-F1AD024V 2
RL401,402 214 0209 002 Relay FTR-F1AD024V 2
TP101,102 205 0154 030 3P NH connector base 2
TP111-114 205 1192 062 6P pin header (TIX-H1) 4
TP202 205 0154 030 3P NH connector base 1
TP212 205 1192 062 6P pin header (TIX-H1) 1
TP214 205 1192 062 6P pin header (TIX-H1) 1
TP301,302 205 0154 030 3P NH connector base 2
TP311-314 205 1192 062 6P pin header (TIX-H1) 4
TP401,402 205 0154 030 3P NH connector base 2
TP411-414 205 1192 062 6P pin header (TIX-H1) 4
W501,502 203 5264 000 3C wire Ass’y 2
449 0080 089 Edging 2

Denon AVR-4802 Specifications

General

Impedance	8 ohms
Frequency Response	10 Hz - 100 kHz (+1, -3 dB)
THD	0.05%
Signal-to-Noise Ratio	100 dB
Surround Sound	Dolby Digital, DTS, Dolby Pro Logic II
Component Video Inputs	3
Digital Inputs	5 (3 Optical, 2 Coaxial)
Type	AV Receiver
Channels	7.1
Input Impedance	47 kOhms
Input Sensitivity	200 mV
Inputs	5 Digital (3 Optical, 2 Coaxial)
Outputs	composite video, component video, optical digital
Audio D/A Converter	24-bit/192kHz
