Removetheconnector,thenremovetheHDMIUNITASSYfromthemainunit.
(5) Disconnecttheconnectorboard.
(6) Disconnecttheconnectorboard.
Direction of photograph: D
CP12
PCB HDMI
Board to board
Board to board
Board to board
PCB AUDIO VIDEO
PCB FRONT CNTPCB SIDE CNT
Board to board
Board to board
