Denon AVR-591 Service Manual

16
SPECIAL MODE
Special mode setting button
b
Press the ON/STANDBY button to turn on while pressing both buttons A and B at the same time.
Mode Button A Button B Contents
µcom/DSP Version display mode STATUS DIMMER
Firmware versions such as Main, Sub, DSP are displayed in
the FL manager. Errors are displayed when they occur. (Refer
to 17 page.)
Errors checking mode
(Displaying the protection history)
STATUS MULT EQ
Displaying the protection history
(Refer to 18 page.)
Initialization mode
SURROUND
MODE
0
SURROUND
MODE
1
Backup data initialization is carried out.
(Refer to 5 page.)
Mode for switching tuner frequency step DINAMIC EQ
DINAMIC
VOLUME
---E2 model only---
Select with the SOURCE
0 d 1 f
button.
Change tuner frequency step to AM9k/FM50kHz STEP or
AM:10k/FM:200kHz.
Mode for preventing remote control
acceptance
DINAMIC
VOLUME
RETURN
Operations using remote control are rejected.
(Mode cancellation: Turn off power and execute the same
button operations as when performing setup.)
Panel lock mode DINAMIC EQ ENTER
Operations using main unit panel buttons or master volume are
rejected.
Panel lock mode
(Remove Master volume)
DINAMIC EQ CURSOR
1
Operations using main unit panel buttons are rejected.
Cancellation of panel lock mode DINAMIC EQ RETURN Panel lock mode is cancelled.
ON/STANDBY
CURSOR 1 SURROUND MODE 0 1
ENTER
DINAMIC EQ MULT EQ
DINAMIC VOLUME DIMMER
STATUS
RETURN

Denon AVR-591 Specifications

General

Channels	5.1
Power Output	75 W per channel (8 ohms, 20 Hz - 20 kHz, 0.08% THD)
Frequency Response	10 Hz - 100 kHz (+1, -3 dB)
Input Sensitivity/Impedance	200 mV / 47 kohms
Signal-to-Noise Ratio	98 dB
HDMI Inputs	4
HDMI Outputs	1
Audyssey	Audyssey MultEQ
HDMI Pass-Through	Yes
Tuner Bands	AM/FM
Preset Station Qty	56
Total Harmonic Distortion	0.08%
Tuner Frequency Range	FM: 87.5 - 107.9 MHz, AM: 520 - 1710 kHz
Dolby Support	Dolby Digital, Dolby Digital Plus
DTS Support	DTS-HD Master Audio
Dimensions	434 x 167 x 382 mm
Weight	21.6 lbs (9.8 kg)
