Denon AVR-591 Service Manual

CLOCK FLOW & WAVE FORM IN DIGITAL BLOCK
U1707
AUDIO PLD
EPM3032ATC
U1901
DSP
ADSP-21367
U1001
HDMI Rx
ADV7840
DIR/DIT
U1706
LC89058W-E
ADC
U2101
AAK5358B
DAC
U2102
AK4358VQ
MCLK(11)
SCLK(12)
LRCLK(10)
ADATA(9)
SDTI1(14)
SDTI2(15)
SDTI3(16)
SDTI4(13)
BICK(9)
LRCK(17)
DSDDATA4(11)
DSDDATA3(14)
DSDDATA2(15)
DSDDATA1(16)
DBCLK(17)
DLRCK(18)
MCLK(10)
SDIN(24)
SLRCK(23)
RMCK(16)
RBCK(17)
RLRCK(20)
RDATA(21)
SBCK(22)
TMCK(44)
TBCK(45)
TLRCK(46)
TDATA(47)
(42)SLRCK
(37)256fsDIR
(3)64fsDIR
(2)fsDIR
(44)DATADIR1
(43)SBCK
(21)DSPIN64fs (22)DSPINfs (28)DSPINSB (31)DSPINS (33)DSPINC (34)DSPINF (23)DSPOUTfs (25)DSPOUT64fs
(F3)HRMCK (B1)HR64fs/DCLK (A2)HRfs/DR0 (K3)HRSD0/DL0 (D5)HRSD1/DR1 (J3)HRSD2/DL1 (J4)HRSD3/DR2 (B2)HRSPDIF/DL2
HRMCK(5)
HR64fs/DCLK(6)
HRfs/DR0(8)
HRSD0/DL0(14)
HRSD1/DR1(13)
HRSD2/DL1(12)
HRSD3/DR2(10)
(2)RX0
(4)RX2
(9)RX5
COAXIAL-1
OPTICAL-1
(130) (125) (143) (137) (146) (144) (132) (131)
DAC_FL/FR(133)
DAC_C/SW(134)
DAC_SL/SR(135)
DAC_SBL/SBR(136)
INPUT
q
w
e
CH1: D-DATA
1
CH1: DATA
CH2: fs
CH3: 64fs
CH4: 256fs
3
CH1: DATA
CH2: fs
CH3: 64fs
2
Wave form
47

Denon AVR-591 Specifications

General

Channels	5.1
Power Output	75 W per channel (8 ohms, 20 Hz - 20 kHz, 0.08% THD)
Frequency Response	10 Hz - 100 kHz (+1, -3 dB)
Input Sensitivity/Impedance	200 mV / 47 kohms
Signal-to-Noise Ratio	98 dB
HDMI Inputs	4
HDMI Outputs	1
Audyssey	Audyssey MultEQ
HDMI Pass-Through	Yes
Tuner Bands	AM/FM
Preset Station Qty	56
Total Harmonic Distortion	0.08%
Tuner Frequency Range	FM: 87.5 - 107.9 MHz, AM: 520 - 1710 kHz
Dolby Support	Dolby Digital, Dolby Digital Plus
DTS Support	DTS-HD Master Audio
Dimensions	434 x 167 x 382 mm
Weight	21.6 lbs (9.8 kg)
