Denon AVR-591 Service Manual

120
PARTS LIST OF P.C.B. UNIT
zParts for which "nsp" is indicated on this table cannot be supplied.
zThe parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions.
PCB 5CH_AMP ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
Q401 00D2710314903 TR 2SA KTA1024Y J5001024Y0050S
Q403 00D2710318909 TR 2SA 2N5401S J520254010010S
Q405 00D2710318909 TR 2SA 2N5401S J520254010010S
Q406 00D2730479909 TR 2SC 2N5551S J522255510010S
Q407,408 00D9600196302 TR KTA1268BL J5001268B0050S
Q412 00D2730471907 TR 2SC KTC3206Y J5023206Y0050S
Q413 00D2710314903 TR 2SA KTA1024Y J5001024Y0050S
Q415 00D2710318909 TR 2SA 2N5401S J520254010010S
Q417 00D9600196302 TR KTA1268BL J5001268B0050S
Q418 00D2730479909 TR 2SC 2N5551S J522255510010S
Q419,420 00D9600196302 TR KTA1268BL J5001268B0050S
Q424 00D2730471907 TR 2SC KTC3206Y J5023206Y0050S
Q425 00D2710314903 TR 2SA KTA1024Y J5001024Y0050S
Q427 00D2710318909 TR 2SA 2N5401S J520254010010S
Q430 00D2730479909 TR 2SC 2N5551S J522255510010S
Q431,432 00D9600196302 TR KTA1268BL J5001268B0050S
Q436 00D2730471907 TR 2SC KTC3206Y J5023206Y0050S
Q437 00D2710314903 TR 2SA KTA1024Y J5001024Y0050S
Q439 00D2710318909 TR 2SA 2N5401S J520254010010S
Q442 00D2730479909 TR 2SC 2N5551S J522255510010S
Q443,444 00D9600196302 TR KTA1268BL J5001268B0050S
Q448 00D2730471907 TR 2SC KTC3206Y J5023206Y0050S
Q449 00D2710314903 TR 2SA KTA1024Y J5001024Y0050S
Q451 00D2710318909 TR 2SA 2N5401S J520254010010S
Q454 00D2730479909 TR 2SC 2N5551S J522255510010S
Q455,456 00D9600196302 TR KTA1268BL J5001268B0050S
Q460 00D2730471907 TR 2SC KTC3206Y J5023206Y0050S
D402-404 00D2760401905 D,SWITCHING 1SS133T K000013300520S
D408-410 00D2760401905 D,SWITCHING 1SS133T K000013300520S
D414-416 00D2760401905 D,SWITCHING 1SS133T K000013300520S
D420-422 00D2760401905 D,SWITCHING 1SS133T K000013300520S
D426-428 00D2760401905 D,SWITCHING 1SS133T
K000013300520S
ZD401 00D2760643983 D,ZENER MTZJ5.1A K06005R134520S
ZD402,403 00D9630047502 D,ZENER MTZJ3.3B K06003R344520S
ZD404 00D2760643983 D,ZENER MTZJ5.1A K06005R134520S
ZD405,406 00D9630047502 D,ZENER MTZJ3.3B K06003R344520S
ZD407 00D2760643983 D,ZENER MTZJ5.1A K06005R134520S
ZD408,409 00D9630047502 D,ZENER MTZJ3.3B K06003R344520S
ZD410 00D2760643983 D,ZENER MTZJ5.1A K06005R134520S
ZD411,412 00D9630047502 D,ZENER MTZJ3.3B K06003R344520S
ZD413 00D2760643983 D,ZENER MTZJ5.1A K06005R134520S
ZD414,415 00D9630047502 D,ZENER MTZJ3.3B K06003R344520S

Denon AVR-591 Specifications

General

Channels	5.1
Power Output	75 W per channel (8 ohms, 20 Hz - 20 kHz, 0.08% THD)
Frequency Response	10 Hz - 100 kHz (+1, -3 dB)
Input Sensitivity/Impedance	200 mV / 47 kohms
Signal-to-Noise Ratio	98 dB
HDMI Inputs	4
HDMI Outputs	1
Audyssey	Audyssey MultEQ
HDMI Pass-Through	Yes
Tuner Bands	AM/FM
Preset Station Qty	56
Total Harmonic Distortion	0.08%
Tuner Frequency Range	FM: 87.5 - 107.9 MHz, AM: 520 - 1710 kHz
Dolby Support	Dolby Digital, Dolby Digital Plus
DTS Support	DTS-HD Master Audio
Dimensions	434 x 167 x 382 mm
Weight	21.6 lbs (9.8 kg)
