Denon AVR-591 Service Manual

123
Ref. No. Part No. Part Name Remarks Q'ty New
C471 00D9630234506 C,ELECT 47UF-M/50V (Pb Free) D040470087070S
C472 00D9630224503 C,ELECT 22UF-M/50V D040220087060S
C474 00D9609009937 C,ELECT 100UF-M/50V D040101087060S
C476 nsp C,CERAMIC 470PF-K/500V D00447127D050S
C477 nsp C,CERAMIC X7R2200PF-K/50V D011222777200S
C479,480 00D9630234302 C,ELECT 10UF-M/100V D04010008C050S
C513,514 00D9630338402 C,ELECT 330UF-M/6.3V D040331081050S
C515 00D9630324607 C,ELECT 47UF-M/10V (Pb Free) D040470082060S
OTHERS PARTS GROUP
BKT400 nsp BRACKET 0.8t/SCREW 4010210196100S
CLAMP400,401 nsp CLAMP WIRE(SOLDER) 4330000120000S
CN404 nsp CN.WIRE 5P L002251052620S *
CP401 nsp CN.WAFER 13P STRAIGHT L101200101310S
CP402 nsp CN.WAFER 5P L102526700500S
CP403 nsp CN.WAFER 10P STRAIGHT L101200101010S
TP401-405 nsp CN.WAFER 3P L101200100320S

Denon AVR-591 Specifications

General

Channels	5.1
Power Output	75 W per channel (8 ohms, 20 Hz - 20 kHz, 0.08% THD)
Frequency Response	10 Hz - 100 kHz (+1, -3 dB)
Input Sensitivity/Impedance	200 mV / 47 kohms
Signal-to-Noise Ratio	98 dB
HDMI Inputs	4
HDMI Outputs	1
Audyssey	Audyssey MultEQ
HDMI Pass-Through	Yes
Tuner Bands	AM/FM
Preset Station Qty	56
Total Harmonic Distortion	0.08%
Tuner Frequency Range	FM: 87.5 - 107.9 MHz, AM: 520 - 1710 kHz
Dolby Support	Dolby Digital, Dolby Digital Plus
DTS Support	DTS-HD Master Audio
Dimensions	434 x 167 x 382 mm
Weight	21.6 lbs (9.8 kg)
