Denon AVR-591 Service Manual

45
4.3. Analog audio
No sound is output
Is the voltage of ±8V supplied to
AV B'D CP8?
Is the audio signal transmitted to
AV B'D CN401?
Is the serial data for electronic volume
transmitted to AV B'D CP11?
Once more, checking the connection of the connector.
When can specify the trouble of the channel and function, Check signal route where it
corresponds.
The power supply of ±8V is repaired.
The power amplier is repaired.
Is the connector correctly connected
with HDMI B'D?
Connect the connectors properly.
The HDMI B'D is repaired.
YES
NO
YES
NO
NO
YES
YES
YES

Denon AVR-591 Specifications

General

Channels	5.1
Power Output	75 W per channel (8 ohms, 20 Hz - 20 kHz, 0.08% THD)
Frequency Response	10 Hz - 100 kHz (+1, -3 dB)
Input Sensitivity/Impedance	200 mV / 47 kohms
Signal-to-Noise Ratio	98 dB
HDMI Inputs	4
HDMI Outputs	1
Audyssey	Audyssey MultEQ
HDMI Pass-Through	Yes
Tuner Bands	AM/FM
Preset Station Qty	56
Total Harmonic Distortion	0.08%
Tuner Frequency Range	FM: 87.5 - 107.9 MHz, AM: 520 - 1710 kHz
Dolby Support	Dolby Digital, Dolby Digital Plus
DTS Support	DTS-HD Master Audio
Dimensions	434 x 167 x 382 mm
Weight	21.6 lbs (9.8 kg)
