9
(3) Cutthewireclampbands,thendisconnecttheconnectorwiresandFFCcable.
(4) Disconnecttheconnectorwires.
STYLE PIN : Loose
N2706
CP100
FFC cable
cut
RADIATOR ASSY
CP401 CP402
CP403
PCB 5CH AMP
Pleasereferto"EXPLODEDVIEW"forthedisassemblymethodofeachP.W.BincludedinRADIATORASSY.
