Rear panel
See the page indicated in parentheses ( ).
q
e r t
yi u
w
q FM/AM antenna terminals (ANTENNA) ································ (13)
w Analog audio connectors (AUDIO) ·································· (11, 12)
e Speaker terminals (SPEAKERS) ············································· (26)
r HDMI connectors ··································································· (6, 7)
t VIDEO connectors ······················································· (10, 11, 12)
y Power cord ··············································································· (14)
u PRE OUT connector ································································· (26)
i Digital audio connectors (DIGITAL AUDIO) ·············· (10, 11, 12)
NOTE
Do not touch the inner pins of the connectors on the rear panel.
Electrostatic discharge may cause permanent damage to the unit.
