Denon AVR-S700W User Manual

Setting items Detailed items Description Page
.
Inputs
Input Assign Changes input connector assignment. 153
Source Rename Changes the display name for input source. 155
Hide Sources Removes from the display input sources that are not used. 155
Source Level Adjusts the playback level of the audio input. 155
Input Select Sets the audio input mode and decode mode. 156
.
Speakers
Audyssey
®
Setup
The acoustic characteristics of the connected speakers and listening room are
measured and the optimum settings are made automatically.
157
Manual Setup
Sets up the speakers manually or changes the Audyssey
®
Setup settings.
167
.
Network
Information Displays network information. 174
Connection Selects whether to connect the home network to a wireless LAN or a wired LAN. 174
Settings Used for manually setting the IP address or when using a proxy server. 177
IP Control Enables network communication in standby power mode. 178
Friendly Name The “Friendly Name” is the name of this unit displayed on the network. You can change
the Friendly Name according to your preferences.
179
Diagnostics Used to check the network connection. 179
Contents Connections Playback Settings Tips Appendix
132
Front panel Display Rear panel Remote Index

Denon AVR-S700W Specifications

General

Channels	7.2
Power Output per Channel	75 W (8 ohms, 20 Hz - 20 kHz, 0.08% THD)
Frequency Response	10 Hz - 100 kHz
Total Harmonic Distortion	0.08%
Signal-To-Noise Ratio	98 dB
Input Impedance	47 kOhms
Input Sensitivity	200 mV
HDMI Inputs	6
HDMI Outputs	1
Composite Inputs	2
Component Inputs	2
Analog Inputs	4
Composite Output	1
Component Output	1
Wi-Fi	Yes
Bluetooth	Yes
AirPlay	Yes
DLNA	Yes
HDMI Pass-Through	Yes
HDMI Switching	Yes
3D Technology	Yes
Digital Inputs	2 Optical
Supported Audio Formats	DTS-HD Master Audio, Dolby TrueHD
Supported Video Formats	4K, 3D
Additional Features	Audyssey MultEQ
Tuner Presets	56
Dimensions	17.1 x 13.3 x 6.6 inches
