Denon AVR-S700W User Manual

Setting items Detailed items Description Page
.
General
Language Changes the language of the display on the TV screen. 180
ECO Configures the ECO Mode and Auto Standby energy-saving functions. 180
ZONE2 Setup Sets ZONE2 audio playback settings. 182
Zone Rename Changes the display title of each zone to one you prefer. 183
Quick Sel.Names Changes the Quick Select Name display title to one you prefer. 183
Front Display Makes settings related to the display on this unit. 183
Information Shows information about this unit settings, input signals, etc. 184
Usage Data Selects whether or not to send anonymous usage data to Denon. 185
Firmware Checks for the latest firmware information about updates and upgrades, updates the
firmware, and sets up the notification message display.
186
Setup Lock Protects settings from inadvertent changes. 188
.
Setup Assistant
Begin Setup... Performs basic installation/connections/settings from the beginning according to the
guidance indicated on the TV screen.
Page 8 of
the separate
manual
“Quick Start
Guide”
Language Select Sets individual setting items according to the guidance displayed on the TV screen.
Speaker Setup
Sp.Calibration
Network Setup
Input Setup
Contents Connections Playback Settings Tips Appendix
133
Front panel Display Rear panel Remote Index

Denon AVR-S700W Specifications

General

Channels	7.2
Power Output per Channel	75 W (8 ohms, 20 Hz - 20 kHz, 0.08% THD)
Frequency Response	10 Hz - 100 kHz
Total Harmonic Distortion	0.08%
Signal-To-Noise Ratio	98 dB
Input Impedance	47 kOhms
Input Sensitivity	200 mV
HDMI Inputs	6
HDMI Outputs	1
Composite Inputs	2
Component Inputs	2
Analog Inputs	4
Composite Output	1
Component Output	1
Wi-Fi	Yes
Bluetooth	Yes
AirPlay	Yes
DLNA	Yes
HDMI Pass-Through	Yes
HDMI Switching	Yes
3D Technology	Yes
Digital Inputs	2 Optical
Supported Audio Formats	DTS-HD Master Audio, Dolby TrueHD
Supported Video Formats	4K, 3D
Additional Features	Audyssey MultEQ
Tuner Presets	56
Dimensions	17.1 x 13.3 x 6.6 inches
