Denon AVR-X1200W Service Manual

Pin Pin Name Symbol I/O Pu/Pd
Lv
Cnv
STBY STOP
CEC
STBY
Function
29
P30/IRQ0-A/PO8/
TIOCA0
RC IN I I I I
remote input
30
P27/PO7/TIOCA5/
TIOCB5/SCK1
Hi-B RL O L L L
HIGH B RELAY control pin
31
P26/PO6/TIOCA5/
TMO1/TxD1
PSCL I/O C
CEC3VPu
O/L L L
HDMI (MN864788/788A) control pin
32
P25/PO5/TIOCA4/
TMCI1/RxD1
PSDA I/O C
CEC3VPu
O/L L L
HDMI (MN864788/788A) control pin
33
P24/PO4/TIOCA4/
TIOCB4/TMRI1
TU RST O SW3VPu L L L
TUNER control
34
P23/PO3/TIOCC3/
TIOCD3
E RESET
O(ODR)
N3VPu L L L
ETHERNET(CY920) RESET control pin
35
P22/PO2/TIOCC3/
TMO0/SCK0
E SPI CLK O N3VPu L L L
ETHERNET(CY920) control pin
36
P21/PO1/TIOCA3/
TMCI0/RxD0
E SPI MIEO I N3VPu I L I
ETHERNET(CY920) control pin
37
P20/PO0/TIOCA3/
TIOCB3/TMRI0/TxD0
E SPI MOEI O N3VPu L L L
ETHERNET(CY920) control pin
38
P17/IRQ7-B/
TCLKD-B/TxD3/
SCL0/ADTRG1#
TU SCLK O L L L
TUNER control pin
39 PLLVCC PLLVCC - - - -
Power supply pin for the PLL circuit
40
P16/IRQ6-B/
TCLKC-B/RxD3/
SDA0
TU SDIO I_O L L L
TUNER control pin
41 PLLVSS PLLVSS -
- - -
Ground pin for the PLL circuit
42
P15/IRQ5-B/
TCLKB-B/SCK3/
SCL1
EEPROM SCL O M3VPu I I I
EEPROM control pin
43
P14/IRQ4-B/
TCLKA-B/SDA1
EEPROM SDA I_O M3VPu I I I
EEPROM control pin
44
P13/IRQ3-B/TxD2/
ADTRG0#
ADV7623 SPI
MO
O L L L
HDMI transceiver w/ GUI(ADV7623) control pin
45 P12/IRQ2-B/RxD2
ADV7623 SPI
MI
I L L L
HDMI transceiver w/ GUI(ADV7623) control pin
46 P11/IRQ1-B/SCK2
ADV7623 SPI
CLK
O L L L
HDMI transceiver w/ GUI(ADV7623) control pin
47 P10/IRQ0-B
ADV7623 SPI
CS
O L L L
HDMI transceiver w/ GUI(ADV7623) control pin
48
P37/PO15/TIOCA2/
TIOCB2/TCLKD-A
HSCL (400k) O CEC3VPu L L L
HDMI transceiver w/ GUI(ADV7623) control pin
49 P36/PO14/TIOCA2 HSDA (400k) I_O CEC3VPu L L L
HDMI transceiver w/ GUI(ADV7623) control pin
50
P35/PO13/TIOCA1/
TIOCB1/TCLKC-A
MN864788 RST O SW3VPu L L L
HDMI Tx (MN864788) Reset control pin
51 P84 CEC_OUT O L L -
CEC-D control pin
52
P57/WAIT#/
TRDATA3
MN864788A
RST
O SW3VPu L L L
HDMI Rx (MN864788A) Reset control pin
53 P56/TRDATA2 E POWER1 O L L L
ETHERNET (CY920) power supply control
54 P55/TRDATA1 ADV7623 RST O SW3VPu L L L
HDMI transceiver w/ GUI(ADV7623) reset control
pin
55 P54/TRDATA0 E POWER2 O L L
L
ETHERNET (CY920) power supply control
56 P83 E POWER3 O L L L
ETHERNET (CY920) power supply control
57 VSS VSS - - - -
Ground pin.
58 P82/TRCLK FL CE O L L L
Fluorescent display control pin
59 VCC VCC - - - -
Power supply pin.
60 P81/TRSYNC FL RST O L L L
Fluorescent display control pin
61 P80 E POWER4 O L L L
ETHERNET (CY920) power supply control
62 BCLK/P53(for Input) DSP BSY I I I I
DSP BSY signal input
63 P52/RD#
MN864788A
HINT
I Pu I I I
HDMI Rx (MN864788A) interrupt signal det
64 P51/WR1#/BC1# PWR_UNBAL I I L I
Poweramp unbalance det
65 P50/WR0#/WR# HIN SELC I I L I
HDMI +5V (TC4051) control pin
66 P77 H5V DET I I I I
HDMI IN 5V detect signal pin
67 P76/IRQ14-A TU GPO2_INT I L L L
TUNER control pin
68 P75 DONGLE DET I I L I
For debug
69
PC7/A23/CS4#-D/
CS7#-D/TxD5
DSP MOSI O DA3VPu L L L
DSP(CS49844A) control pin
130

Denon AVR-X1200W Specifications

General

HDMI in	6
AC (power) in	Yes
Composite video in	2
USB ports quantity	1
Digital audio coaxial in	0
Receiver type	-
Audio output channels	7.2 channels
Total Harmonic Distortion (THD)	1 %
Power output per channel (20-20KHz@8 Ohm)	145 W
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Internet radio services supported	Spotify
Product color	Black
Audio decoders	DTS-HD Master Audio
Apple docking compatibility	iPhone, iPod
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	430 W
Connectivity technology	Wired
Optical drive included	No
Audio formats supported	AIFF, ALAC, FLAC

Weight and Dimensions

Depth	339 mm
Width	434 mm
Height	151 mm
Weight	8500 g
