FRONT
REF No. Part No. Part Name Remarks Q'ty New Ver
C1053-1055 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 3
C1065 nsp CAP, ELECT(50V/1uF) CCEA1HH1R0T 1
C1066 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C1067 nsp CAP, ELECT(50V/1uF) CCEA1HH1R0T 1
C1068 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C1071,1072 nsp CAP, CHIP(1608, 50V/680pF, C0G)_SAMSUNG CCUS1H681JAS 2
C1073 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C1076,1077 nsp CAP, CHIP(1608, 50V/0.01uF, X7R)_SAMSUNG CCUS1H103KCS 2
C1081 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C1401 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C1402 nsp CAP, ELECT(50V/1uF)-S CCEA1HKS1R0T 1
C1403 nsp CAP, CHIP(1608, 50V/100pF, C0G)_SAMSUNG CCUS1H101JAS 1
C1405 nsp CAP, ELECT(50V/10uF)-S CCEA1HKS100T 1
C1406 nsp CAP, CHIP(1608, 50V/0.047uF, X7R)_SAMSUNG CCUS1H473KCS 1
C1407 nsp CAP, ELECT(16V/100uF)-S CCEA1CKS101T 1
C1408 nsp CAP, CHIP(1608, 50V/82pF, C0G)_SAMSUNG CCUS1H820JAS 1
C1410,1411 nsp CAP, ELECT(50V/1uF)-S CCEA1HKS1R0T 2
C1414 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C1415 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CCUS1H102KCS 1
C1417 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C1424 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C1425,1426 nsp CAP, CHIP(1608, 50V/0.01uF, X7R)_SAMSUNG CCUS1H103KCS 2
OTHER PARTS GROUP
BK101,102 nsp BRACKET , FIP CMD1A572-V1 2
BN101 nsp WIRE ASS'Y B'D-B'D IN (9P,2MM,80MM,#28) CWB1A009080CC 1
BN104 nsp WIRE ASS'Y Locking (YH,5P,2.0MM,330MM,#24)
CWB1C205330HC001
1*
BN12A nsp WIRE ASS'Y B'D to B'D(CKM) (5P,2MM,80MM,#26) CWB1B005080CC 1
BN12B1 nsp WAFER,FFC 1.25mm,ANGLE CJP27GB286ZN 1
BN131 nsp WIRE ASS'Y Locking (YH) (3P,2MM,50MM,#28) CWB1A003050HC 1
CN102 nsp WAFER/ANGLE/2.5mm/07P CJP07GB03ZY 1
CN103 nsp LOCK-WAFER/ANGLE/2MM PITCH/3PIN CJP03GJ288ZY 1
CN104 nsp LOCK-WAFER/STRAIGHT/2MM PITCH/3PIN CJP03GI288ZY 1
! F1001 943652500600S FUSE(932Series, 250V/200mA) E3, S710 CBA2J0200TLUBT 1
! F1001 943652500550D FUSE(372 Series/200mA/TR5) E2, E1C, JP CBA2D0200A3EYT 1
FL101 943172100150S V.F.D (FUTABA, 18-BT-02GINK) CFL18BT021GINK 1
IC101 00D2631289900 I.C , OPAMP(DUAL/LOW NOISE) CVIAZ4580MTR-E1 1
J1056,1057 nsp WIRE, COPPER(D0.6) S710 C3A206 2
J1059 nsp WIRE, COPPER(D0.6) S710 C3A206 1
J1061 nsp WIRE, COPPER(D0.6) S710 C3A206 1
J1064 nsp WIRE, COPPER(D0.6) S710 C3A206 1
JK101 943643101590S JACK, USB STRAIGHT(BLACK 1.5A) CJJ9X010Z 1
JK104 90M-YT004500R JACK, PHONES(6.35mm,SILVER) CJJ2E026Z 1
JK105 943643102930S JACK, STEREO, 3.5mm MINI, BLACK MOLD CJJ2D029Z 1
L1001 nsp FERRITE CHIP BEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1003 nsp FERRITE CHIP BEAD(4516/60R) CLZ9Z014V 1
L1004,1005 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 2
L1010-1013 nsp FERRITE CHIP BEAD(1608/60R,CB03YTYH600) CLZ9R005V 4
L1401-1404 nsp FERRITE CHIP BEAD(1608/60R,CB03YTYH600) CLZ9R005V 4
LD101 963262010460S L.E.D (Infrared light emitting diode) E3 CVDSIR341ST3FT0 1
LUG11 nsp WIRE ASS'Y CWE8102100RV 1
LUG13 nsp WIRE ASS'Y CWE8102180RV 1
RC101 943262100140S SENSOR, REMOTE(37.9KHz) CRVHM238RT12 1
SW101 00D9430004402 SW , TACT CST1A012ZT 1
SW102,103 00D9430004402 SW , TACT S710 CST1A012ZT 2
SW104-106 00D9430004402 SW , TACT CST1A012ZT 3
SW107,108 00D9430004402 SW , TACT S710 CST1A012ZT 2
SW109-111 00D9430004402 SW , TACT CST1A012ZT 3
SW112-114 00D9430004402 SW , TACT S710 CST1A012ZT 3
SW115-118 00D9430004402 SW , TACT CST1A012ZT 4
SW119 00D9430004402 SW , TACT S710 CST1A012ZT 1
VR101 943671010330S ENCODER(16MM, 24PULSES),W/CLICK CSR2A055Z 1
VR102 943671101000D ENCODER(16MM, 12PULSES) CSR2A060Z 1
