Denon AVR-X1200W Service Manual

FRONT-HDMI
FRONT-HDMI PCB ASS'Y
※Parts indicated b
y
"ns
p
"on this table cannot be su
pp
lied
.
※The
p
arts listed below are onl
y
for maintenance. Therefore the
y
mi
g
ht differ from the
p
arts used in the unit in a
pp
earances or dimension
s
NOTE:The symbols in the column Remarks indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model E1C : China model E1 : Asia model JP : Japan model
BK : Black model SP : Premium Silver model
REF No. Part No. Part Name Remarks Q'ty New Ver
SEMICONDUCTORS GROUP
IC811 963236101380P I.C, HDMI BUFFER CVIAD8195ACPZ 1
Q8101 943215500020S T.R,RT1P141C(10K-10K) CVTRT1P141C 1
Q8102 943216500040S T.R,RT1N241C(22K-22K) CVTRT1N241C 1
RESISTOR GROUP
R8102 nsp RES, CHIP(1005/5%/1Kohm) CRJ06IJ102T 1
R8103 nsp RES, CHIP(1005/5%/22Kohm) CRJ06IJ223T 1
R8104 nsp RES, CHIP(1005/5%/47Kohm) CRJ06IJ473T 1
R8105 nsp RES, CHIP(1005/5%/0ohm) CRJ06IJ0R0T 1
R8107 nsp RES, CHIP(1005/5%/47Kohm) CRJ06IJ473T 1
R8108 nsp RES, CHIP(1005/5%/0ohm) CRJ06IJ0R0T 1
R8111 nsp RES, CHIP(1005/5%/2Kohm) CRJ06IJ202T 1
R8117,8118 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 2
R8120,8121 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 2
R8123 nsp RES, CHIP(1005/5%/4.7Kohm) CRJ06IJ472T 1
R8126,8127 nsp RES, CHIP(1005/5%/2Kohm) CRJ06IJ202T 2
R8128 nsp RES, CHIP(1005/5%/0ohm) CRJ06IJ0R0T 1
RN811-814 nsp RES, CHIP(1005/5%/0ohm*2) CRJ062IJ0R0T 4
CAPACIITORS GROUP
C8101-8105 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 5
C8108-8111 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 4
C8112 nsp CAP, CHIP(2012, 6.3V/10uF, X5R)_SAMSUNG CCUC0J106KCS 1
C8113-8121 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 9
C8122 nsp CAP, CHIP(2012, 6.3V/10uF, X5R)_SAMSUNG CCUC0J106KCS 1
C8127 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C8128 nsp CAP, CHIP(2012, 6.3V/10uF, X5R)_SAMSUNG CCUC0J106KCS 1
C8134 nsp CAP, CHIP(1005, 25V/0.01uF, X7R)_SAMSUNG CCUI1E103KCS 1
OTHER PARTS GROUP
BK871 nsp EARTH , HDMI CMC1A422 1
CN811 nsp WAFER, FFC(23PIN, 1mm STRAIGHT) CJP23GA333ZR 1 *
JK811 943643102920S JACK , HDMI(TYPE-A, SMT-19P, WITH FLANGE) CJJ9H021Z 1
L8101,8102 nsp FERRITE CHIP BEAD(1608/60R,CB03YTYH600) CLZ9R005V 2
3

Denon AVR-X1200W Specifications

General

HDMI in	6
AC (power) in	Yes
Composite video in	2
USB ports quantity	1
Digital audio coaxial in	0
Receiver type	-
Audio output channels	7.2 channels
Total Harmonic Distortion (THD)	1 %
Power output per channel (20-20KHz@8 Ohm)	145 W
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Internet radio services supported	Spotify
Product color	Black
Audio decoders	DTS-HD Master Audio
Apple docking compatibility	iPhone, iPod
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	430 W
Connectivity technology	Wired
Optical drive included	No
Audio formats supported	AIFF, ALAC, FLAC

Weight and Dimensions

Depth	339 mm
Width	434 mm
Height	151 mm
Weight	8500 g
