Denon AVR-X1200W Service Manual

DIFF-AMP
DIFF-AMP PCB ASS'Y
※Parts indicated b
y
"ns
p
"on this table cannot be su
pp
lied
.
※The
p
arts listed below are onl
y
for maintenance. Therefore the
y
mi
g
ht differ from the
p
arts used in the unit in a
pp
earances or dimension
s
NOTE:The symbols in the column Remarks indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model E1C : China model E1 : Asia model JP : Japan model
BK : Black model SP : Premium Silver model
REF No. Part No. Part Name Remarks Q'ty New Ver
SEMICONDUCTORS GROUP
Q2101,2102 943211500150S PNP, TO-92, LOW NOISE, HFE:300-600, FAILCHILD CVTKSA992FTA 2
Q2103 943213500150S NPN, TO-92, LOW NOISE, HFE:300-600, FAILCHILD CVTKSC1845FTA 1
Q2104 90M-HT800120R T.R , BIAS HVTKTC3114A 7
Q2201,2202 943211500150S PNP, TO-92, LOW NOISE, HFE:300-600, FAILCHILD CVTKSA992FTA 2
Q2203 943213500150S NPN, TO-92, LOW NOISE, HFE:300-600, FAILCHILD CVTKSC1845FTA 1
Q2301,2302 943211500150S PNP, TO-92, LOW NOISE, HFE:300-600, FAILCHILD CVTKSA992FTA 2
Q2303 943213500150S NPN, TO-92, LOW NOISE, HFE:300-600, FAILCHILD CVTKSC1845FTA 1
Q2401,2402 943211500150S PNP, TO-92, LOW NOISE, HFE:300-600, FAILCHILD CVTKSA992FTA 2
Q2403 943213500150S NPN, TO-92, LOW NOISE, HFE:300-600, FAILCHILD CVTKSC1845FTA 1
Q2501,2502 943211500150S PNP, TO-92, LOW NOISE, HFE:300-600, FAILCHILD CVTKSA992FTA 2
Q2503 943213500150S NPN, TO-92, LOW NOISE, HFE:300-600, FAILCHILD CVTKSC1845FTA 1
Q2601,2602 943211500150S PNP, TO-92, LOW NOISE, HFE:300-600, FAILCHILD CVTKSA992FTA 2
Q2603 943213500150S NPN, TO-92, LOW NOISE, HFE:300-600, FAILCHILD CVTKSC1845FTA 1
Q2701,2702 943211500150S PNP, TO-92, LOW NOISE, HFE:300-600, FAILCHILD CVTKSA992FTA 2
Q2703 943213500150S NPN, TO-92, LOW NOISE, HFE:300-600, FAILCHILD CVTKSC1845FTA 1
RESISTOR GROUP
R2101 nsp RES, CARBON(1/5W,100Kohm,J) CRD20TJ104T 1
R2102 nsp RES, CARBON(1/5W,680ohm,J) CRD20TJ681T 1
R2103 nsp RES, CARBON(1/5W,10Kohm,J) CRD20TJ103T 1
R2104 nsp RES, CARBON(1/5W,18Kohm,J) CRD20TJ183T 1
R2105 nsp RES, CARBON(1/5W,1.2Kohm,J) CRD20TJ122T 1
R2106 nsp RES, M-OXIDE FILM(1W/1.2Kohm) CRG1SANJ122RT 1
R2107 nsp RES, CARBON(1/5W,220ohm,J) CRD20TJ221T 1
R2108 nsp RES, CARBON(1/5W,470Kohm,J) CRD20TJ474T 1
R2109 nsp RES, CARBON(1/5W,33Kohm,J) CRD20TJ333T 1
R2110 nsp RES, M-OXIDE FILM(1W/47ohm) CRG1SANJ470RT 1
R2201 nsp RES, CARBON(1/5W,100Kohm,J) CRD20TJ104T 1
R2202 nsp RES, CARBON(1/5W,680ohm,J) CRD20TJ681T 1
R2203 nsp RES, CARBON(1/5W,10Kohm,J) CRD20TJ103T 1
R2204 nsp RES, CARBON(1/5W,18Kohm,J) CRD20TJ183T 1
R2205 nsp RES, CARBON(1/5W,1.2Kohm,J) CRD20TJ122T 1
R2206 nsp RES, M-OXIDE FILM(1W/1.2Kohm) CRG1SANJ122RT 1
R2207 nsp RES, CARBON(1/5W,220ohm,J) CRD20TJ221T 1
R2208 nsp RES, CARBON(1/5W,470Kohm,J) CRD20TJ474T 1
R2209 nsp RES, CARBON(1/5W,33Kohm,J) CRD20TJ333T 1
R2210 nsp RES, M-OXIDE FILM(1W/47ohm) CRG1SANJ470RT 1
R2301 nsp RES, CARBON(1/5W,100Kohm,J) CRD20TJ104T 1
R2302 nsp RES, CARBON(1/5W,680ohm,J) CRD20TJ681T 1
R2303 nsp RES, CARBON(1/5W,10Kohm,J) CRD20TJ103T 1
R2304 nsp RES, CARBON(1/5W,18Kohm,J) CRD20TJ183T 1
R2305 nsp RES, CARBON(1/5W,1.2Kohm,J) CRD20TJ122T 1
R2306 nsp RES, M-OXIDE FILM(1W/1.2Kohm) CRG1SANJ122RT 1
R2307 nsp RES, CARBON(1/5W,220ohm,J) CRD20TJ221T 1
R2308 nsp RES, CARBON(1/5W,470Kohm,J) CRD20TJ474T 1
R2309 nsp RES, CARBON(1/5W,33Kohm,J) CRD20TJ333T 1
R2310 nsp RES, M-OXIDE FILM(1W/47ohm) CRG1SANJ470RT 1
R2401 nsp RES, CARBON(1/5W,100Kohm,J) CRD20TJ104T 1
R2402 nsp RES, CARBON(1/5W,680ohm,J) CRD20TJ681T 1
R2403 nsp RES, CARBON(1/5W,10Kohm,J) CRD20TJ103T 1
R2404 nsp RES, CARBON(1/5W,18Kohm,J) CRD20TJ183T 1
R2405 nsp RES, CARBON(1/5W,1.2Kohm,J) CRD20TJ122T 1
R2406 nsp RES, M-OXIDE FILM(1W/1.2Kohm) CRG1SANJ122RT 1
R2407 nsp RES, CARBON(1/5W,220ohm,J) CRD20TJ221T 1
R2408 nsp RES, CARBON(1/5W,470Kohm,J) CRD20TJ474T 1
R2409 nsp RES, CARBON(1/5W,33Kohm,J) CRD20TJ333T 1
R2410 nsp RES, M-OXIDE FILM(1W/47ohm) CRG1SANJ470RT 1
R2501 nsp RES, CARBON(1/5W,100Kohm,J) CRD20TJ104T 1
R2502 nsp RES, CARBON(1/5W,680ohm,J) CRD20TJ681T 1
R2503 nsp RES, CARBON(1/5W,10Kohm,J) CRD20TJ103T 1
R2504 nsp RES, CARBON(1/5W,18Kohm,J) CRD20TJ183T 1
R2505 nsp RES, CARBON(1/5W,1.2Kohm,J) CRD20TJ122T 1
R2506 nsp RES, M-OXIDE FILM(1W/1.2Kohm) CRG1SANJ122RT 1
R2507 nsp RES, CARBON(1/5W,220ohm,J) CRD20TJ221T 1
R2508 nsp RES, CARBON(1/5W,470Kohm,J) CRD20TJ474T 1
R2509 nsp RES, CARBON(1/5W,33Kohm,J) CRD20TJ333T 1
R2510 nsp RES, M-OXIDE FILM(1W/47ohm) CRG1SANJ470RT 1
R2601 nsp RES, CARBON(1/5W,100Kohm,J) CRD20TJ104T 1
R2602 nsp RES, CARBON(1/5W,680ohm,J) CRD20TJ681T 1
R2603 nsp RES, CARBON(1/5W,10Kohm,J) CRD20TJ103T 1
R2604 nsp RES, CARBON(1/5W,18Kohm,J) CRD20TJ183T 1
R2605 nsp RES, CARBON(1/5W,1.2Kohm,J) CRD20TJ122T 1
R2606 nsp RES, M-OXIDE FILM(1W/1.2Kohm) CRG1SANJ122RT 1
R2607 nsp RES, CARBON(1/5W,220ohm,J) CRD20TJ221T 1
R2608 nsp RES, CARBON(1/5W,470Kohm,J) CRD20TJ474T 1
R2609 nsp RES, CARBON(1/5W,33Kohm,J) CRD20TJ333T 1
R2610 nsp RES, M-OXIDE FILM(1W/47ohm) CRG1SANJ470RT 1
R2701 nsp RES, CARBON(1/5W,100Kohm,J) CRD20TJ104T 1
R2702 nsp RES, CARBON(1/5W,680ohm,J) CRD20TJ681T 1
R2703 nsp RES, CARBON(1/5W,10Kohm,J) CRD20TJ103T 1
R2704 nsp RES, CARBON(1/5W,18Kohm,J) CRD20TJ183T 1
R2705 nsp RES, CARBON(1/5W,1.2Kohm,J) CRD20TJ122T 1
R2706 nsp RES, M-OXIDE FILM(1W/1.2Kohm) CRG1SANJ122RT 1
R2707 nsp RES, CARBON(1/5W,220ohm,J) CRD20TJ221T 1
R2708 nsp RES, CARBON(1/5W,470Kohm,J) CRD20TJ474T 1
R2709 nsp RES, CARBON(1/5W,33Kohm,J) CRD20TJ333T 1
R2710 nsp RES, M-OXIDE FILM(1W/47ohm) CRG1SANJ470RT 1
CAPACIITORS GROUP
C2101 nsp CAP, ELECT(50V/47uF) CCEA1HH470T 1
C2102 nsp CAP, MYLAR(100V/470pF/J) HCQI2A471JZT 1
C2103 nsp CAP, CERAMIC(50V/82pF/J) CCCT1H820JC 1
C2104 nsp CAP, MYLAR(50V/2200pF/J) HCQI1H222JZT 1
C2105 nsp CAP, ELECT(50V/220uF) CCEA1HH221T 1
C2106 nsp CAP, CERAMIC(50V/33pF/J) CCCT1H330JC 1
C2201 nsp CAP, ELECT(50V/47uF) CCEA1HH470T 1
C2202 nsp CAP, MYLAR(100V/470pF/J) HCQI2A471JZT 1
C2203 nsp CAP, CERAMIC(50V/82pF/J) CCCT1H820JC 1
C2204 nsp CAP, MYLAR(50V/2200pF/J) HCQI1H222JZT 1
C2205 nsp CAP, ELECT(50V/220uF) CCEA1HH221T 1
C2206 nsp CAP, CERAMIC(50V/33pF/J) CCCT1H330JC 1
C2301 nsp CAP, ELECT(50V/47uF) CCEA1HH470T 1
C2302 nsp CAP, MYLAR(100V/470pF/J) HCQI2A471JZT 1
C2303 nsp CAP, CERAMIC(50V/82pF/J) CCCT1H820JC 1
C2304 nsp CAP, MYLAR(50V/2200pF/J) HCQI1H222JZT 1
C2305 nsp CAP, ELECT(50V/220uF) CCEA1HH221T 1
C2306 nsp CAP, CERAMIC(50V/33pF/J) CCCT1H330JC 1
4

Denon AVR-X1200W Specifications

General

HDMI in	6
AC (power) in	Yes
Composite video in	2
USB ports quantity	1
Digital audio coaxial in	0
Receiver type	-
Audio output channels	7.2 channels
Total Harmonic Distortion (THD)	1 %
Power output per channel (20-20KHz@8 Ohm)	145 W
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Internet radio services supported	Spotify
Product color	Black
Audio decoders	DTS-HD Master Audio
Apple docking compatibility	iPhone, iPod
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	430 W
Connectivity technology	Wired
Optical drive included	No
Audio formats supported	AIFF, ALAC, FLAC

Weight and Dimensions

Depth	339 mm
Width	434 mm
Height	151 mm
Weight	8500 g
