Denon AVR-X2100W User Manual

o
Proxy
Make this setting when connecting to the Internet via a proxy server.
Make the proxy settings only when you connect to the Internet via a
proxy server that is on your internal network or provided by your
provider, etc.
On(Address): Select when inputting by address.
On(Name): Select when inputting by domain name.
Off
(Default):
Disables the proxy server.
o
Port
Enter port number.
0
If you cannot connect to the Internet, recheck the connections and settings.
(v p. 50)
0
If you do not understand about Internet connection, contact your ISP (Internet
Service Provider) or the store from which you purchased your computer.
IP Control
Enables network communication in standby power mode.
Off In Standby
(Default):
Suspend network function during standby.
Always On:
Network is on during standby. Main unit
operable with a network compatible
controller.
When using the web control function or Denon Remote App, use with the “IP Control”
setting set to “Always On”.
NOTE
When “IP Control” is set to “Always On”, it consumes more standby power.
Contents Connections Playback Settings Tips Appendix
185
Front panel Display Rear panel Remote Index

Denon AVR-X2100W Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	100 dB
Power output per channel (1KHz@6 Ohm)	150 W
Power output per channel (20-20KHz@8 Ohm)	95 W
HDMI in	8
Composite video in	2
Component video (YPbPr/YCbCr) in	1
Speakers connectivity type	-
Ethernet LAN	Yes
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Optical drive included	No
Product color	Black
Audio decoders	Dolby Digital EX, Dolby Pro Logic IIx, Dolby TrueHD, DTS 96/24, DTS-ES, DTS-HD
Apple docking compatibility	iPhone, iPod
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	500 W

Weight and Dimensions

Depth	339 mm
Width	434 mm
Height	167 mm
Weight	9700 g
