Denon AVR-X2100W - Connection 1: TV Equipped with an HDMI Connector and Compatible with the ARC (Audio Return Channel)

Connection 1 : TV equipped with an HDMI connector and compatible with the ARC
(Audio Return Channel)
Use an HDMI cable to connect a TV that is compatible with the ARC function to this unit.
Set “HDMI Control” (v p. 151) to “On” when using a TV that supports the ARC function.
.
