Denon AVR-X4000 Service Manual

AMP
AMP PCB ASS'
Y
※Parts indicated b
y
"ns
p
" on this table cannot be su
pp
lied.
※The
p
arts listed below are onl
y
for maintenance. Therefore the
y
mi
g
ht differ from the
p
arts used in the unit in a
pp
earances or dimensions.
NOTE:The symbols in the column Remarks indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model E1C : China model E1 : Asia model K : Japan model
BK : Black model SP : Premium Silver model
REF No. Part No. Part Name Remarks Q't
y
New
V
e
r
SEMICONDUCTORS GROUP
D7011,7012 943209001080S DIODE , CHIP , SWITCHING 1SS355/HOMI(HK) COMPANY LTD CVD1SS355T 2
D7108,7109 00D9430182609 DIODE , SWITCHING 1SS133/HOMI(HK) COMPANY LTD CVD1SS133MT 2
D7118 00D9430182609 DIODE , SWITCHING 1SS133/HOMI(HK) COMPANY LTD CVD1SS133MT 1
D7139 00D9430182609 DIODE , SWITCHING 1SS133/HOMI(HK) COMPANY LTD CVD1SS133MT 1
D7208,7209 00D9430182609 DIODE , SWITCHING 1SS133/HOMI(HK) COMPANY LTD CVD1SS133MT 2
D7218 00D9430182609 DIODE , SWITCHING 1SS133/HOMI(HK) COMPANY LTD CVD1SS133MT 1
D7239 00D9430182609 DIODE , SWITCHING 1SS133/HOMI(HK) COMPANY LTD CVD1SS133MT 1
D7308,7309 00D9430182609 DIODE , SWITCHING 1SS133/HOMI(HK) COMPANY LTD CVD1SS133MT 2
D7318 00D9430182609 DIODE , SWITCHING 1SS133/HOMI(HK) COMPANY LTD CVD1SS133MT 1
D7339 00D9430182609 DIODE , SWITCHING 1SS133/HOMI(HK) COMPANY LTD CVD1SS133MT 1
D7408,7409 00D9430182609 DIODE , SWITCHING 1SS133/HOMI(HK) COMPANY LTD CVD1SS133MT 2
D7418 00D9430182609 DIODE , SWITCHING 1SS133/HOMI(HK) COMPANY LTD CVD1SS133MT 1
D7439 00D9430182609 DIODE , SWITCHING 1SS133/HOMI(HK) COMPANY LTD CVD1SS133MT 1
D7508,7509 00D9430182609 DIODE , SWITCHING 1SS133/HOMI(HK) COMPANY LTD CVD1SS133MT 2
D7518 00D9430182609 DIODE , SWITCHING 1SS133/HOMI(HK) COMPANY LTD CVD1SS133MT 1
D7539 00D9430182609 DIODE , SWITCHING 1SS133/HOMI(HK) COMPANY LTD CVD1SS133MT 1
D7608,7609 00D9430182609 DIODE , SWITCHING 1SS133/HOMI(HK) COMPANY LTD CVD1SS133MT 2
D7618 00D9430182609 DIODE , SWITCHING 1SS133/HOMI(HK) COMPANY LTD CVD1SS133MT 1
D7639 00D9430182609 DIODE , SWITCHING 1SS133/HOMI(HK) COMPANY LTD CVD1SS133MT 1
D7708,7709 00D9430182609 DIODE , SWITCHING 1SS133/HOMI(HK) COMPANY LTD CVD1SS133MT 2
D7718 00D9430182609 DIODE , SWITCHING 1SS133/HOMI(HK) COMPANY LTD CVD1SS133MT 1
D7739 00D9430182609 DIODE , SWITCHING 1SS133/HOMI(HK) COMPANY LTD CVD1SS133MT 1
Q7001 943212500020S High Voltage PNP Transistors(SOT-23) CVTMMBT5401 1
Q7104,7105 943211500150S PNP, TO-92, LOW NOISE, HFE:300-600, FAILCHILD KSA992FTA HFE F(300~600) CVTKSA992FTA 2
Q7114 00D2710314903 T.R HVTKTA1024YT 1
Q7118 00D2710314903 T.R HVTKTA1024YT 1
Q7120,7121 00D2730471907 T.R HVTKTC3206YAT 2
Q7125 963219003340S T.R , BIAS KTC3964/TO-126 CVTKTC3964 1
Q7131 00D9630235301 T.R , POWER(Pc 130W) 2SD2560 SANKEN HVT2SD2560 1
Q7132 00D9630235204 T.R , POWER(Pc 130W) 2SB1647 SANKEN HVT2SB1647 1
Q7138 943212500020S High Voltage PNP Transistors(SOT-23) CVTMMBT5401 1
Q7139 943214500040S High Voltage NPN Transistors(SOT-23) CVTMMBT5551 1
Q7204,7205 943211500150S PNP, TO-92, LOW NOISE, HFE:300-600, FAILCHILD KSA992FTA HFE F(300~600) CVTKSA992FTA 2
Q7214 00D2710314903 T.R HVTKTA1024YT 1
Q7218 00D2710314903 T.R HVTKTA1024YT 1
Q7220,7221 00D2730471907 T.R HVTKTC3206YAT 2
Q7225 963219003340S T.R , BIAS KTC3964/TO-126 CVTKTC3964 1
Q7231 00D9630235301 T.R , POWER(Pc 130W) 2SD2560 SANKEN HVT2SD2560 1
Q7232 00D9630235204 T.R , POWER(Pc 130W) 2SB1647 SANKEN HVT2SB1647 1
Q7238 943212500020S High Voltage PNP Transistors(SOT-23) CVTMMBT5401 1
Q7239 943214500040S High Voltage NPN Transistors(SOT-23) CVTMMBT5551 1
Q7304,7305 943211500150S PNP, TO-92, LOW NOISE, HFE:300-600, FAILCHILD KSA992FTA HFE F(300~600) CVTKSA992FTA 2
Q7314 00D2710314903 T.R HVTKTA1024YT 1
Q7318 00D2710314903 T.R HVTKTA1024YT 1
Q7320,7321 00D2730471907 T.R HVTKTC3206YAT 2
Q7325 963219003340S T.R , BIAS KTC3964/TO-126 CVTKTC3964 1
Q7331 00D9630235301 T.R , POWER(Pc 130W) 2SD2560 SANKEN HVT2SD2560 1
Q7332 00D9630235204 T.R , POWER(Pc 130W) 2SB1647 SANKEN HVT2SB1647 1
Q7338 943212500020S High Voltage PNP Transistors(SOT-23) CVTMMBT5401 1
Q7339 943214500040S High Voltage NPN Transistors(SOT-23) CVTMMBT5551 1
Q7404,7405 943211500150S PNP, TO-92, LOW NOISE, HFE:300-600, FAILCHILD KSA992FTA HFE F(300~600) CVTKSA992FTA 2
Q7414 00D2710314903 T.R HVTKTA1024YT 1
Q7418 00D2710314903 T.R HVTKTA1024YT 1
Q7420,7421 00D2730471907 T.R HVTKTC3206YAT 2
Q7425 963219003340S T.R , BIAS KTC3964/TO-126 CVTKTC3964 1
Q7431 00D9630235301 T.R , POWER(Pc 130W) 2SD2560 SANKEN HVT2SD2560 1
Q7432 00D9630235204 T.R , POWER(Pc 130W) 2SB1647 SANKEN HVT2SB1647 1
Q7438 943212500020S High Voltage PNP Transistors(SOT-23) CVTMMBT5401 1
Q7439 943214500040S High Voltage NPN Transistors(SOT-23) CVTMMBT5551 1
Q7504,7505 943211500150S PNP, TO-92, LOW NOISE, HFE:300-600, FAILCHILD KSA992FTA HFE F(300~600) CVTKSA992FTA 2
Q7514 00D2710314903 T.R HVTKTA1024YT 1
Q7518 00D2710314903 T.R HVTKTA1024YT 1
Q7520,7521 00D2730471907 T.R HVTKTC3206YAT 2
Q7525 963219003340S T.R , BIAS KTC3964/TO-126 CVTKTC3964 1
Q7531 00D9630235301 T.R , POWER(Pc 130W) 2SD2560 SANKEN HVT2SD2560 1
Q7532 00D9630235204 T.R , POWER(Pc 130W) 2SB1647 SANKEN HVT2SB1647 1
Q7538 943212500020S High Voltage PNP Transistors(SOT-23) CVTMMBT5401 1
Q7539 943214500040S High Voltage NPN Transistors(SOT-23) CVTMMBT5551 1
Q7604,7605 943211500150S PNP, TO-92, LOW NOISE, HFE:300-600, FAILCHILD KSA992FTA HFE F(300~600) CVTKSA992FTA 2
Q7614 00D2710314903 T.R HVTKTA1024YT 1
Q7618 00D2710314903 T.R HVTKTA1024YT 1
Q7620,7621 00D2730471907 T.R HVTKTC3206YAT 2
Q7625 963219003340S T.R , BIAS KTC3964/TO-126 CVTKTC3964 1
Q7631 00D9630235301 T.R , POWER(Pc 130W) 2SD2560 SANKEN HVT2SD2560 1
Q7632 00D9630235204 T.R , POWER(Pc 130W) 2SB1647 SANKEN HVT2SB1647 1
Q7638 943212500020S High Voltage PNP Transistors(SOT-23) CVTMMBT5401 1
Q7639 943214500040S High Voltage NPN Transistors(SOT-23) CVTMMBT5551 1
Q7704,7705 943211500150S PNP, TO-92, LOW NOISE, HFE:300-600, FAILCHILD KSA992FTA HFE F(300~600) CVTKSA992FTA 2
Q7714 00D2710314903 T.R HVTKTA1024YT 1
Q7718 00D2710314903 T.R HVTKTA1024YT 1
Q7720,7721 00D2730471907 T.R HVTKTC3206YAT 2
Q7725 963219003340S T.R , BIAS KTC3964/TO-126 CVTKTC3964 1
Q7731 00D9630235301 T.R , POWER(Pc 130W) 2SD2560 SANKEN HVT2SD2560 1
Q7732 00D9630235204 T.R , POWER(Pc 130W) 2SB1647 SANKEN HVT2SB1647 1
Q7738 943212500020S High Voltage PNP Transistors(SOT-23) CVTMMBT5401 1
Q7739 943214500040S High Voltage NPN Transistors(SOT-23) CVTMMBT5551 1
ZD714 943202010080S DIODE , ZENER ,1/2W, 5.1V ZJ5.1B/HOMI(H.K) COMPANY LTD CVDZJ5.1BT 1
ZD724 943202010080S DIODE , ZENER ,1/2W, 5.1V ZJ5.1B/HOMI(H.K) COMPANY LTD CVDZJ5.1BT 1
ZD734 943202010080S DIODE , ZENER ,1/2W, 5.1V ZJ5.1B/HOMI(H.K) COMPANY LTD CVDZJ5.1BT 1
ZD744 943202010080S DIODE , ZENER ,1/2W, 5.1V ZJ5.1B/HOMI(H.K) COMPANY LTD CVDZJ5.1BT 1
ZD754 943202010080S DIODE , ZENER ,1/2W, 5.1V ZJ5.1B/HOMI(H.K) COMPANY LTD CVDZJ5.1BT 1
ZD764 943202010080S DIODE , ZENER ,1/2W, 5.1V ZJ5.1B/HOMI(H.K) COMPANY LTD CVDZJ5.1BT 1
ZD774 943202010080S DIODE , ZENER ,1/2W, 5.1V ZJ5.1B/HOMI(H.K) COMPANY LTD CVDZJ5.1BT 1
RESISTOR GROUP
R7001 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R7002 00MGD05333160 RES, CARBON(1/5W,33Kohm,J) CRD20TJ333T 1
3

Denon AVR-X4000 Specifications

General

Receiver type	-
Frequency range	10 - 100000 Hz
Output impedance	16 Ω
Speaker selector	A+B
Input sensitivity	200 mV
Audio output channels	7.2 channels
Signal-to-Noise Ratio (SNR)	102 dB
Total Harmonic Distortion (THD)	0.008 %
Power output per channel (1KHz@6 Ohm)	165 W
Power output per channel (20-20KHz@8 Ohm)	125 W
HDMI in	7
AC (power) in	Yes
Composite video in	4
Ethernet LAN (RJ-45) ports	1
Component video (YPbPr/YCbCr) in	2
Number of HDMI outputs	3
Connectivity technology	Wired
Speakers connectivity type	Banana connector
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Wi-Fi	No
RDS features	PTY, TP
FM band range	87.5 - 108 MHz
Supported radio bands	FM
Internet radio services supported	Spotify, vTuner
Supported video modes	1080i, 1080p, 480p, 576p, 720p
Display	VFL
Color depth	24 bit
Aspect ratio	4:3, 16:9
Product color	Silver
Audio decoders	Dolby Digital, Dolby Digital EX, Dolby Digital Plus, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), DTS-HD, DTS-HD Master Audio
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Apple docking compatibility	Not supported
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	670 W

Weight and Dimensions

Depth	379 mm
Width	434 mm
Height	167 mm
Weight	12300 g
