Denon AVR-X4000 Service Manual

AMP
REF No. Part No. Part Name Remarks Q't
y
New
V
e
r
R7011 nsp RES, CHIP(1608/5%/330Kohm) CRJ10DJ334T 1
! R7012 252310006520S PTC THEMISTORS, CHIP(95'C) PRF18BD471QB5RB CRTPRF18BD471Q
B
1
R7013 nsp RES, CHIP(1608/5%/330Kohm) CRJ10DJ334T 1
! R7014 252310006520S PTC THEMISTORS, CHIP(95'C) PRF18BD471QB5RB CRTPRF18BD471Q
B
1
R7016 nsp RES, CARBON(1/5W,3.3Kohm,J) CRD20TJ332T 1
R7017 nsp RES, CARBON(1/5W,10Kohm,J) CRD20TJ103T 1
R7018 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R7101 00MGD05122160 RES, CARBON(1/5W,1.2Kohm,J) CRD20TJ122T 1
R7102 00MGD05474160 RES, CARBON(1/5W,470Kohm,J) CRD20TJ474T 1
R7103 00MGD05333160 RES, CARBON(1/5W,33Kohm,J) CRD20TJ333T 1
R7105 nsp RES, M-OXIDE FILM(1W/1Kohm) CRG1SANJ102RT 1
R7106 nsp RES, CARBON(1/5W,470ohm,J) CRD20TJ471T 1
R7108 nsp RES, M-OXIDE FILM(1W/1Kohm) CRG1SANJ102RT 1
R7109,7110 nsp RES, CARBON(1/5W,220ohm,J) CRD20TJ221T 2
R7111 nsp RES, M-OXIDE FILM(1W/3.3Kohm) CRG1SANJ332RT 1
R7112 00MGD05333160 RES, CARBON(1/5W,33Kohm,J) CRD20TJ333T 1
R7114 nsp RES, M-OXIDE FILM(1W/56Kohm) CRG1SANJ563RT 1
R7116,7117 00MGD05122160 RES, CARBON(1/5W,1.2Kohm,J) CRD20TJ122T 2
R7118,7119 nsp RES, M-OXIDE FILM(1W/270ohm) CRG1SANJ271RT 2
R7120 nsp RES, M-OXIDE FILM(2W/15Kohm) CRG2SANJ153RT 1
R7121 nsp RES, M-OXIDE FILM(1W/270ohm) CRG1SANJ271RT 1
R7124 00MGD05272160 RES, CARBON(1/5W,2.7Kohm,J) CRD20TJ272T 1
R7125 nsp RES, CARBON(1/5W,470ohm,J) CRD20TJ471T 1
R7126 00MGD05561160 RES, CARBON(1/5W,560ohm,J) CRD20TJ561T 1
R7129,7130 943124500240S RES, M-OXIDE FILM(1W/22ohm) CRG1SANJ220RT 2
R7131-7134 943124500050S RES, M-OXIDE FILM(2W/0.47ohm) CRG2SANJR47RT 4
R7135,7136 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 2
R7137 nsp RES, CARBON(1/5W,680Kohm,J) CRD20TJ684T 1
! R7138 252310006506S PTC THEMISTORS, CHIP(115'C) PRF18BB471QB5RB CRTPRF18BB471Q
B
1
R7139 nsp RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T 1
R7140 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R7141 00MNN05562610 RES, CHIP(1608/5%/5.6Kohm) CRJ10DJ562T 1
R7143 nsp RES, CARBON(1/5W,47Kohm,J) CRD20TJ473T 1
R7144 nsp RES, CHIP(3216/5%/22Kohm) CRJ14CJ223T 1
R7145 nsp RES, CARBON(1/5W,22Kohm,J) CRD20TJ223T 1
R7201 00MGD05122160 RES, CARBON(1/5W,1.2Kohm,J) CRD20TJ122T 1
R7202 00MGD05474160 RES, CARBON(1/5W,470Kohm,J) CRD20TJ474T 1
R7203 00MGD05333160 RES, CARBON(1/5W,33Kohm,J) CRD20TJ333T 1
R7205 nsp RES, M-OXIDE FILM(1W/1Kohm) CRG1SANJ102RT 1
R7206 nsp RES, CARBON(1/5W,470ohm,J) CRD20TJ471T 1
R7208 nsp RES, M-OXIDE FILM(1W/1Kohm) CRG1SANJ102RT 1
R7209,7210 nsp RES, CARBON(1/5W,220ohm,J) CRD20TJ221T 2
R7211 nsp RES, M-OXIDE FILM(1W/3.3Kohm) CRG1SANJ332RT 1
R7212 00MGD05333160 RES, CARBON(1/5W,33Kohm,J) CRD20TJ333T 1
R7214 nsp RES, M-OXIDE FILM(1W/56Kohm) CRG1SANJ563RT 1
R7216,7217 00MGD05122160 RES, CARBON(1/5W,1.2Kohm,J) CRD20TJ122T 2
R7218,7219 nsp RES, M-OXIDE FILM(1W/270ohm) CRG1SANJ271RT 2
R7220 nsp RES, M-OXIDE FILM(2W/15Kohm) CRG2SANJ153RT 1
R7221 nsp RES, M-OXIDE FILM(1W/270ohm) CRG1SANJ271RT 1
R7224 00MGD05272160 RES, CARBON(1/5W,2.7Kohm,J) CRD20TJ272T 1
R7225 nsp RES, CARBON(1/5W,470ohm,J) CRD20TJ471T 1
R7226 00MGD05561160 RES, CARBON(1/5W,560ohm,J) CRD20TJ561T 1
R7230 943124500240S RES, M-OXIDE FILM(1W/22ohm) CRG1SANJ220RT 1
R7231-7234 943124500050S RES, M-OXIDE FILM(2W/0.47ohm) CRG2SANJR47RT 4
R7235,7236 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 2
R7237 nsp RES, CARBON(1/5W,680Kohm,J) CRD20TJ684T 1
! R7238 252310006506S PTC THEMISTORS, CHIP(115'C) PRF18BB471QB5RB CRTPRF18BB471Q
B
1
R7239 nsp RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T 1
R7240 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R7241 00MNN05562610 RES, CHIP(1608/5%/5.6Kohm) CRJ10DJ562T 1
R7243 nsp RES, CHIP(3216/5%/47Kohm) CRJ14CJ473T 1
R7244 nsp RES, CHIP(3216/5%/22Kohm) CRJ14CJ223T 1
R7245 nsp RES, CARBON(1/5W,22Kohm,J) CRD20TJ223T 1
R7279 943124500240S RES, M-OXIDE FILM(1W/22ohm) CRG1SANJ220RT 1
R7301 00MGD05122160 RES, CARBON(1/5W,1.2Kohm,J) CRD20TJ122T 1
R7302 00MGD05474160 RES, CARBON(1/5W,470Kohm,J) CRD20TJ474T 1
R7303 00MGD05333160 RES, CARBON(1/5W,33Kohm,J) CRD20TJ333T 1
R7305 nsp RES, M-OXIDE FILM(1W/1Kohm) CRG1SANJ102RT 1
R7306 nsp RES, CARBON(1/5W,470ohm,J) CRD20TJ471T 1
R7308 nsp RES, M-OXIDE FILM(1W/1Kohm) CRG1SANJ102RT 1
R7309,7310 nsp RES, CARBON(1/5W,220ohm,J) CRD20TJ221T 2
R7311 nsp RES, M-OXIDE FILM(1W/3.3Kohm) CRG1SANJ332RT 1
R7312 00MGD05333160 RES, CARBON(1/5W,33Kohm,J) CRD20TJ333T 1
R7314 nsp RES, M-OXIDE FILM(1W/56Kohm) CRG1SANJ563RT 1
R7316,7317 00MGD05122160 RES, CARBON(1/5W,1.2Kohm,J) CRD20TJ122T 2
R7318,7319 nsp RES, M-OXIDE FILM(1W/270ohm) CRG1SANJ271RT 2
R7320 nsp RES, M-OXIDE FILM(2W/15Kohm) CRG2SANJ153RT 1
R7321 nsp RES, M-OXIDE FILM(1W/270ohm) CRG1SANJ271RT 1
R7324 00MGD05272160 RES, CARBON(1/5W,2.7Kohm,J) CRD20TJ272T 1
R7325 nsp RES, CARBON(1/5W,470ohm,J) CRD20TJ471T 1
R7326 00MGD05561160 RES, CARBON(1/5W,560ohm,J) CRD20TJ561T 1
R7329,7330 943124500240S RES, M-OXIDE FILM(1W/22ohm) CRG1SANJ220RT 2
R7331-7334 943124500050S RES, M-OXIDE FILM(2W/0.47ohm) CRG2SANJR47RT 4
R7335,7336 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 2
R7337 nsp RES, CARBON(1/5W,680Kohm,J) CRD20TJ684T 1
! R7338 252310006506S PTC THEMISTORS, CHIP(115'C) PRF18BB471QB5RB CRTPRF18BB471Q
B
1
R7339 nsp RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T 1
R7340 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R7341 00MNN05562610 RES, CHIP(1608/5%/5.6Kohm) CRJ10DJ562T 1
R7343 nsp RES, CHIP(3216/5%/47Kohm) CRJ14CJ473T 1
R7344 nsp RES, CHIP(3216/5%/22Kohm) CRJ14CJ223T 1
R7345 nsp RES, CARBON(1/5W,22Kohm,J) CRD20TJ223T 1
R7401 00MGD05122160 RES, CARBON(1/5W,1.2Kohm,J) CRD20TJ122T 1
R7402 00MGD05474160 RES, CARBON(1/5W,470Kohm,J) CRD20TJ474T 1
R7403 00MGD05333160 RES, CARBON(1/5W,33Kohm,J) CRD20TJ333T 1
R7405 nsp RES, M-OXIDE FILM(1W/1Kohm) CRG1SANJ102RT 1
R7406 nsp RES, CARBON(1/5W,470ohm,J) CRD20TJ471T 1
R7408 nsp RES, M-OXIDE FILM(1W/1Kohm) CRG1SANJ102RT 1
R7409,7410 nsp RES, CARBON(1/5W,220ohm,J) CRD20TJ221T 2
R7411 nsp RES, M-OXIDE FILM(1W/3.3Kohm) CRG1SANJ332RT 1
R7412 00MGD05333160 RES, CARBON(1/5W,33Kohm,J) CRD20TJ333T 1
R7414 nsp RES, M-OXIDE FILM(1W/56Kohm) CRG1SANJ563RT 1
R7416,7417 00MGD05122160 RES, CARBON(1/5W,1.2Kohm,J) CRD20TJ122T 2
R7418,7419 nsp RES, M-OXIDE FILM(1W/270ohm) CRG1SANJ271RT 2
R7420 nsp RES, M-OXIDE FILM(2W/15Kohm) CRG2SANJ153RT 1
R7421 nsp RES, M-OXIDE FILM(1W/270ohm) CRG1SANJ271RT 1
4

Denon AVR-X4000 Specifications

General

Receiver type	-
Frequency range	10 - 100000 Hz
Output impedance	16 Ω
Speaker selector	A+B
Input sensitivity	200 mV
Audio output channels	7.2 channels
Signal-to-Noise Ratio (SNR)	102 dB
Total Harmonic Distortion (THD)	0.008 %
Power output per channel (1KHz@6 Ohm)	165 W
Power output per channel (20-20KHz@8 Ohm)	125 W
HDMI in	7
AC (power) in	Yes
Composite video in	4
Ethernet LAN (RJ-45) ports	1
Component video (YPbPr/YCbCr) in	2
Number of HDMI outputs	3
Connectivity technology	Wired
Speakers connectivity type	Banana connector
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Wi-Fi	No
RDS features	PTY, TP
FM band range	87.5 - 108 MHz
Supported radio bands	FM
Internet radio services supported	Spotify, vTuner
Supported video modes	1080i, 1080p, 480p, 576p, 720p
Display	VFL
Color depth	24 bit
Aspect ratio	4:3, 16:9
Product color	Silver
Audio decoders	Dolby Digital, Dolby Digital EX, Dolby Digital Plus, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), DTS-HD, DTS-HD Master Audio
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Apple docking compatibility	Not supported
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	670 W

Weight and Dimensions

Depth	379 mm
Width	434 mm
Height	167 mm
Weight	12300 g
