Denon AVR-X4000 Service Manual

AMP
REF No. Part No. Part Name Remarks Q't
y
New
V
e
r
R7424 00MGD05272160 RES, CARBON(1/5W,2.7Kohm,J) CRD20TJ272T 1
R7425 nsp RES, CARBON(1/5W,470ohm,J) CRD20TJ471T 1
R7426 00MGD05561160 RES, CARBON(1/5W,560ohm,J) CRD20TJ561T 1
R7429,7430 943124500240S RES, M-OXIDE FILM(1W/22ohm) CRG1SANJ220RT 2
R7431-7434 943124500050S RES, M-OXIDE FILM(2W/0.47ohm) CRG2SANJR47RT 4
R7435,7436 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 2
R7437 nsp RES, CARBON(1/5W,680Kohm,J) CRD20TJ684T 1
! R7438 252310006506S PTC THEMISTORS, CHIP(115'C) PRF18BB471QB5RB CRTPRF18BB471Q
B
1
R7439 nsp RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T 1
R7440 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R7441 00MNN05562610 RES, CHIP(1608/5%/5.6Kohm) CRJ10DJ562T 1
R7443 nsp RES, CARBON(1/5W,47Kohm,J) CRD20TJ473T 1
R7444 nsp RES, CHIP(3216/5%/22Kohm) CRJ14CJ223T 1
R7445 nsp RES, CARBON(1/5W,22Kohm,J) CRD20TJ223T 1
R7501 00MGD05122160 RES, CARBON(1/5W,1.2Kohm,J) CRD20TJ122T 1
R7502 00MGD05474160 RES, CARBON(1/5W,470Kohm,J) CRD20TJ474T 1
R7503 00MGD05333160 RES, CARBON(1/5W,33Kohm,J) CRD20TJ333T 1
R7505 nsp RES, M-OXIDE FILM(1W/1Kohm) CRG1SANJ102RT 1
R7506 nsp RES, CARBON(1/5W,470ohm,J) CRD20TJ471T 1
R7508 nsp RES, M-OXIDE FILM(1W/1Kohm) CRG1SANJ102RT 1
R7509,7510 nsp RES, CARBON(1/5W,220ohm,J) CRD20TJ221T 2
R7511 nsp RES, M-OXIDE FILM(1W/3.3Kohm) CRG1SANJ332RT 1
R7512 00MGD05333160 RES, CARBON(1/5W,33Kohm,J) CRD20TJ333T 1
R7514 nsp RES, M-OXIDE FILM(1W/56Kohm) CRG1SANJ563RT 1
R7516,7517 00MGD05122160 RES, CARBON(1/5W,1.2Kohm,J) CRD20TJ122T 2
R7518,7519 nsp RES, M-OXIDE FILM(1W/270ohm) CRG1SANJ271RT 2
R7520 nsp RES, M-OXIDE FILM(2W/15Kohm) CRG2SANJ153RT 1
R7521 nsp RES, M-OXIDE FILM(1W/270ohm) CRG1SANJ271RT 1
R7524 00MGD05272160 RES, CARBON(1/5W,2.7Kohm,J) CRD20TJ272T 1
R7525 nsp RES, CARBON(1/5W,470ohm,J) CRD20TJ471T 1
R7526 00MGD05561160 RES, CARBON(1/5W,560ohm,J) CRD20TJ561T 1
R7529,7530 943124500240S RES, M-OXIDE FILM(1W/22ohm) CRG1SANJ220RT 2
R7531-7534 943124500050S RES, M-OXIDE FILM(2W/0.47ohm) CRG2SANJR47RT 4
R7535,7536 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 2
R7537 nsp RES, CARBON(1/5W,680Kohm,J) CRD20TJ684T 1
! R7538 252310006506S PTC THEMISTORS, CHIP(115'C) PRF18BB471QB5RB CRTPRF18BB471Q
B
1
R7539 nsp RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T 1
R7540 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R7541 00MNN05562610 RES, CHIP(1608/5%/5.6Kohm) CRJ10DJ562T 1
R7543 nsp RES, CHIP(3216/5%/47Kohm) CRJ14CJ473T 1
R7544 nsp RES, CHIP(3216/5%/22Kohm) CRJ14CJ223T 1
R7545 nsp RES, CARBON(1/5W,22Kohm,J) CRD20TJ223T 1
R7601 00MGD05122160 RES, CARBON(1/5W,1.2Kohm,J) CRD20TJ122T 1
R7602 00MGD05474160 RES, CARBON(1/5W,470Kohm,J) CRD20TJ474T 1
R7603 00MGD05333160 RES, CARBON(1/5W,33Kohm,J) CRD20TJ333T 1
R7605 nsp RES, M-OXIDE FILM(1W/1Kohm) CRG1SANJ102RT 1
R7606 nsp RES, CARBON(1/5W,470ohm,J) CRD20TJ471T 1
R7608 nsp RES, M-OXIDE FILM(1W/1Kohm) CRG1SANJ102RT 1
R7609,7610 nsp RES, CARBON(1/5W,220ohm,J) CRD20TJ221T 2
R7611 nsp RES, M-OXIDE FILM(1W/3.3Kohm) CRG1SANJ332RT 1
R7612 00MGD05333160 RES, CARBON(1/5W,33Kohm,J) CRD20TJ333T 1
R7614 nsp RES, M-OXIDE FILM(1W/56Kohm) CRG1SANJ563RT 1
R7616,7617 00MGD05122160 RES, CARBON(1/5W,1.2Kohm,J) CRD20TJ122T 2
R7618,7619 nsp RES, M-OXIDE FILM(1W/270ohm) CRG1SANJ271RT 2
R7620 nsp RES, M-OXIDE FILM(2W/15Kohm) CRG2SANJ153RT 1
R7621 nsp RES, M-OXIDE FILM(1W/270ohm) CRG1SANJ271RT 1
R7624 00MGD05272160 RES, CARBON(1/5W,2.7Kohm,J) CRD20TJ272T 1
R7625 nsp RES, CARBON(1/5W,470ohm,J) CRD20TJ471T 1
R7626 00MGD05561160 RES, CARBON(1/5W,560ohm,J) CRD20TJ561T 1
R7629,7630 943124500240S RES, M-OXIDE FILM(1W/22ohm) CRG1SANJ220RT 2
R7631-7634 943124500050S RES, M-OXIDE FILM(2W/0.47ohm) CRG2SANJR47RT 4
R7635,7636 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 2
R7637 nsp RES, CARBON(1/5W,680Kohm,J) CRD20TJ684T 1
! R7638 252310006506S PTC THEMISTORS, CHIP(115'C) PRF18BB471QB5RB CRTPRF18BB471Q
B
1
R7639 nsp RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T 1
R7640 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R7641 00MNN05562610 RES, CHIP(1608/5%/5.6Kohm) CRJ10DJ562T 1
R7643 nsp RES, CHIP(3216/5%/47Kohm) CRJ14CJ473T 1
R7644 nsp RES, CHIP(3216/5%/22Kohm) CRJ14CJ223T 1
R7655 nsp RES, CARBON(1/5W,22Kohm,J) CRD20TJ223T 1
R7701 00MGD05122160 RES, CARBON(1/5W,1.2Kohm,J) CRD20TJ122T 1
R7702 00MGD05474160 RES, CARBON(1/5W,470Kohm,J) CRD20TJ474T 1
R7703 00MGD05333160 RES, CARBON(1/5W,33Kohm,J) CRD20TJ333T 1
R7705 nsp RES, M-OXIDE FILM(1W/1Kohm) CRG1SANJ102RT 1
R7706 nsp RES, CARBON(1/5W,470ohm,J) CRD20TJ471T 1
R7708 nsp RES, M-OXIDE FILM(1W/1Kohm) CRG1SANJ102RT 1
R7709,7710 nsp RES, CARBON(1/5W,220ohm,J) CRD20TJ221T 2
R7711 nsp RES, M-OXIDE FILM(1W/3.3Kohm) CRG1SANJ332RT 1
R7712 00MGD05333160 RES, CARBON(1/5W,33Kohm,J) CRD20TJ333T 1
R7714 nsp RES, M-OXIDE FILM(1W/56Kohm) CRG1SANJ563RT 1
R7716,7717 00MGD05122160 RES, CARBON(1/5W,1.2Kohm,J) CRD20TJ122T 2
R7718,7719 nsp RES, M-OXIDE FILM(1W/270ohm) CRG1SANJ271RT 2
R7720 nsp RES, M-OXIDE FILM(2W/15Kohm) CRG2SANJ153RT 1
R7721 nsp RES, M-OXIDE FILM(1W/270ohm) CRG1SANJ271RT 1
R7724 00MGD05272160 RES, CARBON(1/5W,2.7Kohm,J) CRD20TJ272T 1
R7725 nsp RES, CARBON(1/5W,470ohm,J) CRD20TJ471T 1
R7726 00MGD05561160 RES, CARBON(1/5W,560ohm,J) CRD20TJ561T 1
R7729,7730 943124500240S RES, M-OXIDE FILM(1W/22ohm) CRG1SANJ220RT 2
R7731-7734 943124500050S RES, M-OXIDE FILM(2W/0.47ohm) CRG2SANJR47RT 4
R7735,7736 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 2
R7737 nsp RES, CARBON(1/5W,680Kohm,J) CRD20TJ684T 1
! R7738 252310006506S PTC THEMISTORS, CHIP(115'C) PRF18BB471QB5RB CRTPRF18BB471Q
B
1
R7739 nsp RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T 1
R7740 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R7741 00MNN05562610 RES, CHIP(1608/5%/5.6Kohm) CRJ10DJ562T 1
R7743 nsp RES, CHIP(3216/5%/47Kohm) CRJ14CJ473T 1
R7744 nsp RES, CHIP(3216/5%/22Kohm) CRJ14CJ223T 1
R7745 nsp RES, CARBON(1/5W,22Kohm,J) CRD20TJ223T 1
VR714 963161012400S RES ,SEMI FIXED(1K/B-CURVE) ANGLE PANASONIC CVN1RE102B01T 1
VR724 963161012400S RES ,SEMI FIXED(1K/B-CURVE) ANGLE PANASONIC CVN1RE102B01T 1
VR734 963161012400S RES ,SEMI FIXED(1K/B-CURVE) ANGLE PANASONIC CVN1RE102B01T 1
VR744 963161012400S RES ,SEMI FIXED(1K/B-CURVE) ANGLE PANASONIC CVN1RE102B01T 1
VR754 963161012400S RES ,SEMI FIXED(1K/B-CURVE) ANGLE PANASONIC CVN1RE102B01T 1
VR764 963161012400S RES ,SEMI FIXED(1K/B-CURVE) ANGLE PANASONIC CVN1RE102B01T 1
VR774 963161012400S RES ,SEMI FIXED(1K/B-CURVE) ANGLE PANASONIC CVN1RE102B01T 1
CAPACIITORS GROUP
5

Denon AVR-X4000 Specifications

General

Receiver type	-
Frequency range	10 - 100000 Hz
Output impedance	16 Ω
Speaker selector	A+B
Input sensitivity	200 mV
Audio output channels	7.2 channels
Signal-to-Noise Ratio (SNR)	102 dB
Total Harmonic Distortion (THD)	0.008 %
Power output per channel (1KHz@6 Ohm)	165 W
Power output per channel (20-20KHz@8 Ohm)	125 W
HDMI in	7
AC (power) in	Yes
Composite video in	4
Ethernet LAN (RJ-45) ports	1
Component video (YPbPr/YCbCr) in	2
Number of HDMI outputs	3
Connectivity technology	Wired
Speakers connectivity type	Banana connector
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Wi-Fi	No
RDS features	PTY, TP
FM band range	87.5 - 108 MHz
Supported radio bands	FM
Internet radio services supported	Spotify, vTuner
Supported video modes	1080i, 1080p, 480p, 576p, 720p
Display	VFL
Color depth	24 bit
Aspect ratio	4:3, 16:9
Product color	Silver
Audio decoders	Dolby Digital, Dolby Digital EX, Dolby Digital Plus, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), DTS-HD, DTS-HD Master Audio
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Apple docking compatibility	Not supported
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	670 W

Weight and Dimensions

Depth	379 mm
Width	434 mm
Height	167 mm
Weight	12300 g
