Denon AVR-X4000 Service Manual

INPUT
INPUT PCB ASS'
Y
※Parts indicated b
y
"ns
p
" on this table cannot be su
pp
lied.
※The
p
arts listed below are onl
y
for maintenance. Therefore the
y
mi
g
ht differ from the
p
arts used in the unit in a
pp
earances or dimensions.
NOTE:The symbols in the column Remarks indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model E1C : China model E1 : Asia model K : Japan model
BK : Black model SP : Premium Silver model
REF No. Part No. Part Name Remarks Q't
y
New
V
e
r
SEMICONDUCTORS GROUP
D6803 963209003510S DIODE , RELIABLE ESD PROTECTION CDS3C05HDMI1 CVDCDS3C05HDMI
1
1
D6835,6836 963209003510S DIODE , RELIABLE ESD PROTECTION CDS3C05HDMI1 CVDCDS3C05HDMI
1
2
D8795 943209001080S DIODE , CHIP , SWITCHING 1SS355/HOMI(HK) COMPANY LTD CVD1SS355T 1
D8797-8800 943209001080S DIODE , CHIP , SWITCHING 1SS355/HOMI(HK) COMPANY LTD CVD1SS355T 4
D8845-8847 943203003150S DIODE , RECTIFIER, RADIAL CVD1N4007SRT 3
D8848 943202500720S DIODE , ZENER(3.6V/0.5W, SOD-123) CVDMM1Z3V6H 1
IC466 943232100380S I.C , DUAL OPAMP(SOP-8P) NJM8080G CVINJM8080G 1
IC471 235810045600S I.C , 8CH VOLUME RENESAS CVIR2A15220FP 1
IC481-483 943232100380S I.C , DUAL OPAMP(SOP-8P) NJM8080G CVINJM8080G 3
IC484 943236101540D I.C , FUNCTION SWITCH(SSOP-32) BD3841FS ROHM CVIBD3841FSE2 1 *
IC486-488 943232100380S I.C , DUAL OPAMP(SOP-8P) NJM8080G CVINJM8080G 3
IC491 943235003810S I.C , INPUT WITH 8CH VOLUME(100P QFP) RENESAS CVIR2A15218FP 1
Q8713 943215500030S T.R,RT1P441C(47K-47K) RT1P441C(PNP,SC-59,SISAHAYA CVTRT1P441C 1
Q8714 943216500050S T.R,RT1N441C(47K-47K) RT1N441C(NPN,SC-59,SISAHAYA CVTRT1N441C 1
Q8717,8718 943214500030S T.R , MUTE INC2001AC1(NPN,SC-59ISAHAYA CVTINC2001AC1 2
Q8720 943215500030S T.R,RT1P441C(47K-47K) RT1P441C(PNP,SC-59,SISAHAYA CVTRT1P441C 1
Q8733 943215500030S T.R,RT1P441C(47K-47K) RT1P441C(PNP,SC-59,SISAHAYA CVTRT1P441C 1
Q8734 943216500050S T.R,RT1N441C(47K-47K) RT1N441C(NPN,SC-59,SISAHAYA CVTRT1N441C 1
Q8737,8738 943214500030S T.R , MUTE INC2001AC1(NPN,SC-59ISAHAYA CVTINC2001AC1 2
Q8740 943215500030S T.R,RT1P441C(47K-47K) RT1P441C(PNP,SC-59,SISAHAYA CVTRT1P441C 1
Q8753 943215500030S T.R,RT1P441C(47K-47K) RT1P441C(PNP,SC-59,SISAHAYA CVTRT1P441C 1
Q8754 943216500050S T.R,RT1N441C(47K-47K) RT1N441C(NPN,SC-59,SISAHAYA CVTRT1N441C 1
Q8757,8758 943214500030S T.R , MUTE INC2001AC1(NPN,SC-59ISAHAYA CVTINC2001AC1 2
Q8760 943215500030S T.R,RT1P441C(47K-47K) RT1P441C(PNP,SC-59,SISAHAYA CVTRT1P441C 1
Q8795 943213500160S T.R,RT1N237C(2.2K-47K) RT1N237C(NPN,SC-59,SISAHAYA CVTRT1N237C 1
Q8797-8800 943213500160S T.R,RT1N237C(2.2K-47K) RT1N237C(NPN,SC-59,SISAHAYA CVTRT1N237C 4
Q8813 943215500030S T.R,RT1P441C(47K-47K) RT1P441C(PNP,SC-59,SISAHAYA CVTRT1P441C 1
Q8814 943216500050S T.R,RT1N441C(47K-47K) RT1N441C(NPN,SC-59,SISAHAYA CVTRT1N441C 1
Q8817 943214500030S T.R , MUTE INC2001AC1(NPN,SC-59ISAHAYA CVTINC2001AC1 1
Q8820 943215500030S T.R,RT1P441C(47K-47K) RT1P441C(PNP,SC-59,SISAHAYA CVTRT1P441C 1
Q8863 943215500030S T.R,RT1P441C(47K-47K) RT1P441C(PNP,SC-59,SISAHAYA CVTRT1P441C 1
Q8864 943216500050S T.R,RT1N441C(47K-47K) RT1N441C(NPN,SC-59,SISAHAYA CVTRT1N441C 1
Q8870 943215500030S T.R,RT1P441C(47K-47K) RT1P441C(PNP,SC-59,SISAHAYA CVTRT1P441C 1
Q8923 943215500030S T.R,RT1P441C(47K-47K) RT1P441C(PNP,SC-59,SISAHAYA CVTRT1P441C 1
Q8924 943216500050S T.R,RT1N441C(47K-47K) RT1N441C(NPN,SC-59,SISAHAYA CVTRT1N441C 1
Q8927,8928 943214500030S T.R , MUTE INC2001AC1(NPN,SC-59ISAHAYA CVTINC2001AC1 2
Q8930 943215500030S T.R,RT1P441C(47K-47K) RT1P441C(PNP,SC-59,SISAHAYA CVTRT1P441C 1
Q8973 943215500030S T.R,RT1P441C(47K-47K) RT1P441C(PNP,SC-59,SISAHAYA CVTRT1P441C 1
Q8974 943216500050S T.R,RT1N441C(47K-47K) RT1N441C(NPN,SC-59,SISAHAYA CVTRT1N441C 1
Q8977,8978 943214500030S T.R , MUTE INC2001AC1(NPN,SC-59ISAHAYA CVTINC2001AC1 2
Q8980 943215500030S T.R,RT1P441C(47K-47K) RT1P441C(PNP,SC-59,SISAHAYA CVTRT1P441C 1
RESISTOR GROUP
! R2396 252310006537S PTC THEMISTORS, CHIP(85'C) PRF18BE471QB5RB BRAND CRTPRF18BE471Q
B
1
! R2399 252310006537S PTC THEMISTORS, CHIP(85'C) PRF18BE471QB5RB BRAND CRTPRF18BE471Q
B
1
R4601,4602 nsp RES, CHIP(1608/5%/470ohm) CRJ10DJ471T 2
R4603,4604 nsp RES, CHIP(1608/5%/51Kohm) CRJ10DJ513T 2
R4605,4606 nsp RES, CHIP(1608/5%/470ohm) CRJ10DJ471T 2
R4607,4608 nsp RES, CHIP(1608/5%/51Kohm) CRJ10DJ513T 2
R4609,4610 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 2
R4611,4612 nsp RES, CHIP(1608/5%/470ohm) CRJ10DJ471T 2
R4613,4614 nsp RES, CHIP(1608/5%/51Kohm) CRJ10DJ513T 2
R4615,4616 nsp RES, CHIP(1608/5%/470ohm) CRJ10DJ471T 2
R4617,4618 nsp RES, CHIP(1608/5%/51Kohm) CRJ10DJ513T 2
R4619,4620 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 2
R4625,4626 nsp RES, CHIP(1608/5%/470ohm) CRJ10DJ471T 2
R4627,4628 nsp RES, CHIP(1608/5%/51Kohm) CRJ10DJ513T 2
R4629,4630 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 2
R4633,4634 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 2
R4637,4638 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 2
R4643,4644 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 2
R4647,4648 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 2
R4661 nsp RES, CHIP(1608/5%/0ohm) E3/K CRJ10DJ0R0T 1
R4661 nsp RES, CHIP(1608/5%/4.7ohm) E2/E1C CRJ10DJ4R7T 1
R4662 nsp RES, CHIP(1608/5%/0ohm) E3/K CRJ10DJ0R0T 1
R4662 nsp RES, CHIP(1608/5%/4.7ohm) E2/E1C CRJ10DJ4R7T 1
R4663,4664 nsp RES, CHIP(1608/5%/390ohm) CRJ10DJ391T 2
R4665,4666 nsp RES, CHIP(1608/5%/68Kohm) CRJ10DJ683T 2
R4667,4668 nsp RES, CHIP(1608/5%/150Kohm) CRJ10DJ154T 2
R4669,4670 nsp RES, CHIP(1608/5%/47ohm) CRJ10DJ470T 2
R4671,4672 nsp RES, CHIP(1608/5%/240ohm) CRJ10DJ241T 2
R4679,4680 nsp RES, CHIP(1608/5%/130Kohm) CRJ10DJ134T 2
R4681,4682 nsp RES, CHIP(1608/5%/11Kohm) CRJ10DJ113T 2
R4683,4684 nsp RES, CHIP(1608/5%/22ohm) CRJ10DJ220T 2
R4685,4686 nsp RES, CHIP(1608/5%/47ohm) CRJ10DJ470T 2
R4687,4688 nsp RES, CHIP(1608/5%/470Kohm) CRJ10DJ474T 2
R4697-4699 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 3
R4701-4705 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 5
R4707 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R4709-4716 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 8
R4719,4720 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 2
R4721,4722 nsp RES, CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 2
R4737,4738 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 2
R4743-4746 nsp RES, CHIP(1608/5%/47Kohm) CRJ10DJ473T 4
R4757,4758 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 2
R4761-4771 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 11
R4773,4774 nsp RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T 2
R4777,4778 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 2
R4781-4784 nsp RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T 4
R4794-4799 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 6
R4801,4802 nsp RES, CHIP(1608/5%/470Kohm) CRJ10DJ474T 2
R4803,4804 nsp RES, CHIP(1608/5%/150Kohm) CRJ10DJ154T 2
R4805,4806 nsp RES, CHIP(1608/5%/270Kohm) CRJ10DJ274T 2
R4807,4808 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 2
R4811,4812 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 2
R4813,4814 nsp RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T 2
R4815-4818 nsp RES, CHIP(1608/5%/68Kohm) CRJ10DJ683T 4
9

Denon AVR-X4000 Specifications

General

Receiver type	-
Frequency range	10 - 100000 Hz
Output impedance	16 Ω
Speaker selector	A+B
Input sensitivity	200 mV
Audio output channels	7.2 channels
Signal-to-Noise Ratio (SNR)	102 dB
Total Harmonic Distortion (THD)	0.008 %
Power output per channel (1KHz@6 Ohm)	165 W
Power output per channel (20-20KHz@8 Ohm)	125 W
HDMI in	7
AC (power) in	Yes
Composite video in	4
Ethernet LAN (RJ-45) ports	1
Component video (YPbPr/YCbCr) in	2
Number of HDMI outputs	3
Connectivity technology	Wired
Speakers connectivity type	Banana connector
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Wi-Fi	No
RDS features	PTY, TP
FM band range	87.5 - 108 MHz
Supported radio bands	FM
Internet radio services supported	Spotify, vTuner
Supported video modes	1080i, 1080p, 480p, 576p, 720p
Display	VFL
Color depth	24 bit
Aspect ratio	4:3, 16:9
Product color	Silver
Audio decoders	Dolby Digital, Dolby Digital EX, Dolby Digital Plus, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), DTS-HD, DTS-HD Master Audio
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Apple docking compatibility	Not supported
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	670 W

Weight and Dimensions

Depth	379 mm
Width	434 mm
Height	167 mm
Weight	12300 g
