Denon AVR-X4000 Service Manual

INPUT
REF No. Part No. Part Name Remarks Q't
y
New
V
e
r
R4819,4820 nsp RES, CHIP(1608/5%/33Kohm) CRJ10DJ333T 2
R4821-4824 nsp RES, CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 4
R4825,4826 nsp RES, CHIP(1608/5%/47ohm) CRJ10DJ470T 2
R4827,4828 nsp RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T 2
R4831,4832 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 2
R4833-4836 nsp RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T 4
R4851,4852 nsp RES, CHIP(1608/5%/470Kohm) CRJ10DJ474T 2
R4853,4854 nsp RES, CHIP(1608/5%/150Kohm) CRJ10DJ154T 2
R4855,4856 nsp RES, CHIP(1608/5%/270Kohm) CRJ10DJ274T 2
R4857,4858 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 2
R4861,4862 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 2
R4863,4864 nsp RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T 2
R4865-4868 nsp RES, CHIP(1608/5%/68Kohm) CRJ10DJ683T 4
R4869,4870 nsp RES, CHIP(1608/5%/33Kohm) CRJ10DJ333T 2
R4871-4874 nsp RES, CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 4
R4875,4876 nsp RES, CHIP(1608/5%/47ohm) CRJ10DJ470T 2
R4877,4878 nsp RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T 2
R4881,4882 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 2
R4883-4886 nsp RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T 4
R4893,4894 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 2
R4901-4908 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 8
R4911-4914 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 4
R4921 nsp RES, CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 1
R4924 nsp RES, CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 1
R4931-4934 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 4
R4951,4952 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 2
R6803 nsp RES, CHIP(1608/5%/2.2Kohm) CRJ10DJ222T 1
R6837,6838 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 2
R6841,6842 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 2
R8681-8691 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 11
R8701,8702 nsp RES, CHIP(1608/5%/470Kohm) CRJ10DJ474T 2
R8703-8706 nsp RES, CHIP(1608/5%/470ohm) CRJ10DJ471T 4
R8707-8710 nsp RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T 4
R8711,8712 nsp RES, CHIP(1608/5%/220ohm) CRJ10DJ221T 2
R8713 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R8717,8718 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 2
R8719 nsp RES, CHIP(1608/5%/470Kohm) CRJ10DJ474T 1
R8720 nsp RES, CHIP(1608/5%/1Kohm) CRJ10DJ102T 1
R8721,8722 nsp RES, CHIP(1608/5%/470Kohm) CRJ10DJ474T 2
R8723-8726 nsp RES, CHIP(1608/5%/470ohm) CRJ10DJ471T 4
R8727-8730 nsp RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T 4
R8731,8732 nsp RES, CHIP(1608/5%/220ohm) CRJ10DJ221T 2
R8733 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R8737,8738 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 2
R8739 nsp RES, CHIP(1608/5%/470Kohm) CRJ10DJ474T 1
R8740 nsp RES, CHIP(1608/5%/1Kohm) CRJ10DJ102T 1
R8741,8742 nsp RES, CHIP(1608/5%/470Kohm) CRJ10DJ474T 2
R8743-8746 nsp RES, CHIP(1608/5%/470ohm) CRJ10DJ471T 4
R8747-8750 nsp RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T 4
R8751,8752 nsp RES, CHIP(1608/5%/220ohm) CRJ10DJ221T 2
R8753 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R8757,8758 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 2
R8759 nsp RES, CHIP(1608/5%/470Kohm) CRJ10DJ474T 1
R8760 nsp RES, CHIP(1608/5%/1Kohm) CRJ10DJ102T 1
R8767-8770 nsp RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T 4
R8771,8772 nsp RES, CHIP(1608/5%/1.2Kohm) CRJ10DJ122T 2
R8787-8790 nsp RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T 4
R8791,8792 nsp RES, CHIP(1608/5%/1.2Kohm) CRJ10DJ122T 2
R8793 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R8795-8800 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 6
R8801 nsp RES, CHIP(1608/5%/470Kohm) CRJ10DJ474T 1
R8803 nsp RES, CHIP(1608/5%/470ohm) CRJ10DJ471T 1
R8805 nsp RES, CHIP(1608/5%/470ohm) CRJ10DJ471T 1
R8807 nsp RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T 1
R8809 nsp RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T 1
R8811 nsp RES, CHIP(1608/5%/220ohm) CRJ10DJ221T 1
R8813 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R8817 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R8819 nsp RES, CHIP(1608/5%/470Kohm) CRJ10DJ474T 1
R8820 nsp RES, CHIP(1608/5%/1Kohm) CRJ10DJ102T 1
R8846 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R8848 nsp RES, CHIP(1608/5%/820ohm) CRJ10DJ821T 1
R8849 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R8851,8852 nsp RES, CHIP(1608/5%/470Kohm) CRJ10DJ474T 2
R8853,8854 nsp RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T 2
R8855,8856 nsp RES, CHIP(1608/5%/470ohm) CRJ10DJ471T 2
R8863 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R8869 nsp RES, CHIP(1608/5%/470Kohm) CRJ10DJ474T 1
R8870 nsp RES, CHIP(1608/5%/1Kohm) CRJ10DJ102T 1
R8901,8902 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 2
R8911,8912 nsp RES, CHIP(1608/5%/470Kohm) CRJ10DJ474T 2
R8913-8916 nsp RES, CHIP(1608/5%/470ohm) CRJ10DJ471T 4
R8917-8920 nsp RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T 4
R8921,8922 nsp RES, CHIP(1608/5%/220ohm) CRJ10DJ221T 2
R8923 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R8927,8928 nsp RES, CHIP(1608/5%/10Kohm)
CRJ10DJ103T 2
R8929
nsp
RES, CHIP(1608/5%/470Kohm) CRJ10DJ474T 1
R8930 nsp RES, CHIP(1608/5%/1Kohm) CRJ10DJ102T 1
R8951,8952 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 2
R8961,8962 nsp RES, CHIP(1608/5%/470Kohm) CRJ10DJ474T 2
R8963-8966 nsp RES, CHIP(1608/5%/470ohm) CRJ10DJ471T 4
R8967-8970 nsp RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T 4
R8971,8972 nsp RES, CHIP(1608/5%/220ohm) CRJ10DJ221T 2
R8973 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R8977,8978 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 2
R8979 nsp RES, CHIP(1608/5%/470Kohm) CRJ10DJ474T 1
R8980 nsp RES, CHIP(1608/5%/1Kohm) CRJ10DJ102T 1
R8991-8996 nsp RES, CHIP(1608/5%/820Kohm) CRJ10DJ824T 6
CAPACIITORS GROUP
C4603,4604 nsp CAP, CHIP(1608, 50V/330pF) CCUS1H331JA 2
C4607,4608 nsp CAP, CHIP(1608, 50V/330pF) CCUS1H331JA 2
C4613,4614 nsp CAP, CHIP(1608, 50V/330pF) CCUS1H331JA 2
C4617,4618 nsp CAP, CHIP(1608, 50V/330pF) CCUS1H331JA 2
C4627,4628 nsp CAP, CHIP(1608, 50V/330pF) CCUS1H331JA 2
C4641 00D9430148708 CAP, ELECT(50V/47uF) CCEA1HH470T 1
C4661,4662 nsp CAP, CHIP(1608, 50V/100pF) E2/E1C CCUS1H101JA 2
10

Denon AVR-X4000 Specifications

General

Receiver type	-
Frequency range	10 - 100000 Hz
Output impedance	16 Ω
Speaker selector	A+B
Input sensitivity	200 mV
Audio output channels	7.2 channels
Signal-to-Noise Ratio (SNR)	102 dB
Total Harmonic Distortion (THD)	0.008 %
Power output per channel (1KHz@6 Ohm)	165 W
Power output per channel (20-20KHz@8 Ohm)	125 W
HDMI in	7
AC (power) in	Yes
Composite video in	4
Ethernet LAN (RJ-45) ports	1
Component video (YPbPr/YCbCr) in	2
Number of HDMI outputs	3
Connectivity technology	Wired
Speakers connectivity type	Banana connector
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Wi-Fi	No
RDS features	PTY, TP
FM band range	87.5 - 108 MHz
Supported radio bands	FM
Internet radio services supported	Spotify, vTuner
Supported video modes	1080i, 1080p, 480p, 576p, 720p
Display	VFL
Color depth	24 bit
Aspect ratio	4:3, 16:9
Product color	Silver
Audio decoders	Dolby Digital, Dolby Digital EX, Dolby Digital Plus, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), DTS-HD, DTS-HD Master Audio
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Apple docking compatibility	Not supported
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	670 W

Weight and Dimensions

Depth	379 mm
Width	434 mm
Height	167 mm
Weight	12300 g
