Denon AVR-X4000 - Page 220

DIGITAL
REF No. Part No. Part Name Remarks Q't
y
New
V
e
r
C5506 nsp CAP, CHIP(1005, 16V/0.1uF) CCUI1C104KC 1
C5507 943134005160M CAP, SMD ELECT(6.3V/22uF) HCEC0JRV2220T 1
C5508,5509 nsp CAP, CHIP(1005, 16V/0.1uF) CCUI1C104KC 2
C5510 nsp CAP, CHIP(1608, 6.3V/2.2uF) CCUS0J225KC 1
C5511 nsp CAP, CHIP(1005, 16V/0.1uF) CCUI1C104KC 1
C5512 nsp CAP, CHIP(1608, 6.3V/2.2uF) CCUS0J225KC 1
C5513 nsp CAP, CHIP(1005, 16V/0.1uF) CCUI1C104KC 1
C5514 nsp CAP, CHIP(2012, 6.3V/10uF, X7R) CCUC0J106KC 1
C5515,5516 nsp CAP, CHIP(1005, 50V/2200pF) CCUI1H222KC 2
C5517,5518 nsp CAP, CHIP(1005, 16V/0.1uF) CCUI1C104KC 2
C5519 nsp CAP, CHIP(1608, 6.3V/2.2uF) CCUS0J225KC 1
C5520 nsp CAP, CHIP(1005, 16V/0.1uF) CCUI1C104KC 1
C5521 nsp CAP, CHIP(1608, 6.3V/2.2uF) CCUS0J225KC 1
C5522 nsp CAP, CHIP(1005, 16V/0.1uF) CCUI1C104KC 1
C5523 nsp CAP, CHIP(2012, 6.3V/10uF, X7R) CCUC0J106KC 1
C5524,5525 nsp CAP, CHIP(1005, 50V/2200pF) CCUI1H222KC 2
OTHER PARTS GROUP
BD401 nsp FERRITE CHIP BEAD(2012/220R, CB05YTYH221) CLZ9R018V 1
BK101-103 nsp BRACKET , PCB CMD1A569-V1 3
BK104 nsp EARTH , HDMI CMC2A432 1
BN21A nsp PIN SOCKET (19P,1.25mm,ANGLE, B-TO-B) C125Z2/COSMOS CJP19HJ282Z 1
BN23A,24 nsp PIN SOCKET (27P,1.25mm,ANGLE,B-TO-B) C125Z2/COSMOS CJP27HJ282Z 2
BN25A nsp PIN SOCKET (19P,1.25mm,ANGLE, B-TO-B) C125Z2/COSMOS CJP19HJ282Z 1
BN26A nsp PIN SOCKET (13P,1.25mm,ANGLE, B-TO-B) C125Z2/COSMOS CJP13HJ282Z 1
BN27A nsp PIN SOCKET (17P,1.25mm,ANGLE,B-TO-B) C125Z2/COSMOS CJP17HJ282Z 1
CN101 nsp WAFER, FFC, SMD(23P-1mm, STRAIGHT) CJP23GA193ZY 1
CN121 nsp WAFER, FFC, SMD(23P-1mm, STRAIGHT) CJP23GA193ZY 1
CN151 nsp WAFER, FFC, SMD(07P-1mm, STRAIGHT) CJP07GA193ZY 1
CN201 nsp WAFER, FFC, SMD(07P-1mm, STRAIGHT) CJP07GA193ZY 1
CN202 nsp WAFER, FFC, SMD(11P-1mm, STRAIGHT) CJP11GA193ZY 1
CN203 nsp WAFER , SMD (2MM PITCH)-3P 20022WS-03C CJP03GA208ZY 1
CN231 nsp WAFER, FFC, SMD(11P-1mm, STRAIGHT) CJP11GA193ZY 1
CN321 nsp WAFER , SMD (2MM PITCH) 20022WS-NN CJP05GA208ZY 1
CN390 nsp WAFER, FFC, SMD(07P-1mm, STRAIGHT) CJP07GA193ZY 1
CN391 nsp WAFER , SMD (2MM PITCH) 20022WS-NN CJP06GA208ZY 1
CN401 nsp WAFER, FFC, SMD(07P-1mm, STRAIGHT) CJP07GA193ZY 1
CN402,403 nsp WAFER, FFC, SMD(11P-1mm, STRAIGHT) CJP11GA193ZY 2
CN404,405 nsp WAFER, FFC, SMD(07P-1mm, STRAIGHT) CJP07GA193ZY 2
CN69B nsp WAFER, FFC, SMD(40P-1mm, STRAIGHT) CJP40GA193ZY 1
CN704 nsp WAFER , SMD (2MM PITCH) 20022WS-NN CJP05GA208ZY 1
CN903 nsp LOCK-WAFER/STRAIGHT/2.5MM PITCH/5PIN SMW250-05 CJP05GI289ZY 1
J3200 943643102430S JACK , RJ-45 W/TRANSFORMER KRJ-015XXNL CJJ9L029Z 1
JK101 943644101840D JACK, HDMI(KSI-TWI, W/O FLANGE) AD3PBJ19G0 CJJ9H017Z 1 *
JK151,152 943643100040S JACK, HDMI(KSI-TWI, W/ FLANGE) AD3PBC19G0 CJJ9H016Z 2
JK401 943643101110S JACK, 2P(ORG),SILVER RCA-215A-00-01/YUQIU CJJ4N068Y 1
JK402,403 943262100150S MODULE , OPTICAL(RX 16MHz) CJSJSR1124 2
JK404 943643101920S JACK , RCA (1P, BK, GOLD PLATE) RJ-0111R-29T CJJ4M073ZY 1
JK501-507 943643100040S JACK, HDMI(KSI-TWI, W/ FLANGE) AD3PBC19G0 CJJ9H016Z 7
L1001,1002 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 2
L1201-1213 nsp FERRITE CHIP BEAD(2012/220R) BLM21PG221SN1/MURATA CLZBLM21PG221SN1 13
L1501-1508 nsp FERRITE CHIP BEAD(1608/60R, CB03YTYH600) CB03YTYH600 CLZ9R005V 8 *
L1510 nsp FERRITE CHIP BEAD(1608/60R, CB03YTYH600) CB03YTYH600 CLZ9R005V 1 *
L1512 nsp FERRITE CHIP BEAD(1608/60R, CB03YTYH600) CB03YTYH600 CLZ9R005V 1 *
L1514 nsp FERRITE CHIP BEAD(1608/60R, CB03YTYH600) CB03YTYH600 CLZ9R005V 1 *
L1518 nsp FERRITE CHIP BEAD(1608/60R, CB03YTYH600) CB03YTYH600 CLZ9R005V 1 *
L1521,1522 nsp FERRITE CHIP BEAD(1608/60R, CB03YTYH600) CB03YTYH600 CLZ9R005V 2 *
L2903-2907 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 5
L2908 nsp FERRITE CHIP BEAD(1608/60R, CB03YTYH600) CB03YTYH600 CLZ9R005V 1 *
L2909 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
L2910 nsp FERRITE CHIP BEAD(1608/60R, CB03YTYH600) CB03YTYH600 CLZ9R005V 1 *
L2911-2913 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 3
L2914,2915 nsp FERRITE CHIP BEAD(1608/60R, CB03YTYH600) CB03YTYH600 CLZ9R005V 2 *
L2916-2920 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 5
L2922-2925 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 4
L2929-2934 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 6
L3001-3018 nsp FERRITE CHIP BEAD(2012/220R, CB05YTYH221) CB05YTYH221 CLZ9R018V 18 *
L3019-3021 nsp FERRITE CHIP BEAD(2012/220R) BLM21PG221SN1/MURATA CLZBLM21PG221SN1 3
L3022 nsp FERRITE CHIP BEAD(2012/120R) BLM21AG121SN1/MURATA CLZBLM21AG121SN1 1
L3023-3032 nsp FERRITE CHIP BEAD(2012/220R, CB05YTYH221) CB05YTYH221 CLZ9R018V 10 *
L3200,3201 nsp COIL, CHOKE CHIP(2012/90R) DLW21SN900SQ2L/MURATA CLZ9Z128Z 2
L3205,3206 nsp FERRITE CHIP BEAD(2012/220R, CB05YTYH221) CB05YTYH221 CLZ9R018V 2 *
L3208 nsp FERRITE CHIP BEAD(2012/220R, CB05YTYH221) CB05YTYH221 CLZ9R018V 1 *
L3211 nsp RES, CHIP(2012/5%/0ohm) CRJ18AJ0R0T 1
L3212 nsp COIL, CHOKE CHIP(2012/180R) DLW21SN181SQ2L/MURATA CLZ9Z127Z 1
L3216 nsp RES, CHIP(2012/5%/0ohm) CRJ18AJ0R0T 1
L3217,3218 nsp FERRITE CHIP BEAD(2012/220R, CB05YTYH221) CB05YTYH221 CLZ9R018V 2 *
L3900-3902 nsp FERRITE CHIP BEAD(2012/220R, CB05YTYH221) CB05YTYH221 CLZ9R018V 3 *
L5001-5012 nsp FERRITE CHIP BEAD(1608/60R, CB03YTYH600) CB03YTYH600 CLZ9R005V 12 *
X1201 943141100720S X-TAL, SMD 3.2X2.5, 27.000MHz, 10PF 7V27000050 TXC COX27000I100ST 1
X1501 943141100720S X-TAL, SMD 3.2X2.5, 27.000MHz, 10PF 7V27000050 TXC COX27000I100ST 1
X2001 943141100610S X-TAL, SMD 3.2X2.5, 12.000MHz, 10PF 7V12000005 TXC COX12000I100ST 1
X2301 943141100730S X-TAL, SMD 3.2X2.5, 16.000MHz, 9PF 7V16000001 TXC COX16000I090ST 1
X3900 943141100640S X-TAL, SMD 3.2X2.5, 24.000MHz, 8PF 7V24000002 TXC COX24000I080ST 1
X4001 943141100620S X-TAL, SMD 3.2X2.5, 24.576MHz, 12PF 7V24500006 TXC COX24576I120ST 1
X4002 943141101000D X-TAL, SMD 3.2X2.5, 21.875MHz, 12PF 7V21800001 TXC COX21875I120ST 1 *
X4201 943141100740S X-TAL, SMD 3.2X2.5, 25.000MHz, 12PF 7V25000009 TXC COX25000I120ST 1
X5001 943141100720S X-TAL, SMD 3.2X2.5, 27.000MHz, 10PF 7V27000050 TXC COX27000I100ST 1
