Denon AVR-X4000 - Page 221

SMPS
SMPS PCB ASS'
Y
※Parts indicated b
y
"ns
p
" on this table cannot be su
pp
lied.
※The
p
arts listed below are onl
y
for maintenance. Therefore the
y
mi
g
ht differ from the
p
arts used in the unit in a
pp
earances or dimensions.
NOTE:The symbols in the column Remarks indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model E1C : China model E1 : Asia model K : Japan model
BK : Black model SP : Premium Silver model
REF No. Part No. Part Name Remarks Q't
y
New
V
e
r
SEMICONDUCTORS GROUP
D9001-9006 00D9630328409 DIODE , RECTIFIER, AXIAL CVD1N4007ST 6
D9008,9009 00D9630328409 DIODE , RECTIFIER, AXIAL CVD1N4007ST 2
D9010 00D9430182609 DIODE , SWITCHING 1SS133/HOMI(HK) COMPANY LTD CVD1SS133MT 1
D9012 943209500030S DIODE, LOW FORWARD SCHOTTKY RECTIFIER SRL3060P/MIC CVDSRL3060P 1
D9013 963209010430S DIODE, RECTIFIER (1000V) AP01C CVDAP01CT 1
! IC901 231010091708S I.C , OFF-LINE POWER SWITCH TOP258MG PI CVITOP258MG 1
! IC902 963239010480S I.C , PHOTOCOUPLER PC123Y22FZ0F BRAND CVIPC123Y22FZ0F 1
IC903 212050010508S I.C,SHUNT REGULATOR(TO-92) KIA2431AP CVIKIA2431AP 1
Q9001-9003 00D9430154404 T.R KTC3198Y HVTKTC3198YT 3
ZD901 00D2760762958 DIODE , ZENER ,1/2W, 39V ZJ39B/HOMI(H.K) COMPANY LTD E3/K CVDZJ39BT 1
ZD902 00D2760762958 DIODE , ZENER ,1/2W, 39V ZJ39B/HOMI(H.K) COMPANY LTD E3/K CVDZJ39BT 1
ZD903 963202010440S DIODE , ZENER ,1/2W, 22V ZJ22B/HOMI(H.K) COMPANY LTD E3 CVDZJ22BT 1
ZD903 00D2760762958 DIODE , ZENER ,1/2W, 39V ZJ39B/HOMI(H.K) COMPANY LTD E2/E1C CVDZJ39BT 1
ZD903,904 00D9430101101 WIRE, COPPER(D0.6) CU97.8/SN2.1, D0.6 K C3A206 2
ZD904 00D2760762958 DIODE , ZENER ,1/2W, 39V ZJ39B/HOMI(H.K) COMPANY LTD E2/E1C CVDZJ39BT 1
ZD905 00D9430101101 WIRE, COPPER(D0.6) CU97.8/SN2.1, D0.6 E3/K C3A206 0.02
ZD905 00D2760762958 DIODE , ZENER ,1/2W, 39V ZJ39B/HOMI(H.K) COMPANY LTD E2/E1C CVDZJ39BT 1
ZD906 00D9430101101 WIRE, COPPER(D0.6) CU97.8/SN2.1, D0.6 E3/K C3A206 0.02
ZD906 00D2760762958 DIODE , ZENER ,1/2W, 39V ZJ39B/HOMI(H.K) COMPANY LTD E2/E1C CVDZJ39BT 1
ZD907 00D9430101101 WIRE, COPPER(D0.6) CU97.8/SN2.1, D0.6 E3/K C3A206 0.02
ZD907-910 00D2760762958 DIODE , ZENER ,1/2W, 39V ZJ39B/HOMI(H.K) COMPANY LTD E2/E1C CVDZJ39BT 4
ZD911-918 963202010440S DIODE , ZENER ,1/2W, 22V ZJ22B/HOMI(H.K) COMPANY LTD CVDZJ22BT 8
ZD919 00D9600095607 DIODE , ZENER ,1/2W, 5.6V ZJ5.6B/HOMI(H.K) COMPANY LTD CVDZJ5.6BT 1
ZD920 00D2760762958 DIODE , ZENER ,1/2W, 39V ZJ39B/HOMI(H.K) COMPANY LTD CVDZJ39BT 1
RESISTOR GROUP
R9002,9003 nsp RES, CARBON(1/5W,1Mohm,J) CRD20TJ105T 2
R9004 00MGD05474160 RES, CARBON(1/5W,470Kohm,J) CRD20TJ474T 1
R9005 nsp RES, CHIP(1608/5%/47ohm) CRJ10DJ470T 1
R9006 nsp RES, CHIP(1608/5%/1Mohm) CRJ10DJ105T 1
R9007 00MNN05274610 RES, CHIP(1608/5%/270Kohm) CRJ10DJ274T 1
R9008,9009 00MGD05225160 RES, CARBON(1/5W,2.2Mohm,J) E3/K CRD20TJ225T 2
R9010 nsp RES, CARBON(1/5W,1Mohm,J) E3/K CRD20TJ105T 1
R9013 nsp RES, CHIP(1608/5%/10ohm) CRJ10DJ100T 1
R9014 00MNN05274610 RES, CHIP(1608/5%/270Kohm) E3/K CRJ10DJ274T 1
R9014 00MNN05563610 RES, CHIP(1608/5%/56Kohm) E2/E1C CRJ10DJ563T 1
R9015 nsp RES, CHIP(1608/5%/15Kohm) CRJ10DJ153T 1
R9016 nsp RES, CHIP(1608/5%/1Kohm) CRJ10DJ102T 1
R9017 nsp RES, CARBON(1/5W,6.8ohm,J) CRD20TJ6R8T 1
R9018 00MGD05560160 RES, CARBON(1/5W,56ohm,J) CRD20TJ560T 1
R9019 nsp RES, CARBON(1/5W,3.3Kohm,J) CRD20TJ332T 1
R9020 00MGD05562160 RES, CARBON(1/5W,5.6Kohm,J) CRD20TJ562T 1
R9021 nsp RES, CHIP(1608/1%/22Kohm) CRJ10DF2202T 1
R9024 nsp RES, CHIP(1608/1%/6.8Kohm) CRJ10DF6801T 1
R9025 nsp RES, CHIP(1608/5%/1Mohm) CRJ10DJ105T 1
R9026 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R9027 nsp RES, CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 1
! R9031-9034 943121500030S RES, CHIP(2012/5%/2.2Mohm) CRJ18AJ225T 4
ZD902 nsp RES, CARBON(1/5W,1Mohm,J) E2/E1C CRD20TJ105T 1
ZD901 nsp RES, CARBON(1/5W,1Mohm,J) E2/E1C CRD20TJ105T 1
CAPACIITORS GROUP
! C9001-9003 963132011940S CAP, CERAMIC(X1/Y2,0.01uF,AC250V) DE2F3KY103MB3BM02 CCKDKY103MFM 3
C9004 943134501590S CAP, ELECT(200V/100uF),105'C NHA 200VB 100M(16*20L) E3/K CCET200NHA101E
S
1
C9004 963134010200S CAP , ELECT (400V/100UF, 18X40, NHA) NHA400VB100M/SAMYOUNG E2/E1C CCET400NHA101E
S
1
C9006-9008 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC 3
C9009 00D9430175108 CAP, ELECT(50V/10uF),105'C 5X11L/105/NXA/SAMYOUNG CCEA1HNXA100TS 1
C9010 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC 1
C9012 963132010120S CAP, CERAMIC(DC1KV/1000pF) DEHR33A102KB2B CCKDDEH102KCM 1
C9016 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC 1
C9017 00MOA47602520 CAP, ELECT(25V/47uF),105'C 5X11L/105/NXA/SAMYOUNG CCEA1ENXA470TS 1
C9018 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC 1
C9019 nsp CAP, CHIP(1608, 6.3V/4.7uF, MURATA GRM18) CCUS0J475KC 1
C9020-9022 963134010220S CAP, ELECT(6.3V/5600uF) NXA6.3VB 5600M 5.0MC(12.5*35L) CCEA0JNXA562ES 3
C9024 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC 1
! C9028 963132011930S CAP, CERAMIC(X1/Y1,2200P,AC250V) DE1E3KX222MB4BL01 CCKDKX222MEM 1
C9029 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC 1
OTHER PARTS GROUP
BK901,902 nsp BRACKET , PCB M3 CMD1A834 2
BK903 nsp BRACKET , PCB CMD1A629 1
BN903 nsp WIRE ASS'Y LOCKING (5P,2.5MM,350MM,UL1569#22,105) CWB7D0053503D 1 *
CN901 nsp WAFER, 2P, 3.96mm CJP02KA060ZY 1
CN902 nsp WAFER, 2P, 7.92mm YW396-02AB/YEONHO CJP02GA89ZY 1
! CX901 943139500020S CAP , POLYPROPYLENE FILM (0.1uF/275VAC) M-CMP2D104ML12T CCQF2E104KZE-T 1
! CY901,902 963134011730S CAP, CERAMIC(X1/Y1,470P,AC250V) DE1B3KX471KB4BL01 CCKDKX471KBM 2
F9001,9002 nsp HOLDER , FUSE CJCFC5S 2
J9001-9003 00D9430101101 WIRE, COPPER(D0.6) CU97.8/SN2.1, D0.6 C3A206 3
J9011-9020 00D9430101101 WIRE, COPPER(D0.6) CU97.8/SN2.1, D0.6 C3A206 10
! LF902 963111010230S LINE FILTER, 27uH LF-4ZB-E273H/KORIN E3/K CLZ9Z126Z 1
! LF902 943111100410S LINE FILTER, 50uH LF-4ZB-E503H/KORIN E2/E1C CLZ9Z133Z 1
! RY901 963682010370S RELAY,HL31-1AT-5H,DC5V,1C1P HL31-1AT-5H/HANDOUK CSL1C006ZE 1
! T9001 943102100350S TRANS , SWITCHING STR28L-979C XINHUA CLT9Z093ZE 1
★ nsp RUBBER , TRANS CHG1A587 1 *
★ nsp SHEILD , TRANS COVER CMC1A445 1 *
