Denon AVR-X4000 - Page 222

EXPLODED
EXPLODED
※Parts indicated b
y
"ns
p
" on this table cannot be su
pp
lied.
※The
p
arts listed below are onl
y
for maintenance. Therefore the
y
mi
g
ht differ from the
p
arts used in the unit in a
pp
earances or dimensions.
NOTE:The symbols in the column Remarks indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model E1C : China model E1 : Asia model K : Japan model
BK : Black model SP : Premium Silver model
REF No. Part No. Part Name Remarks Q't
y
New
V
e
r
- nsp FRONT PCB AUTO ASS'Y E3/E2/K CIP12434F 1
- nsp FRONT PCB AUTO ASS'Y E1C CIP12434H 1
C1 - FRONT PCB ASS'Y COP12434F/H-1,2 -
C2 - FRONT PCB ASS'Y COP12434F/H-3
C3 - FRONT PCB ASS'Y COP12434F/H-4 -
- 9U6391011400D DIGITAL PCB MANUAL ASS'Y E3 COP12525B 1 *
- 9U6391011500D DIGITAL PCB MANUAL ASS'Y E2 COP12525C 1 *
- 9U6391011600D DIGITAL PCB MANUAL ASS'Y E1C COP12525E 1 *
- 9U6391011700D DIGITAL PCB MANUAL ASS'Y K COP12525D 1 *
C4 - DIGITAL PCB ASS'Y COP12525B/C/D/E-
2
-
C20 - DIGITAL PCB ASS'Y COP12525B/C/D/E-1 -
- nsp SPK PCB MANUAL ASS'Y E3 COP12521B 1 *
- nsp SPK PCB MANUAL ASS'Y E2 COP12521C 1 *
- nsp SPK PCB MANUAL ASS'Y E1C COP12521E 1 *
- nsp SPK PCB MANUAL ASS'Y K COP12521D 1 *
C7 - MAIN PCB ASS'Y COP12521B/C/D/E-
4
-
C13 - MAIN PCB ASS'Y COP12521B/C/D/E-
3
-
C14 - MAIN PCB ASS'Y COP12521B/C/D/E-1 -
C17 - MAIN PCB ASS'Y COP12521B/C/D/E-
2
-
C19 - MAIN PCB ASS'Y COP12521B/C/D/E-
6
-
C8 nsp AMP PCB MANUAL ASS'Y E3/E2/K COP12385E 1
C8 nsp AMP PCB MANUAL ASS'Y E1C COP12385F 1
- nsp CNT PCB MANUAL ASS'Y E3 COP12522B 1 *
- nsp CNT PCB MANUAL ASS'Y E2 COP12522C 1 *
- nsp CNT PCB MANUAL ASS'Y E1C COP12522E 1 *
- nsp CNT PCB MANUAL ASS'Y K COP12522C 1 *
C12 - CNT PCB ASS'Y COP12522B/C/E-1 -
C15 - CNT PCB ASS'Y COP12522B/C/E-2 -
- nsp INPUT PCB MANUAL ASS'Y E3/K COP12523B 1 *
- nsp INPUT PCB MANUAL ASS'Y E2 COP12523C 1 *
- nsp INPUT PCB MANUAL ASS'Y E1C COP12523E 1 *
C5 - INPUT PCB ASS'Y COP12523B/C/E-2 -
C10 - INPUT PCB ASS'Y COP12523B/C/E-3 -
C16 - INPUT PCB ASS'Y COP12523B/C/E-1 -
- nsp VIDEO PCB MANUAL ASS'Y E3/E2/K COP12524B 1 *
- nsp VIDEO PCB MANUAL ASS'Y E1C COP12524E 1 *
C9 - VIDEO PCB ASS'Y COP12524B/E-2 -
C18 - VIDEO PCB ASS'Y COP12524B/E-1 -
C6 nsp SMPS PCB ASS'Y E3 COP12526R 1 *
C6 nsp SMPS PCB ASS'Y E2 COP12526S 1 *
C6 nsp SMPS PCB ASS'Y K COP12526T 1 *
C6 nsp SMPS PCB ASS'Y E1 COP12526U 1 *
M1 41201007500AD VOLUME KNOB ASS'Y BK CGK1A166ZA 1
M1 41201007501AD VOLUME KNOB ASS'Y SP CGK1A166YA 1
M2 41201007600AD SELECT KNOB ASS'Y BK CGK1A167ZA 1
M2 41201007601AD SELECT KNOB ASS'Y SP CGK1A167YA 1
M3
42141002400AD BADGE , DENON BK CGB1A254Z-V1 1
M3 42141002401AD BADGE , DENON SP CGB1A254Y-V1 1
M4 943402103710D PANEL , AL FRONT E3 CKM1A244UC45 1 *
M4 943402103720D PANEL , AL FRONT BKE2 CKM1A244TC45 1 *
M4 943402103730D PANEL , AL FRONT SPE2 CKM1A244SC62 1 *
M4 943402103740D PANEL , AL FRONT K CKM1A244RC45 1 *
M4 943402103750D PANEL , AL FRONT SPE1C CKM1A244QC62 1
M5 943415100330D DOOR , AL BK CKM1A245C45 1
M5 943415100340D DOOR , AL SP CKM1A245C62 1
M6 00M10BW305010 MAGNET CJC1A008 1
M7 nsp EARTH , DOOR CMC1A433 1
M8 nsp BRACKET , FRONT CMD1A804 1
M9 00M07BW257010 CABINET , TOP BK CKC2A155K117 1
M9 943403002040M CABINET , TOP SP CKC2A155D11 1
M10 nsp SMPS BRACKET CMD1A790 1
M11 nsp CHASSIS , BOTTOM CUA5A330 1 *
M12 nsp HEATSINK CMY2A376 1
M13 nsp BRACKET , PCB (AMP) CMD1A796 5
M14 nsp PCB BRACKET (HDMI) CMD1A791 1
M15 nsp PANEL , REAR CKF1A469Z 1 *
M15 nsp PANEL , REAR BKE2, SPE2 CKF2A469Z 1 *
M15 nsp PANEL , REAR K CKF2A469Y 1 *
M15 nsp PANEL , REAR SPE1C CKF2A469X 1 *
M16 42141002600AD BADGE , IN COMMAND CGB1A268Z 1
P1 963416100980D WINDOW , VFD CGU1A463Z 1
P2 943451101230D SHEET , SELECT KNON CGX1A473 1
P3 943451101210D SHEET , VOLUME KNOB CGX1A474 1
P4 42451003000AD RING , SELECT KNOB BK CGR1A536 1
P4 42451003001AD RING , SELECT KNOB SP CGR1A536C73 1
P5 42451002900AD RING , VOLUME KNOB BK CGR1A535 1
P5 42451002901AD RING , VOLUME KNOB SP CGR1A535C73 1
P6 943415100350D HOLDER , DOOR BK CKG1A056 1
P6 943415100360D HOLDER , DOOR SP CKG1A056G45 1
P7 943413100390D CAP , DOOR CHG1A551 1 *
P8 943421100280D ORNAMENT , SHEET BK CGX1A470X 1 *
P8 943421100290D ORNAMENT , SHEET SP CGX1A470W 1 *
P9 00M446T056010 STOPPER , AL DOOR CHG1A296Y 2
P10 943402103760D PANEL , INNER BK CGW2A521 1 *
P10 943402103770D PANEL , INNER SP CGW2A521G45 1 *
P11 943423100310D INDICATOR , POWER CGL1A299 1
P12 943411101750D BUTTON , POWER BK CBT1A1167 1
P12 943411101760D BUTTON , POWER SP CBT1A1167C73 1
P13 nsp COVER , DOOR A CMH1A329 1
P14 943474004230M DAMPER , GEAR CDG1A027W 1
P15 943411101870D BUTTON , ENTER CBT1A1165 1
P16 nsp COVER , DOOR B CMH1A330 1
P17 nsp CUSHION CHG1A590 1 *
P18 nsp FOOT CKL1A093 4
P19 nsp CUSHION , FOOT CHG2A289 4
P20 nsp RUBBER CHG1A113 4
P21 nsp HOLDER , PCB CHE170 3
