EXPLODED
REF No. Part No. Part Name Remarks Q't
y
New
V
e
r
P22 943419100250D SHEET , TOP BK CGX1A492Z 2
P22 943419100260D SHEET , TOP SP CGX1A492Y 2
P23 45451000500AM STOPPER , SHEET BK CMH1A306Z 8
P23 45451000501AM STOPPER , SHEET SP CMH1A306Y 8
P24 nsp SUPPORT , PCB CRE1A102 1
P25 nsp SUPPORT , PCB 31 CRE1A073 1
P26 nsp SUPPORT , RUBBER CHG1A535 1
C11 943101102100S TRANS , POWER(EI96 X 75) E3 CLT5V065ZU 1 *
C11 943101102110S TRANS , POWER(EI96 X 75) E2 CLT5V065ZE 1 *
C11 943101102120S TRANS , POWER(EI96 X 75) E1C CLT5V065ZH 1 *
C11 943101102130S TRANS , POWER(EI96 X 75) K CLT5V065ZJ 1 *
C22 nsp TERMINAL GROUND E3 CMA1A006 1
C21 943183100370D TUNER , MODULE(HD RADIO) UMH-AVR E3 CNVUMH-AVR 1 *
S1 nsp SCREW , DOT BK CTBD3+10JFZR 10
S1 nsp SCREW , DOT SP CTBD3+10JFN 10 *
S2 nsp SCREW CTW3+8JR 15
S3 nsp SCREW CTB3+10JR 13
S4 nsp SCREW CTB3+8JR 21
S5 nsp SCREW , SPECIAL CHD1A012ZR 21
S6 nsp SCREW CTW3+12JR 5
S7 nsp SCREW CTB3+6JR 2
S8 nsp SCREW CTB3+6FR 6
S9 nsp SCREW , DOT BK CTBD3+8JFZR 38
S9 nsp SCREW , DOT SP CTBD3+8JFZR 35
S10 nsp SCREW , DOT E3 CTBD3+6FFZR 13
S10 nsp SCREW , DOT E2,E1C,K CTBD3+6FFZR 12
S11 nsp SCREW , DOT BK CTBD4+8JFZR 6
S11 nsp SCREW , DOT SP CTBD4+8JFN 6
S12 nsp SCREW , TRANS CHDR1A023R 4
S13 nsp SCREW CTB3+8JFZ 2
S14 nsp SCREW , DOT SP CTBD3+8JFN 3 *
★ nsp BOTTOM CHASSIS ASS'Y E3 CUAAVRX4000BKE
3
1*
★ nsp BOTTOM CHASSIS ASS'Y BKE2 CUAAVRX4000BKE
2
1*
★ nsp BOTTOM CHASSIS ASS'Y SPE2 CUAAVRX4000SPE
2
1*
★ nsp BOTTOM CHASSIS ASS'Y SPE1C CUAAVRX4000SPE
1
1*
★ nsp BOTTOM CHASSIS ASS'Y K CUAAVRX4000K 1 *
★ nsp CUSHION , SUPPORT CHG1A305 2
RT01 00MYJ04002640 RECEPTACLE , AC(15A/250V,R-301,B21) R-301(B21) CJJ8A006ZW 1
TW91 nsp 2P WIRE ASS'Y(100MM) CWZPM5003TW91 1
★ nsp 2P WIRE ASS'Y(100MM) CWZPM5003TW91A 1
★ 943606501600S CARD CABLE(1mm/23P/300mm/B) CWC4F2A23A300B1 1
★ 943606502040D CARD CABLE(1mm/40P/250mm/B/sheild) CWC4F2A40A250B
0
1*
★ 943606501260S CARD CABLE(1.25mm/13P/80mm/B) E3 CWC4F2A13B080B1 1
★ nsp ORNAMENT , REAR PANEL CGX1A488Z 1 *
★ nsp ORNAMENT , REAR PANEL CGX1A489Z 1 *
★ nsp LOCKER SH08M790BO E2/E1C CRE1A037 22
! F9001 963652010510S FUSE(S506 Series, 250V,2A) S506-2A E3/K CBA2C2000TLEC 1
! F9001 963652010500S FUSE(S506 Series, 250V,1.6A) S506-1.6A E2/E1C CBA2C1600TLEC 1
！ F9002 90M-FS001430R FUSE(218Series, 250V/6.3A) 021806.3.MXP E3 KBA2C6300TLEY 1
! F9002 90M-FS001490R FUSE(218Series, 250V/4A) 0218004.MXP E2/E1C KBA2C4000TLEY 1
！ F9002 90M-FS001220
R
FUSE
(
218Series, 250V/8A
)
K KBA2C8000TLE
Y
1
! F9331 963652010510S FUSE(S506 Series, 250V,2A) S506-2A CBA2C2000TLEC 1
! F9332 963652010510S FUSE(S506 Series, 250V,2A) S506-2A CBA2C2000TLEC 1
! F9333 963652010910S FUSE(S506 Series, 250V,3.15A) S506-3.15A CBA2C3150TLEC 1
! F9334 963652010910S FUSE(S506 Series, 250V,3.15A) S506-3.15A CBA2C3150TLEC 1
! F9335 963652010910S FUSE(S506 Series, 250V,3.15A) S506-3.15A CBA2C3150TLEC 1
